2022 F-150 Lightning

Meet the All-New F-150 Lightning

Ford is electrifying the Built Ford

Tough lineup with the all-new, all-

electric 2022 F-150 Lightning —

designed to be the smartest, most

connected, most innovative F-150

ever — with available Ford

BlueCruise hands-free highway

driving feature,

Mega Power Frunk,

(1)

9.6 kW of Pro Power Onboard and

Ford Intelligent Backup Power that

can power a home for up to three

days or up to 10 days if rationing

power.

(2)

Plus, the F-150 Lightning is designed

to provide the capability customers

expect with a targeted maximum

available trailer tow rating of

10,000 lbs.,

(3)

a targeted maximum

payload rating of 2,000 lbs.

dual eMotors creating a targeted

775 lb.-ft. of nearly instant torque.

The F-150 Lightning with the

available extended-range battery

oﬀers a targeted 300 miles of EPA-

estimated range.

F-150 Lightning

(6)

delivers all this capability while

expected to be certiﬁed as a zero

tailpipe emissions vehicle.

M e e t t h e 2 0 2 2 F -1 5 0

L i g h t n i n g — the all-new, all-

L i g h t n i n g

electric, lightning-quick pickup.

Coming in the Spring of 2022.

https://www.esourcebook.dealerconnection.com/content/ret-for.../electrified-vehicle/F-150-Lightning/2022.printable.vehicle.html

(4)

and

Key Launch Training Resources

(5)

With Launch Vehicles, it is especially important to keep up with product

information and training. Get all your key launch training resources — job aids,

videos, eLearning, Frontline articles and more.

G o t o Ke y L a u n c h Tr a i n i n g Re s o u r c e s > >

(7)

Preproduction vehicles shown throughout. Available Spring 2022.

1/26/22, 7:58 PM

Page 1 of 146
