- Page 1 SERVICE MANUAL TT35 / TT40 / TT45 Tractor Part number 47899736 English September 2015 © 2015 New Holland Fiat (India) Pvt.Ltd. All Rights Reserved.
- Page 2 SERVICE MANUAL TT35 2WD tractor , TT35 4WD tractor , TT40 2WD tractor , TT40 4WD tractor , TT45 2WD tractor , TT45 4WD tractor 47899736 29/09/2015 Find manuals at https://best-manuals.com...
- Page 3 Contents INTRODUCTION Engine..................10 [10.001] Engine and crankcase ............. 10.1 [10.102] Pan and covers .
- Page 4 [27.100] Powered rear axle..............27.1 [27.106] Rear bevel gear set and differential .
- Page 5 47899736 29/09/2015 Find manuals at https://best-manuals.com...
- Page 6 INTRODUCTION 47899736 29/09/2015 Find manuals at https://best-manuals.com...
- Page 7 Contents INTRODUCTION Foreword ..................3 Safety rules .
- Page 8 Anyone who carries out service operations described without carefully observing these prescriptions will be directly responsible for any damage caused. Notes for equipment Equipment which NEW HOLLAND proposes and shows in this manual is: - Studied and designed expressly for use on NEW HOLLAND tractors. - Necessary to make reliable repair.
- Page 9 INTRODUCTION Safety rules This warning symbol points out important messages involving personal safety. Carefully read the safety rules contained herein and follow advised precautions to avoid potential hazards and safeguarded your safety. In this manual you will find this symbol together with the following keywords. WARNING: It gives warning about improper repair operations and potential consequences affecting the service tech- nician’s personal safety.
- Page 10 INTRODUCTION Safety rules Generalities Carefully follow specified repair and maintenance procedures. • Do not wear rings, wrist watches, jewels, unbuttoned or flapping clothing such as ties, torn clothes, scarves, open jackets or shirts with open zips which could get caught in moving parts. Use approved safety clothing such as anti-slipping footwear, gloves, safety goggles, helmets, etc.
- Page 11 INTRODUCTION Electrical systems • If it is necessary to use auxiliary batteries, cables must be connected at both sides as follows. (+) to (+) and (-) to (-). Avoid short-circuiting the terminals. Gas released from batteries is highly flammable. During charging, leave the battery compartment uncovered to improve ventilation.
- Page 12 INTRODUCTION Safety rules Health and safety precautions Many of the procedures associated with vehicle maintenance and repair involve physical hazards or other risks to health. This section lists, alphabetically, some of these hazardous operations and the materials and equipment asso- ciated with them.
- Page 13 INTRODUCTION Isocyanate (polyurethane) adhesives / sealers See resin based adhesives. Individuals suffering from asthma or respiratory allergies should not work with or near these materials as sensitivity reactions can occur. Any spraying should preferably be carried out in exhaust ventilated booths removing vapors and spray droplets form the breathing zone.
- Page 14 INTRODUCTION Do organise work practices and protective clothing to avoid soling of the skin and eyes, breathing vapors / aerosols / dusts / fumes, inadequate container labelling; fire and explosion hazards. Do wash before job breaks, before eating, smoking, drinking or using toilet facilities when handling chemical materials. Do keep work areas clean, uncluttered and free of spills.
- Page 15 INTRODUCTION Dusts Powder, dusts or clouds may be irritant, harmful or toxic. Avoid breathing dusts from powdery chemical materials or those arising from dry abrasion operations. Wear respiratory protection if ventilation is inadequate. Electric shocks Electric shocks can result from the use of the faulty electrical equipment or from the misuse of equipment even in good condition.
- Page 16 INTRODUCTION Observe strict fire safety when storing and handling flammable materials or solvents, particularly near electrical equip- ment or welding processes. Ensure before using electrical or welding equipment but that there is no fire hazard present. Have suitable fire extinguisher available when using welding or heating equipment. First aid Apart from meeting any legal requirements its i desirable for someone in the workshop to be trained in first aid proce- dures.
