- Page 1 Wireless relay (PLC) ARNAVI PLC User Manual Arusnavi LLC...
-
Page 2: Table Of Contents
Contest General information..........................3 Technical specifications......................4 Principle of operation and appearance of thedevice..............5 Connecting guidelines ..........................6 Warranty……………………………..................... 8 Package contents ............................ 9 User Manual [1.0] Page 2... -
Page 3: General Information
General information ARNAVI PLC is a set of interlocking wireless relay and control module. The kit is designed for the equipment of any security systems on all types of vehicles, additional locking circuit controlled by standard wiring, powered by the on-board network rated voltage +12V and grounded negative output of the battery. -
Page 4: Technical Specifications
1. Technical specifications Please see table 1 for main specifications 64 x 23.5 x 15 Dimensions of blocking relay, mm (excluding harness) Dimensions of control module, mm 32 x 27.5 x 4 Weight of blocking relay, gram Weight of control module, gram Voltage, V 7 - 15 ≤5... -
Page 5: Principle Of Operation And Appearance Of Thedevice
The signal is transmitted through the regular wiring of the car. Physical removal (disconnection) of the control module from the circuit will cause the blocking relay to lock mode (within 30 seconds). The appearance of ARNAVI PLC devices is shown in pictures 1 and 2. Picture 1. Blocking relay Picture 2. -
Page 6: Connecting Guidelines
Connecting guidelines CONNECTING THE CONTROL MODULE The control module is installed on the board of navigation tracker Arnavi Integral 3 by point soldering to the main connector of the tracker as shown in picture 3. Picture 3. Navigation tracker Arnavi Integral 3 with the installed control module Connection of the control module to other trackers is carried out as follows: VCC point: +12V DC with battery. - Page 7 It is possible to block any electrical circuit whose characteristics do not exceed the values specified in table 1. The connection diagram of the Arnavi PLC wireless relay kit is shown in picture 4. Picture 4. Arnavi PLC connection diagram User Manual [1.0]...
-
Page 8: Warranty
Warranty The equipment is designed for long-term operation in Autonomous maintenance-free mode. The warranty period for the equipment is 5 years and is counted from the date of initial installation, provided it is carried out by the installer authorized by the manufacturer of the equipment. The date of initial installation and information about the installer must be specified in the warranty card and stamped by the installer. -
Page 9: Package Contents
Package contents The package set of PLC relay is presented in the table 2. Table 2 – package set № Title Quantity Notes Control module Blocking relay For further information please see the website www.arusnavi.com User Manual [1.0] Page 9...
