Warning
The marking labels must be visible to the operator and shall not
be removed from the instrument or made unreadable in any way.
Warning
EyeFoss is equipped with a earthed type power plug for your
protection against electric shock hazard and must be attached to
a properly grounded/earthed power outlet by using a power
cable (100-240 V AC) with protective earthing.
Warning
The instrument weighs 50 kg and must be lifted by at least two
persons, using the handles in instrument bottom or a lifting
device.
Warning
The cooling flange can reach a very high temperature. (This label
is placed on the cooling flange).
Warning
Risk of getting jammed when cleaning the conveyor belt.
Warning
Risk of getting jammed when cleaning the bottom of the feeder.
1.2.2

Laser

The EyeFoss is a Class I laser product and contains a laser. The laser is totally
shielded by the cabinet, and there is no risk of laser radiation during normal use.
The embedded laser is a Class 3B laser with the specifications:
• Max output of laser: 25 mW
• Led wavelength: 658 nm
Warning
Use of controls or adjustments or performance of procedures
other than those specified in this manual may result in hazardous
radiation exposure. There are no adjustment procedures for the
laser that are to be performed by the operator; all adjustments
are to be carried out by a qualified service engineer.
Warning
Make sure that there is no gap between the protection cap and
the metal sheet by securing the screw as the laser reflection can
be hazardous to the operator.
Warning
Avoid exposure to beam. The class 3b laser product is embedded
in the product. The camera unit cover must be mounted when the
instrument is switched on.
