340 Classic - Polaris 340 CLASSIC 2006 Manual

SPECIFICATIONS

340 CLASSIC

MODEL S06ND3AS
Table 1-1: Engine
Engine type
Engine displacement
Bore in/mm
Stroke in/mm
Piston to cylinder clearance in/
mm
Piston ring end gap
Operating RPM±200
Idle RPM±200
Clutch engagement RPM ±200
Table 1-2: Fuel Delivery
Type
Main Jet
Pilot Jet
Jet Needle/Clip position
Needle Jet
Throttle gap under cutaway
in/mm
Throttle slide cutaway
Valve seat
Starter jet
Pilot air jet
Fuel screw setting
Air screw setting
Recommended fuel octane
(R+M/2)
1.2
Fuji
339cc
2.45/62.3
2.19/55.6
.003-.005/.076-.127
.008-.014/.20-.35
7000
1600
4100
VM30SS
170
35
5DP13/3
O-6 (169)
.240/6.1
2.5AL
1.5Viton
1.5
2.5
N/A
1.5
87 NonOxy/89 Oxy Min
Table 1-3: Jetting
Altitude
meters
(feet)
0-600 185 180 170
(0-2000) #4 #3 #3
600-1200 175 170 160
(2000-4000) #3 #3 #3
1200-1800 165 160 155
(4000-6000) #3 #3 #3
1800-2400 155 150 140
(6000-8000) #3 #3 #3
2400-3000 145 140 130
(8000-10000) #3 #3 #2
3000-3700 135 130 120
(10000-12000) #3 #2 #2
Table 1-4: Clutching
Drive Clutch (P-85)
Altitude meters
Shift Clutch
(feet)
Weight Spring
0-900 Black-
10
(0-3000) 2287
900-1800 10-M Black-
(3000-6000) Blue 2287
1800-2700 Black-
10MW
(6000-9000) 2287
2700-3700 Black-
10MR
(9000-12000) 2287
Drive clutch bolt torque 50 ft-lbs(69Nm)
Table 1-5: Belt
Belt part number
Belt width in/cm
Belt side angle
Outside diameter in/cm
Clutch center distance in/cm
Table 1-6: Chaincase
Center distance in/cm
Reverse type
Ambient Temperature
170 165 160 155 150
#3 #3 #3 #3 #3
160 155 150 140 140
#3 #3 #3 #2 #2
150 145# 140 130 130
#3 3 #2 #2 #2
135 135 130 120 120
#3 #2 #2 #1 #1
130 125 120 110 110
#2 #2 #1 #1 #1
115 115 110 100 100
#2 #1 #1 #1 #1
Driven Clutch (TEAM)
Clutch Driven
Gearing
Spring Helix
Red/
S36ER 16:41-72
Black
Red/
S36ER 16:41-72
Black
Red/
S36ER 16:41-72
Black
Red/
S36ER 16:41-72
Black
3211078
1.438/3.65
28_
46.625/118.4
11.5/29.2
7.92/20.1
PERC