- Page 17 INTRODUCTION Ensure there is adequate ventilation when handling and using gasoline. Great care must be taken to avoid the serious consequences of inhalation in the event of vapor build up arising from spillages in confined spaces. Special precautions apply to cleaning and maintenance operations on gasoline storage tanks. Gasoline should not be used as a cleaning agent.
- Page 18 INTRODUCTION Do not use damaged or defective tools or equipment, particularly high speed equipment such as grinding wheels. A damaged grinding wheel can disintegrate without warning and cause serious injury. Wear suitable eye protection when using grinding, chiselling or sand blasting equipment. Wear a suitable breathing mask when using sand blasting equipment, working with asbestos based materials or using spraying equipment.
- Page 19 INTRODUCTION Two pack Can also contain harmful and toxic unreacted resins and resin hardening agents. The manufacturers' instructions should be followed and the on resin based adhesives, isocyanate containing adhesives and foams should be con- sulted. Spraying should preferably be carried out in exhausted ventilated booths removing vapor and spray mists from the breathing zone.
- Page 20 INTRODUCTION Brief exposure to high concentrations of vapors or mists will cause eye and throat irritation, drowsiness, dizziness, headaches and in the worst circumstances, unconsciousness. Repeated or prolonged exposures to excessive but lower concentrations of vapors or mists, for which there might not be adequate warning indications, can cause more serious toxic or harmful effects.
- Page 21 INTRODUCTION particularly in cases where the general ventilation is poor, or where considerable welding work is anticipated. In extreme cases where adequate ventilation cannot be provided, supplied air respirators may be necessary. Gas welding Oxy-acetylene torches may be used for welding and cutting and special care must be taken to prevent leakage of these gases, with consequent risk of fire and explosion.
- Page 22 SERVICE MANUAL Engine TT35 2WD tractor , TT35 4WD tractor , TT40 2WD tractor , TT40 4WD tractor , TT45 2WD tractor , TT45 4WD tractor 47899736 29/09/2015...
- Page 23 Contents Engine - 10 [10.001] Engine and crankcase ............. . . 10.1 [10.102] Pan and covers .
- Page 24 Engine - 10 Engine and crankcase - 001 TT35 2WD tractor , TT35 4WD tractor , TT40 2WD tractor , TT40 4WD tractor , TT45 2WD tractor , TT45 4WD tractor 47899736 29/09/2015 10.1 [10.001] / 1...
-
Page 25: Table Of Contents
Contents Engine - 10 Engine and crankcase - 001 TECHNICAL DATA Engine General specification ............... 3 General specification . -
Page 26: General Specification
Engine - Engine and crankcase Engine - General specification TT35 / TT40 models Simpsons Make 4 stroke, diesel, naturally aspirated, direct injection, Type water cooled Power TT40 42 Hp (BS Au 141a:1971) 35 Hp(BS Au 141a : 971) TT35 Number of cylinders... -
Page 27: Torque
Engine dimension Height 770.00 mm (30.31 in) Length 730.00 mm (28.74 in) Width 500.00 mm (19.69 in) Engine - Torque TT35 / TT40 models Torque Description Thread size TT40 TT35 Cylinder head nuts and setscrews (non 10.8 kgf (23.8 lbf) 10.8 kgf (23.8 lbf) -
Page 28: Torque
Engine - Engine and crankcase Torque Description Thread size TT40 TT35 3.2 kgf (7.1 lbf) 3.2 kgf (7.1 lbf) Air cleaner bracket to shell nut M10 x 1.5 Starter motor mounting bolts M10 x 1.5 7.4 kgf (16.3 lbf) 7.4 kgf (16.3 lbf) Alternator mounting bracket nuts M10 x 1.25... -
Page 29: Sealing
Engine - Engine and crankcase Engine - Sealing Equivalent Operation description Loctite specification Anabond / other specfication Injector mounting stud Front lift hook retaining stud Water outlet body retaining stud Cylinder block stud fitment (cam side) Cylinder block stud fitment (Fuel Injection Pump (FIP) side) Fuel Injection Pump (FIP) mounting stud on timing case Loctite - 577 Anabond 340... -
