N1 Developer Suite User Guide
Version 1.1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the N1 and is the answer not in the manual?

Questions and answers

Related Manuals for Neoway N1

Summary of Contents for Neoway N1

  • Page 1 N1 Developer Suite User Guide Version 1.1...
  • Page 2 Neoway provides customers complete technical support. If you have any question, please contact your account manager or email to the following email addresses: Sales@neoway.com...
  • Page 3 N1 Developer Suite User Guide Revision Record Issue Changes Date V1.0 Initial draft 2016-06 V1.1 Modified the test command to *#11*# 2018-03 Copyright © Neoway Technology Co., Ltd...

  • Page 4: Table Of Contents

    N1 Developer Suite User Guide Contents 1 About N1 Developer Suite ....................1 2 N1 Developer Suite Hardware ..................2 2.1 Front View and Interfaces ........................2 2.2 Rear View ............................. 3 3 Testing N1 Developer Suite ....................4 3.1 Buttons and Functions .......................... 4 3.2 Power Supply/Power On/Power Off ....................

  • Page 5: About N1 Developer Suite

    N1 Developer Suite User Guide 1 About N1 Developer Suite N1 developer suite contains a series of peripheral interfaces, including main power interface, USB interface to download programs, commissioning interface, GPIO, TF-card interface, SIM card interface, etc. You can commission the module after connecting to the power supply and USB cable. For information about how to update the module, refer to the module upgrade guide.

  • Page 6: N1 Developer Suite Hardware

    N1 Developer Suite User Guide 2 N1 Developer Suite Hardware 2.1 Front View and Interfaces Copyright © Neoway Technology Co., Ltd...

  • Page 7: Rear View

    N1 Developer Suite User Guide 11. Three-axis accelerometer 20. GPS antenna connector N1 module 12. Three-axis magnetometer 21. Sub antenna connector DC power supply interface 13. Six-axis gyroscope 22. UART2 Battery interface 14. Proximity sensor 23. UART1 Power supply switch 15.

  • Page 8: Testing N1 Developer Suite

    Power up the N1 developer suite, hold this button, and then connect the suite to a computer through a USB cable. The module enters forcible download mode. If this button is pressed after the suite is powered up and started, the N1 module will not enter forcible download mode.

  • Page 9: Power Supply/Power On/Power Off

    N1 Developer Suite User Guide Vol+  After the N1 developer suite is powered up, press this button to increase the volume. Vol-  After the N1 developer suite is powered up, press this button to decrease the volume. 3.2 Power Supply/Power On/Power Off 3.2.1 Power Supply...
  • Page 10 N1 Developer Suite User Guide Step 1 Connect the battery to "3. Battery interface". Do not connect the battery to UART1 or UART2. Otherwise, the module will be damaged. Step 2 Switch "4. Power supply switch" to BATT. The LED indicator will turn on after the battery connected properly.

  • Page 11: Power On/Off

    N1 Developer Suite User Guide 3.2.2 Power On/Off The bottom left button among "28. Buttons" is the ON/OFF button. Hold it for 2 seconds after the module is powered on, and the module will start. ON/OFF Hold the PWRKEY button for 2 seconds, and the LCD screen will display a dialog box. Tap Power off and then OK to power off the module.

  • Page 12: Function Test

    N1 Developer Suite User Guide Hold the Reset button for 5 seconds, and the module will reset automatically. 3.3 Function Test On the dialing screen, tap "*#11*#" to enter the factory testing mode. 3.3.1 Testing All Items Tap Auto to start test on all items.

  • Page 13: Testing Single Item

    N1 Developer Suite User Guide If the items work properly, they will become green. Otherwise, the items will become red. If the following dialog box is displayed during the test, tap Pass or Fail to go on testing next item.

  • Page 14: Sim Card

    N1 Developer Suite User Guide 3.4 SIM Card Both SIM_1 and SIM_2 support 4G TDD-LTE and FDD-LTE, 3G TD-SCDMA and EV-DO, as well as 2G CDMA 1X and GSM. The module do not support SIM card plug-and-play.  SIM_1 and SIM_2 can be set to 2G simultaneously.

  • Page 15: Audio Interface And Volume

    You can adjust the volume by pressing Vol+ or Vol- among "28. Buttons". 3.6 USB/OTG Interface "7. USB/OTG" connects N1 developer suite to a PC. The USB connection is used for data transferring between computer and the module, APK installation through computer, and software upgrade.

  • Page 16: Testing Interfaces

    N1 Developer Suite User Guide The USB interface can also used to charge the li-ion battery when battery is used to supply power for the module. The BAT_THERM pin should be connected. 3.7 Testing Interfaces This demo board provides several GPIOs, two UARTs, and other interfaces, supporting 1.2V, 1.8V and 2.85V standard level.
  • Page 17 N1 Developer Suite User Guide Test the vibration effect of "23. Motor". Copyright © Neoway Technology Co., Ltd...

  • Page 18: Material List

    N1 Developer Suite User Guide 4 Material List N1 developer suite  DC power supply  LCD screen  Main/sub camera  USB cable  USB-to-Serial cable  Antenna  Copyright © Neoway Technology Co., Ltd...
