User's Manual
PX-700IV
THERMAL RECEIPT PRINTER
Ver. 1.00
http://www.nexapos.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PX-700IV and is the answer not in the manual?

Questions and answers

Summary of Contents for Nexa PX-700IV

  • Page 1 User’s Manual PX-700IV THERMAL RECEIPT PRINTER Ver. 1.00 http://www.nexapos.com...
  • Page 2 PX-700IV Introduction PX-700IV printers have been designed to be connected to various types of electronic devices such as POS (Point Of Sale) and PC's. ※ The main features of the printer are as follows  THERMAL RECEIPT PRINTER  Low-noise thermal transfer method printing ...
  • Page 3 PX-700IV Safety Information Warning: Warnings must be heeded carefully in order to prevent serious physical harm. Caution: Cautions must be heeded in order to prevent minor injuries, equipment damage, or data loss. Symbol Information DC (Direct current) Error, Warning Paper Feeding...
  • Page 4: Table Of Contents

    PX-700IV Table of Contents 1. Installing Printer and Getting Started .................5 1-1 Unpacking .........................5 1-2 Interface ..........................6 1-2-1 USB Interface......................6 1-2-2 Ethernet Interface....................7 1-2-3 Serial Interface ......................8 1-3 Drawer Port ........................9 1-4 Connecting Power Supply ....................10 1-5 Reconfiguration of Printer....................12 1-6 Installing &...
  • Page 5: Installing Printer And Getting Started

    PX-700IV 1. Installing Printer and Getting Started 1-1 Unpacking • Check the following contents list, and contact your dealer for assistance if any item is missing or incorrect. - Product PX-700IV - Standard Components Power Cord AC/DC Adaptor USB A-B Cable...
  • Page 6: Interface

    PX-700IV 1-2 Interface • Connect the printer to the host computer using the right interface cable that complies with the specifications of the interface 1-2-1 USB Interface PX-700IV USB Port Pin No. Signal Name Designation (Color) Function Shell Shield Drain Cable...
  • Page 7: Ethernet Interface

    PX-700IV 1-2-2 Ethernet Interface - PX-700IV Ethernet Port Pin No. Signal Name Designation (Color) Function WHITE ORANGE Transmit + ORANGE Transmit - WHITE GREEN Receive + BLUE WHITE BLUE GREEN Receive - WHITE BROWN BROWN * Refer to the Ethernet User’s Manual that is available from the BIXOLON website for more detailed information.
  • Page 8: Serial Interface

    PX-700IV 1-2-3 Serial Interface - PX-700IV Serial Port Pin No. Signal Name Direction Function OUTPUT Transmit Data INPUT Receive Data INPUT Data Set Ready OUTPUT Data Terminal Ready INPUT Clear To Send OUTPUT Ready To Send All cables must be connected while the product is turned off.
  • Page 9: Drawer Port

    PX-700IV 1-3 Drawer Port • Connect the cash drawer connection cable to the drawer kick-out connector on the rear side of the printer. - PX-700IV Drawer(DK) Port Pin No. Signal Name Direction Frame Ground Drawer Kick-out Drive Signal 1 Output...
  • Page 10: Connecting Power Supply

    1) Make sure the product is turned off before connecting the power supply. 2) Connect the power cable with the flat side pointing to the outside of the printer, as shown in the diagram below. - PX-700IV Power Connector Power Cable - 10 - Ver.
  • Page 11 - When connecting or disconnecting power, make sure to remove the power supply from the power outlet before removing. - Pay attention to the direction in which you insert the power cable. - PX-700IV Caution Do not connect a voltage out of the specifications of the power Warning supply.
  • Page 12: Reconfiguration Of Printer

    PX-700IV 1-5 Reconfiguration of Printer • This product does not support Dip Switch. In order to change the product’s configuration, use either the virtual memory switch utility or the virtual memory switch management function when performing a self-diagnosis. • Please refer to the Utility and Service Manual for more information.
  • Page 13: Installing & Replacing Paper

    PX-700IV Installing & Replacing Paper 1) Open the paper roll cover by raise the cover-open lever. Do not open the print cover while the printer is operating, Caution otherwise the printer may be damaged. - 13 - Ver. 1.00...
  • Page 14 PX-700IV 2) Remove the empty paper roll and replace with a new one as shown in the image. Check the orientation of the roll paper when inserting it into the printer. Caution - 14 - Ver. 1.00...
  • Page 15 PX-700IV 3) Pull out a small amount of paper as shown in the picture, and close the cover. When closing the cover, hold down the center of printer cover Caution firmly so that paper roll is loaded correctly. 4) Cut the paper as shown in the following picture.
  • Page 16: Recommended Papers

    PX-700IV 1-7 Recommended Papers - NR808024T - NEXA 80mm X 80mm Rolls - Supported Paper Thickness: 60μm - 75μm - Use of papers other than those recommended above may damage TPH or degrade the printing quality and our company Is not responsible for the damage caused by non-recommended Caution papers.
  • Page 17: Using Printer Functions

    PX-700IV 1-9 Using Printer Functions • Power (Button) - The POWER light is on whenever the printer is on. • Error (Indicator Lamp) - Red light will be on in various error conditions such as out of paper, cover open, etc.
  • Page 18: Self-Test

    PX-700IV 2. Self-Test • The self-test checks whether the printer has any problems. If the printer does not function properly, contact your dealer. The self-test procedure is as follows: 1) Make sure paper roll has been installed properly. 2) Turn on the power while holding down the FEED button and the self-test begins.
  • Page 19 PX-700IV • If “VMSM Selection” is selected (1) The following lines will be printed when the VMSM opens. ** VMSM Selection ** 0 : Exit and reboot printer 1 : Ethernet Information Setting 2 : Set Print Density 3 : None...
  • Page 20: Hexadecimal Dumping

    PX-700IV 3. Hexadecimal Dumping • This function allows experienced users to see exactly what data is coming to the printer. This can be useful in finding software problems. When you turn on the hexadecimal dump function, the printer prints all commands and data in hexadecimal format along with a guide section to help you find specific commands.
  • Page 21: Specifications

    PX-700IV 4. Specifications Printing Method Thermal printing 180 dpi (7dots/mm) Dot Density Printing Width 3 inches 72 mm Roll Width 3 inches 79.5±0.5 mm No. of Characters per Line 42 (Font A) ,56 (Font B), 56 (Font C) (Default Value) Printing Speed Max.
  • Page 22: Appendix

    PX-700IV 5. Appendix 5-1 Cleaning Printer • Paper dust inside the printer may lower the print quality. In this case clean the printer as follows: 1) Open the printer cover and remove the paper currently in use. 2) Residue or contamination of printer head should be wiped out by ethanol or IPA.