Page 30: General Specification
The ring gaps quoted above are for a bore diameter of 91.480 mm (3.602 in) TT40 model and 88.930 mm (3.501 in) TT35 model. When checking ring gaps in a worn bore, 0.0800 mm (0.0031 in) should be added to these ring gaps for every 0.0030 mm (0.0001 in) increase in bore diameter. -
Page 31: General Specification
57.190 - 57.210 mm (2.252 - 2.252 in) Bearing running clearance 0.060 - 0.100 mm (0.002 - 0.004 in) Crankcase - General specification TT35 / TT40 models Crankshaft Main journal diameter (std) 69.8100 - 69.8300 mm (2.7480 - 2.7490 in) Main journal length - number 2 and 3 30.8500 - 31.0600 mm (1.2150 - 1.2230 in) -
Page 32: General Specification
Engine - Engine and crankcase Camshaft gear Number of teeth Gear bore diameter 50.7900 - 50.8300 mm (1.9996 - 2.0012 in) Clearance fit of gear on spigot 0.0000 - 0.0600 mm (0.0000 - 0.0024 in) Idler gear and hub Number of teeth Gear bore diameter 53.9800 - 54.0200 mm (2.1252 - 2.1268 in) Diameter of hub... - Page 33 Engine - Engine and crankcase Bore diameter for gudgeon pin 31.753 - 31.758 mm (1.250 - 1.250 in) Top ring groove width 3.000 mm (0.118 in) (Nominal width) - half keystone ring 2nd ring groove width 2.030 - 2.050 mm (0.080 - 0.081 in) 3rd ring groove width 4.030 - 4.050 mm (0.159 - 0.159 in) Piston rings...
- Page 34 Engine - Engine and crankcase NOTE: The ring gaps given above are for when checking in the unworn portion of the cylinder bore. GNIL14TR04883AB 47899736 29/09/2015 10.1 [10.001] / 11...
- Page 35 Engine - Engine and crankcase Connecting rod bearings Type Pre-finished steel backed aluminum tin (or) copper lead Inside diameter 57.190 - 57.210 mm (2.252 - 2.252 in) Bearing running clearance 0.060 - 0.100 mm (0.002 - 0.004 in) 0.250 mm (0.010 in), 0.510 mm (0.020 in), 0.760 mm Recommended sizes in service (0.030 in) Crankshaft...
- Page 36 Engine - Engine and crankcase Engine - Overview Number location (4710 model) NOTE: The engine number is stamped on the camshaft tunnel of the cylinder block. (Right-hand side of the en- gine). When requesting information regarding the engine. The number should be quoted. GNIL14TR04882AA Cylinder head assembly The cylinder head incorporates valves and springs, with the valve rocker arm shaft assembly bolted to the cylinder...
- Page 37 Engine - Engine and crankcase Pistons Pistons are constructed of an aluminium alloy. The combustion chamber being recessed in to the piston crowns. Each piston has two compression rings and one oil control ring, to reduce the friction and increase positive seating. All rings are located above the piston pin.
- Page 38 Engine - Engine and crankcase GNIL14TR04754FA Lubrication system Lubrication of the engine, figure 2 is maintained by a rotor type oil pump mounted in front of the engine block, below timing cover. The oil pump is driven by the crank gear and draws oil from the engine oil sump through strainer and delivers it by a pipe inside the crankcase through a drilling at the side of the cylinder, to the lubricating filter.
- Page 39 Engine - Engine and crankcase GNIL14TR04755GA Fuel system The diesel fuel system consists of fuel tank, fuel filters, fuel feed pump, injection pump, injector nozzles and inter connecting tubes and lines. The injection pump is located on left side of the engine, is pressure fed from fuel feed pump. Fuel flows from fuel tank to the fuel feed pump strainer, through feed pump and then through the fuel filters.
- Page 40 Engine - Engine and crankcase Fuel filters Engine is provided with two spin on type fuel filters. Primary and secondary, located below fuel injection pump. Fuel first passes primary filter and then through the secondary filter before entering injection pump. Primary filter is provided to separate the larger dirt particles whereas secondary is provided to separate the particles, which passed through the primary filter to the secondary filter.
