INSTALLATION GUIDE
DS3+ / DS4+
HONDA7
Designed by Installers for Installers
© 2021 VOXX•DEI LLC.
This product is intended for installation by a professional installer only! Attempts to install this
product by a person other than a trained professional may result in severe damage to a vehicle's
electrical system and components.
2021-11-24

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Directechs DS3+ and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Voxx Directechs DS3+

Summary of Contents for Voxx Directechs DS3+

  • Page 1: Vehicle Application Guide

    HONDA7 Designed by Installers for Installers © 2021 VOXX•DEI LLC. This product is intended for installation by a professional installer only! Attempts to install this product by a person other than a trained professional may result in severe damage to a vehicle’s electrical system and components.

  • Page 2: Table Of Contents

    Contents Introduction ..................................... 3 Vehicle application guide ..............................4 Pre-installation and application warnings ..........................5 Wiring diagram....................................6 Module programming .................................. 12 Pairing Remotes ..................................15 8556T Temperature Sensor..............................15 8504D Combo Sensor ................................. 15 RF Systems ..................................... 15 When used in conjunction with Directed SmartStart ®...

  • Page 3: Introduction

    To configure via DirectLink DT (mobile app): 1. Follow and complete the wiring diagram(s) related to your installation through the app. 2. When installation is complete, select Configure DS4/DS4+. 3. Follow the on-screen instructions. DS4+ HONDA7 © 2021-1 1-24 VOXX•DEI LLC. All rights reserved.
  • Page 4 The following table lists the vehicles and features which are compatible with this product. The number assigned to each year allows you to determine which installation type should be used for your vehicle. DS4+ HONDA7 © 2021-1 1-24 VOXX•DEI LLC. All rights reserved.

  • Page 5: Pre-Installation And Application Warnings

    The installation of an aftermarket hood pin is ONLY required on vehicles that are NOT equipped with a factory hood pin or if NOT supported in data. The siren is ONLY required when enabling the security features during module flashing. The Green wire is OPTIONAL for starter disable and anti-grind applications. DS4+ HONDA7 © 2021-1 1-24 VOXX•DEI LLC. All rights reserved.

  • Page 6: Wiring Diagram

    (+) Siren Output: Brown/Red Position the fuses correctly! Siren 12-pin Black Connector 10-pin White Connector Slide to open Legend: Mandatory Connections Security Only Remote Start Only Remote Start + Security DS4+ HONDA7 © 2021-1 1-24 VOXX•DEI LLC. All rights reserved.
  • Page 7 (+) Accessory: Pin 4 (+) Accessory Output: Orange: 8 Pin 5 (+) Ignition Input/Output: Pink: 10 Slide to open Legend: Mandatory Connections Security Only Remote Start Only Remote Start + Security DS4+ HONDA7 © 2021-1 1-24 VOXX•DEI LLC. All rights reserved.
  • Page 8 (Data) HS CAN High 1 White (F-CAN) Data OBD-Data Link Connector (Data) Immo. Data Blue (S-NET) Data Immobilizer Control Unit on ignition switch Gray (-) Parking Light Output Gray Headlight switch. White DS4+ HONDA7 © 2021-1 1-24 VOXX•DEI LLC. All rights reserved.

  • Page 9: Module Programming

    * Your aftermarket remote may differ from the model shown in the illustrations. For information on how to pair a specific remote, please refer to its corresponding owner documentation, which can be found inside the product packaging of the complete system or on www.directechs.com. You have successfully completed the module programming sequence. DS4+ HONDA7 © 2021-1 1-24 VOXX•DEI LLC. All rights reserved.
  • Page 10 * Your aftermarket remote may differ from the model shown in the illustrations. For information on how to pair a specific remote, please refer to its corresponding owner documentation, which can be found inside the product packaging of the complete system or on www.directechs.com. You have successfully completed the module programming sequence. DS4+ HONDA7 © 2021-1 1-24 VOXX•DEI LLC. All rights reserved.
  • Page 11 * Your aftermarket remote may differ from the model shown in the illustrations. For information on how to pair a specific remote, please refer to its corresponding owner documentation, which can be found inside the product packaging of the complete system or on www.directechs.com. You have successfully completed the module programming sequence. DS4+ HONDA7 © 2021-1 1-24 VOXX•DEI LLC. All rights reserved.

