- Page 1 VRILU90...
- Page 3 Guide to the Appliance Caring for the Environment Safety Information and Warnings Installation Instructions Operation Instructions Troubleshooting Care and Maintenance Specifications...
- Page 4 1. Filters 2. LED Lights 3. 3 speed touch control – low, medium, high 4. Lights on/off button 5. Hood 6. Separate fan motor 7. Power supply...
- Page 5 The packaging of your appliance has been selected from environmentally friendly materials and can usually be recycled. Please ensure these are disposed of correctly. Plastic wrapping can be a suffocation hazard for babies and young children, please ensure all packaging materials are out of reach and are safely disposed of.
- Page 6 • Please ensure this manual is read carefully before installation and use. Keep this manual in a safe and accessible location should future reference be required. • The appliance has been designed as an exhausting version (external exhaust) or as a filter version (inter air recycle) cooker hood. •...
- Page 7 • The exhaust air must not be discharged into a flue which is used for exhausting fumes from other appliances burning gas or other fuels. (Not applicable for appliances which only discharge air back into the room) • For optimal performance, the minimum distance from the top of the cooking surface to the underside of the range hood should be 65-75cm.
- Page 8 1. The main body and the external motor are connected by an extended cable. A separate cable is plugged into the power. 2. The extension ducting will connect the main body and external motor, and cooking residues will be extracted and discharged to outside via a ducting kit.
- Page 9 The Rangehood should be placed at 65-75cm from the cooking surface for the best effect. See Pic 1 6 5c m 1. Cut the required size hole in the underside 7 5c m of the cabinet for the hood body 2.
- Page 10 4. Install the 150mm outlet by (ST4*8mm) screws, and attach the extension ducting pipe. 5. Connect the power cord on main body with extend wiring 6. Fix the left and right support bracket on the side of external motor, by using 6 pcs (ST4*8mm) screws 7.
- Page 11 1. The location of the fan unit shall allow access for maintenance and repair. Permanent fixed means of access is required where the fan unit location is beyond the extent of normal steps or ladders. 2. Before installation, please ensure the area is clean to avoid suction of the remaining bits of debris and dust.
- Page 12 A. Push the 1 icon switch the unit will run at low speed. Push the 2 icon switch the unit will run at medium speed. C. Push the 3 icon switch the unit will run at high speed. D. Push the light button and the two lights will come on. Push it again and the lights will turn off.
- Page 13 Light on, but motor Service call to clear The fan blocked does not work the blockage The capacitor Service call to replace damaged capacitor The motor jammed Service call to replace bearing damaged motor A electrical or burning Service call to replace smell from the motor motor Light does not work,...
- Page 14 Please ensure this rangehood is turned off at the power point before any care and maintenance is carried out. • It is recommended to commence the operation of the appliance prior to cooking. • It is recommended to leave the appliance in operation for 15 minutes after cooking is terminated in order to eliminate cooking vapours and odours.
- Page 15 Changing and cleaning the anti-grease filters • Remove the filters as per shown below. • You can clean the filter using the following methods. Soak them for about 3 minutes in hot water (40-50 degrees) with a grease-loosening detergent then brush it gently with a soft brush.
- Page 16 Undercupboard rangehood 90cm 220-240V/50Hz Stainless steel finish 271W 3 speed touch control 150mm ducting spigot LED lights – 2 x 2W 3 x grease filters 254mm H x 900mm W 1000m x 296mm D Off-board ducted installation 256mm H x 320mm W x 260mm D Aluminium flexi-duct: 3 metres Extension electrical power cable:...
-
Page 17: Manufacturer Guarantee
Subject to the exclusions below, we warrant that the product will not have any electrical or mechanical breakdowns within: a) In the case of Viali products used for personal, domestic or household purposes, a period of 2 years from the date the product is purchased as a brand-new product from a retailer located in Australia / New Zealand. - Page 18 c) The repair relates to the replacement of consumable parts such as fuses and bulbs or any other parts of the product which require routine replacement; d) You are unable to provide us with reasonable proof of purchase for the product; e) the breakdown occurs after the expiry of the express warranty period set out in section 1 or f) the product was not purchased in Australia / New Zealand as a brand-new product.
- Page 19 5. Warranty claims If you make a valid claim under this warranty and none of the exclusions set out in section 2 apply, we will, at our election, either repair the product or replace the product with a product of identical specification (or where the product is superseded or no longer in stock, with a product of as close a specification as possible).
- Page 20 READ THE INSTRUCTION BOOKLET BEFORE INSTALLING AND USING THE APPLIANCE. The manufacturer will not be responsible for any damage to property or to persons caused by incorrect installation or improper use of the appliance. The manufacturer is not responsible for any inaccuracies, due to printing or transcription errors, contained in this manual.
