Originalbetriebsanleitung / Original owner's manual / Notice originale / Istruzioni originali / Manual original / Původní
návod k používání / Eredeti használati utasítás / Izvirna navodila / Pôvodný návod na použitie / Instrukcja oryginalna /
Instrucțiuni originale / Originalne upute / Оригинална инструкция / Orijinal kullanım talimatları
Schwimmbadreiniger
Poolrunner Battery+
Schwimmbadreiniger......................................... 4
de
Nettoyeur de piscine........................................49
fr
Limpiafondos de piscina.................................. 95
es
Úszómedence tisztító..................................... 140
hu
Čistič bazénu.................................................. 186
sk
Dispozitiv de curățare a piscinei................... 231
ro
Уред за почистване на басейни................ 278
bg
Pool cleaner......................................................27
en
Pulitore per piscina...........................................72
it
Čistič bazénů................................................... 1 18
cs
Čistilnik bazena..............................................163
sl
Odkurzacz basenowy...................................208
pl
Čistač bazena................................................255
hr
Yüzme havuzu temizleyicisi.......................... 302
tr

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Poolrunner Battery+ and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Steinbach Poolrunner Battery+

Summary of Contents for Steinbach Poolrunner Battery+

  • Page 1 Originalbetriebsanleitung / Original owner's manual / Notice originale / Istruzioni originali / Manual original / Původní návod k používání / Eredeti használati utasítás / Izvirna navodila / Pôvodný návod na použitie / Instrukcja oryginalna / Instrucțiuni originale / Originalne upute / Оригинална инструкция / Orijinal kullanım talimatları Schwimmbadreiniger Poolrunner Battery+ Schwimmbadreiniger.........
  • Page 3 Lieferumfang/Geräteteile Schutzkappe Oberteil Filtereinheit Unterteil Bürste Schwimmgriff mit Nylonschnur Ladegerät Drehschalter Düse Statusanzeige Griff Ladestecker Betriebsanleitung (ohne Abbildung)

  • Page 4: Package Contents/Components

    Package contents/components Protective cap Top part Filter unit Bottom part Brush Floating handle with nylon cord Charger Rotary switch Nozzle Status indicator Handle Charging plug Operating instructions (without illustration)

  • Page 5: Table Of Contents

    Contents Overview........................2 Package contents/components..................26 General Information....................28 Explanation of Symbols....................28 Safety.......................... 29 Unpacking and checking the package contents............33 Description........................33 Basic settings.......................34 Charging the rechargeable battery................34 Adjusting the nozzles....................35 Attaching the floating handle..................36 Attaching the brush...................... 37 Removing the brush.....................

  • Page 6: General Information

    General Information Read and keep the operating instructions These operating instructions are part of the Pool Runner Battery+ pool cleaner (in the following also called "device"). It contains important information about startup and operation. Read the operating instructions and especially the safety instructions carefully before using the device.

  • Page 7: Safety

    Lithium ion batteries in equipment or lithium ion batteries packaged with equipment. UN 3481 Weight of the packaging unit. Dimensions of the packaging unit. Only use the charger indoors This symbol identifies devices that belong to the protection class II. Safety The following signal words are used in this user manual.
  • Page 8 - Only connect the power cable to an easily accessible socket so that you can quickly disconnect it in the case of a fault. - Only connect the power cable to a grounded socket. - Only operate the device on a grounded socket secured with at least 16A.
  • Page 9 - Only use spare parts and accessory parts supplied or recommended by the manufacturer. All warranty claims will be void when using third-party components. - Do not operate the device with an external timer or a separate remote system. NOTICE! - Never let the device run outside of the water as this can cause damage even after a short time.
  • Page 10 WARNING! Risk of injury through insufficient qualification! Insufficient experience or skills for handling the required tools and insufficient knowledge of regional or normative regulations for the required work can lead to severe injuries or material damage. - Assign all work whose risks you cannot estimate due to insufficient personal experience to a qualified expert.

  • Page 11: Unpacking And Checking The Package Contents

    Unpacking and checking the package contents NOTICE! Careless opening of the packaging, especially with the help of sharp or pointed objects, may cause damage to the device. - Open the packaging very carefully. - Do not penetrate the packaging with sharp or pointed objects. WARNING! Packaging materials pose a risk of suffocation! Catching your head in the packaging foil or swallowing other...