  • Page 12: Pairing Remotes

    System allows the vehicle owner to control the system with enhanced range. Two-way models are available. Please follow the instructions included with the kit for appropriate installation and programming information. DS4+ HONDA7 © 2021-1 1-24 VOXX•DEI LLC. All rights reserved.

  • Page 13: When Used In Conjunction With Directed Smartstart

    The white D2D1 port is reserved ONLY for SmartStart, Module flashing or 3rd Party bypass. The two black D2D2 ports are reserved for the Control Center (antenna) and digital sensors (8504D). DS4+ HONDA7 © 2021-1 1-24 VOXX•DEI LLC. All rights reserved.

  • Page 14: Manual Transmission

    Must be connected to a working tachometer signal in the vehicle (fuel injector, ignition coil, true tach, etc.) and (Violet/White, pin 22) learned successfully to the DS4+. See Tech Tips 10001 - https://directechs.blob.core.windows.net/techtips/10001.pdf DS4+ HONDA7 © 2021-1 1-24 VOXX•DEI LLC. All rights reserved.

  • Page 15: Led Diagnostics And Troubleshooting

    The module has initialized the remote start sequence. received. Flashes green Ignition ON command received. The module has received the Ignition ON command and is processing the remote start sequence. Flashes red & orange DS4+ HONDA7 © 2021-1 1-24 VOXX•DEI LLC. All rights reserved.
  • Page 16 The vehicle was detected as moving, which prevents the system from shutting it down. Flashes red x 4 Analog error codes Description Troubleshooting DEI feature error. A feature config file mismatch was detected. Please contact Technical Support. Flashes red, green & orange DS4+ HONDA7 © 2021-1 1-24 VOXX•DEI LLC. All rights reserved.

  • Page 17: Soft Reset

    After 3 seconds the LED turns ON solid orange. Keep holding the programming button until the & & LED flashes red, then orange slowly. Solid Hold Flashes Release the programming button. The LED turns ON solid red. & Release Solid DS4+ HONDA7 © 2021-1 1-24 VOXX•DEI LLC. All rights reserved.

  • Page 18: Tach Learning Procedure (Not Needed With Virtual Tach)

    Therefore, there is no Over-Rev protection. If the vehicle attempts to remote start, but is unsuccessful, the remote start will keep the ignition on for the entire runtime period. DS4+ HONDA7 © 2021-1 1-24 VOXX•DEI LLC. All rights reserved.

  • Page 19: Limited Lifetime Consumer Warranty

    Limited Lifetime Consumer Warranty VOXX DEI LLC (the Company) warrants to the original purchaser of this product that should this product or any part thereof, under normal use and conditions, be proven defective in material or workmanship within the Lifetime from the date of original purchase in the original vehicle, such defect(s) will be repaired or replaced with new or reconditioned product, (at the Company’s option)

  • Page 20: Quick Reference Guide

    * Icon and remote appearance may differ depending on the model purchased. SmartStart compatible This system is compatible with Directed SmartStart. For a complete list of supported features, please visit www.mysmartstart.com. DS4+ HONDA7 © 2021-1 1-24 VOXX•DEI LLC. All rights reserved.
  • Page 21 The application enables a “Cloud-Connected Car” like never before, providing 2-way interaction with your vehicle. Connectivity is managed through the Directed Cloud Services (DCS) network linking car, app, end user, and the Internet. For more information, visit www.mysmartstart.com. Notes DS4+ HONDA7 © 2021-1 1-24 VOXX•DEI LLC. All rights reserved.
