- Page 1 HIGH POWER PLATING RECTIFIER USER MANUAL VOLTEQ...
- Page 2 Please read the user manual carefully before operating this rectifier. Warning: Do not connect any load to the rectifier before it's turned on. Likewise, make sure to disconnect the load before shutting down the rectifier. Damages to the rectifier may occur if you do not follow this.
- Page 3 DC rectifier. These rectifiers are great choice for anodizing, plating, electrolysis, hydrogen generation, and other applications that require high output power. The table below list the current models available from Volteq. Model Output Voltage...
- Page 4 (1) Power ON/OFF switch (2) Output adjustment knob (3) Output ON/OFF switch (4) Selection switch for CV (constant voltage) and CC operation (5) Amp meter (6) Volt meter...
- Page 5 2.2 Technical specifications Ripple and noise : ≤5% Voltage regulation : ≤0.5% Current regulation : ≤1% Load regulation : ≤0.5% Display accuracy: ±1%±1 digit Control accuracy: ≤1% Protection: Over-current, Over-voltage, Over-temperature Input voltage: AC220V±10% 50/60Hz Working conditions: -100C -400C, relative humidity<90%, no condensation Storage conditions: -200C-800C, relative humidity<80% Ventilation: minimum of 50cm of open space around the rectifier is required for good ventilation Elevation: ≤1500 Meters...
- Page 6 at the minimum position. 3. Plug into AC outlet, and then turn on the power switch (1). Check to make sure the fan is working. 4. Turn on the output (3). Select switch (4) to either "CV" or "CC" as your operating mode. If "CV" is selected, the output voltage will be stable while the output current will change with the load;...
- Page 7 Case is not grounded and is electrically hot some internal components may have failed All products from Volteq come with 1 year full manufacturer's warranty. For technical questions or warranty service, please contact us at support@volteq.com or call us at 408-622-9851.
