DIGIFRAME BUSINESS LINE 158 8GB
MANUAL
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BUSINESS LINE 158 8GB and is the answer not in the manual?

Questions and answers

Summary of Contents for Braun BUSINESS LINE 158 8GB

  • Page 1 DIGIFRAME BUSINESS LINE 158 8GB MANUAL...
  • Page 2: Table Of Contents

    VERVIEW IMPORTANT SAFETY INSTRUCTIONS........7 GETTING STARTED ..............8 ..........8 ONNECTING TO OWER DPF ........... 8 TART UP THE USING THE BRAUN DIGITAL PHOTO FRAME ......9 ............9 ..........9 ELECT NPUT OURCE ........10 IEW A HOTO LIDESHOW ..............
  • Page 3: Introduction

    Introduction Thank you for selecting this BRAUN Digital Photo Frame. Displaying your favorite picture is easy and fun. Features • 15.6" TFT LED full view panel with 1920 * 1080 pixels resolution, 16:9 aspect ratio. • Supports most photo formats: JPG, JPEG, BMP, PNG and more.
  • Page 4: Product Overview

    Product Overview 1.3.1 Function Buttons at Right Side 1 Exit 2 Volume Up/Right 3 Volume Down/Left 4 Next File/Down 5 Previous File/Up 6 Enter/Play/Pause 7 Power On/Off 1.3.2 Interface at Right Side 1 DC Port 2 Power Switch 3 3.5mm Earphone Jack 4 USB Port 5 SD/MMC/SDHC Memory Card Slot 6 HDMI Port...
  • Page 5 Icon Description Power On / Off Mute HDMI/DMP Input Source CALENDAR Calendar/Sub Title PHOTO Photo Play Mode MUSIC Music Play Mode MOVIE Video Play Mode Down Left Right ENTER Enter VOL + Volume Up VOL - Volume Down Fast Forward Fast Backward Play Previous File Play Next File...
  • Page 6 Replacing the remote control battery 1. On the back of the remote control, pull out the battery holder. 2. Insert the new battery into the holder. The battery must be placed with the positive charge facing upwards, as shown in the illustration below. Positive charge faces upwards 3.
  • Page 7: Important Safety Instructions

    Important Safety Instructions Always follow these basic safety precautions when using your Digital Photo Frame (DPF). This will reduce the risk of fire, electric shock and injury. Caution: To reduce the risk of fire or shock hazard, do not expose this product to rain or moisture.
  • Page 8: Getting Started

    Getting Started Connecting to Power 1. Insert and gently push up the back stand. 2. Remove the protecting film on the panel. 3. Place the DPF on a flat surface. 4. Press plug the AC power adapter into the photo frames DC power jack and an electrical wall outlet.
  • Page 9: Using The Braun Digital Photo Frame

    Using the BRAUN Digital Photo Frame Main Menu Press the EXIT button three times to the main menu page. Use the button and the button to select the function or press the function button on the remote control. Select Input Source There are three input sources: Internal memory (8 GB) or SD (SDHC/MMC) memory card (up to 32 GB) or USB memory stick (up to 32 GB).
  • Page 10: View A Photo/Slideshow

    View a Photo/Slideshow Select Photo function from the main menu, press the ENTER button and choose the input source, press the button and the button to select an individual photo by press the ENTER button. Wait for a while, your favorite slideshow will start automatically.
  • Page 11: Music

    Music Select Music function from the main menu, press the ENTER button and choose the input source, press the button and the button to select an individual audio files by press the ENTER button. Press the CALENDAR button to show/hide the sub title menu. Use the button to Play/Pause.
  • Page 12: Movie

    Movie Select Music function from the main menu, press the ENTER button and choose the input source, press the button and the button to select an individual audio files by press the ENTER button. Press the CALENDAR button to show/hide the sub title menu. Use the button to Play/Pause.
  • Page 13: Calendar

    Calendar Press the CALENDAR button on the remote control to see a full-screen month-by-month calendar and clock display. If there are pictures under the current folder, pictures will display automatically. Tips: Adjust photo transition interval via Setup > Transition Interval. As Extended Display The DPF can be used as an extended display.
  • Page 14: Adjusting The Settings

    Adjusting the Settings Using the control buttons Press the button to move up to previous menu. Press the button to move up to next menu. Press the button for previous option. Press the button for next option. Press the EXIT button to exit. Overview Menu Options...
  • Page 15: Copy Files To Internal Memory

    Copy Files to Internal Memory Add a file named “copy.txt” to the USB memory stick. File name must be lowercase. Files under the USB memory stick will be automatically copied to the built-in memory when the USB memory stick is inserted into DPF. IMPORTANT: 1.
  • Page 16: Scroll Subtitle

    Scroll Subtitle Create a file named SCROLL.TXT with the scroll subtitle. Select Unicode as the encoding format and save it. Please refer to below picture. The file name SCROLL.TXT must be uppercase and the file need put under the root directory of USB memory stick or the SD (SDHC/MMC) memory card. Scroll subtitle will appear when you play video.
  • Page 17: Frequently Asked Questions (Faq)

    Frequently Asked Questions (FAQ) Why no photo is displayed in my calendar? There is no photo under the current folder. Use Photo function to check and select folder with photo file as current folder. Then select Calendar function again. I have a memory card in the Digital Photo Frame, but it’s not reading the card.
  • Page 18: Customer Support

    Output power DC12V 2A Customer Support Many questions regarding the operation of your BRAUN product can be answered by reading the instruction manual packaged with this product. If this product is deemed to be defective and is under warranty, you may...