  • Page 12: Basic Settings

    The adjustable nozzles determine the travel path and the speed of the pool cleaner. The removable filter unit filters the water and collects deposits in the pool. Depending on the degree of soiling, an optional brush can improve the cleaning result. When the rechargeable battery is drained, the pool cleaner stops cleaning.

  • Page 13: Adjusting The Nozzles

    2. Take the protective cap off the charging plug matching connectors (groove direction), vertically aligned, same view direction 3. Connect the charger to the device. 4. Plug the charger into a socket. The charge control indicator is lit red. The rechargeable battery is charging. 5.

  • Page 14: Attaching The Floating Handle

    0°/30° (for most pools) 0°/40° (to cover a large cleaning area) 20°/20° (for round pools) Attaching the floating handle Attach the floating handle so you can place the device in the pool and take it out of the pool in a controlled manner.

  • Page 15: Attaching The Brush

    1. Guide the end of the nylon cord of the floating handle through the eyelet on the top part 2. Shorten the nylon cord to a length that roughly corresponds to the depth of your pool and tie it in a knot. The floating handle is attached.

  • Page 16: Operation

    Operation Check the following before each use: - Is there visible damage on the device? - Is there visible damage on the control elements? - Do all individual parts function? - Are the accessories in perfect condition? - Are all cables in perfect condition? Do not start up a damaged device or damaged accessories.
  • Page 17 2. Push the top part onto the bottom part until it has snapped into place on both sides. The filter unit is inserted. Placing the device in the pool and starting cleaning CAUTION! Risk of injury! The device can hurt persons in the pool. - Make sure no one is in the pool while the device is in the water.

  • Page 18: Switching Off The Device

    2. Hold the device by the handle lower it slowly into the water until all the air has escaped. The device should run at a right angle to the pool wall. 3. Set the rotary switch to ON. The device switches itself on automatically as soon as it is fully immersed in the water.

  • Page 19: Cleaning

    The status indicator blinks red once and the device switches itself off. 3. Slowly lift the device out of the water by the handle and hold it above the water surface for 10 to 15 seconds so that most of the water can flow back into the pool. 4.

  • Page 20: Storage

    2. Take the filter unit out of the bottom part 3. Thoroughly rinse the filter unit with plain tap water. 4. Rinse the device after each use with plain tap water inside and out. The device is clean. Storage 1. Thoroughly clean the device (see section "Cleaning"). 2.
  • Page 21 Fault description Cause Remedy The device cannot reach all The nozzle setting is not Change the setting of the spots. suitable. nozzles. The water circulation of the Switch off the filter system of pool is switched on. the pool. The device does not work and The pump is running dry.

  • Page 22: Technical Data

    Technical data Model 061013 Type of rechargeable battery Lithium ion Rechargeable battery capacity 6600 mAh Charging time 5 to 6 hours Battery runtime up to 120 min Safety class IPX8 Ambient temperature 10 °C to 40 °C Operating temperature (water) 10 °C to 35 °C pH value 7.0 to 7.4...

  • Page 23: Spare Parts

    Spare parts...
  • Page 24 061981 - floating handle 061984 - vibrating plate 061986 - nozzle 061982 - drive unit cover 061985 - safety rod system 2 long 061983 - safety rod system 1 short 061980 - side cover 061987 - motor/pump unit with rechargeable battery 061988 - safety grate motor/pump unit 061990 - filter insert 061989 - spring for filter valve...

  • Page 25: Declaration Of Conformity

    Declaration of Conformity Steinbach International GmbH hereby declares that the device meets the following directives: - 2014/35/EU (EN 60335‑1:2012+A11:2014+A13:2017; EN 60335‑2‑41:2003+A1:2004+A2:2010; EN 62233:2008) - 2014/30/EU (EN 55014‑1:2006+A1:2009+A2:2011; EN 55014‑2:2015; EN 61000‑3‑2:2014; EN 61000‑3‑3:2013) You can request the complete text of the EU Declaration of Conformity from the address stated at the end of this instruction manual.
