Apollo AAN-4 Hardware Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
AAN-4 Hardware
Manual
Revision Date: 19 OCT 2011
This manual contains confidential information and
may only be reproduced or distributed with the
written consent of Apollo Security Sales, Inc.
© 2011 Apollo Security Inc.

Advertisement

Table of Contents
loading

Related Manuals for Apollo AAN-4

Summary of Contents for Apollo AAN-4

  • Page 1 AAN-4 Hardware Manual Revision Date: 19 OCT 2011 This manual contains confidential information and may only be reproduced or distributed with the written consent of Apollo Security Sales, Inc. © 2011 Apollo Security Inc.
  • Page 2 Apollo Security, Inc. While every precaution has been taken in the preparation of this document, Apollo Security assumes no responsibility for errors or omissions, or for damages resulting from the use of information contained in this document or from the use of programs and source code that may accompany it.
  • Page 3 IMPORTANT INFORMATION W A R N I N G HIGH VOLTAGE, AC MAIN POWER SHOULD ONLY BE CONNECTED BY QUALIFIED, LICENSED ELECTRICIANS. ALL APPLICABLE LAWS AND CODES MUST BE FOLLOWED. IF THIS PRECAUTION IS NOT OBSERVED, PERSONAL INJURY OR DEATH COULD OCCUR Power should not be applied to the system until after the installation has been completed.

  • Page 4: Table Of Contents

    3 Host Communication Connection ........................... 18 Serial ................................. Network ................................. ENI-100 ..............................Introduction ............................Hardware Layout ............................Connectors ............................21 TTL Serial Connector ............................21 RJ-45 Jack ............................21 Communication Configuration ............................4 Card Reader Wiring ........................... 24 © 2011 Apollo Security Inc.
  • Page 5 ........................... 49 2 Reader / Keypad ........................... 49 3 Input Zones ........................... 49 4 Output relays ........................... 49 Part VI Specifications Part VII Supplemental Figures Part VIII Table of Figures Part IX Revision History Index © 2011 Apollo Security Inc.

  • Page 6: Part I Introduction

    Part Introduction...

  • Page 7: Overview

    Any card reader with standard Wiegand or mag stripe output can be connected to the AAN-4. Provided for each of the four readers are exit push button, door contact and other general purpose inputs as well as are on-board strike relays and additional general purpose relay outputs.

  • Page 8: Programming Host

    AAN-4. Once programmed, the AAN-4 will continue to function without connection to the host. A record of all actions that happen while there is no connection is stored in the memory of the AAN (limited by the capacity of the memory) for reporting at a later time when connection with the host has been re-established.
  • Page 9 Figure 1.3 Programming Host Logical Diagram. Typical System Layout with RS-485 Connections. Several AAN-4 panels can be connected to one host on an RS-485 line using different device addresses. Field devices on the same line must also have unique addresses.
  • Page 10 Part Hardware Layout...

  • Page 11: Part Ii Hardware Layout

    ENI-100 Network Interface module. Terminal Connectors The AAN-4 has 9 terminal blocks for connecting power, reader and alarm inputs, and relay output connections. The connection terminals are factory equipped with removable screw-down quick connectors which are easily removed from the board by firmly grasping the connector and pulling away from the board.
  • Page 12 AUXR Reader 2 Auxiliary Input (Normally Closed) Auxiliary Input Exit Push Button Return EPBR Reader 2 Exit Push Button (Normally Open) Exit Push Button Door Contact Return Reader 2 Door Contact (Normally Closed) Door Contact © 2011 Apollo Security Inc.
  • Page 13 EPBR Reader 4 Exit Push Button (Normally Open) Exit Push Button Door Contact Return Reader 4 Door Contact (Normally Closed) Door Contact Relay Output Connections Common Normally Open Door 1 Strike Relay Connection Normally Closed © 2011 Apollo Security Inc.
  • Page 14 STRK ADA-10/11 External Relay Loop 20 mA loop Signal Return RET Receive Data (+) Receive Data (-) Host Communication Connection Transmit Data (+) (Serial Mode) Transmit Data (-) Signal Ground Table 2.1: AAN-4 Terminal Connections. © 2011 Apollo Security Inc.

  • Page 15: Dip Switches

    Hardware Layout DIP Switches The AAN-4 has one block of DIP switches, with 8 switches. These switches are used to set various configuration options for the interface. It is recommended to power the board down before making any changes in the DIP switch settings as any changes will not take effect unless the power is cycled.

  • Page 16: Dip Switch Function

    This setting must be specified in the host software in able to identify the device. A maximum of 16 AAN-4 devices can be installed on one communication line (RS-485), with each having a unique address (between 0-31). The communications address must also be specified in the host software when the AAN-4 is connected though a network.

  • Page 17: Device Port Communication Driver Socket

    Module Installation - The desired module should be installed so the long end extends towards the middle of the board and the mounting holes provided on the AAN-4 and ASM or ENI align so a plastic stand-off and screws can be attached to connect the holes. METAL SCREWS AND STANDOFFS SHOULD NOT BE USED TO MOUNT THE ASM/ENI.

  • Page 18: Normal Operation

    LED blinks many times a second or lighted solid, depending on the amount of activity. Firmware The operating program for the AAN-4 is stored in re-programmable flash memory. In the event that the firmware must be re-installed or updated, no chips need to be replaced on the panel. The new program can be loaded from the host via special software.

  • Page 19: Additional Installation Information

    Hardware Layout Additional Installation Information 2.7.1 Mounting Holes Four holes are provided for mounting the AAN-4. Standoffs should be used when mounting in order to protect the underside of the circuit board. © 2011 Apollo Security Inc.
  • Page 20 AAN-4 Hardware Manual Figure 2.7.1 AAN-4 Mounting Holes. Location of mounting holes for the AAN-4 is shown in scale. Note that the drawing will not print the exact size of the actual circuit board. © 2011 Apollo Security Inc.
  • Page 21 Part System Wiring...

  • Page 22: Part Iii System Wiring

    Power Connection: TB7 Power is supplied to the AAN-4 by the voltage connection in terminal block 7 (see Part 2.1 for exact locations of terminals). The power connection should be 12-24 VDC. Power consumption is 250 mA. The AAN-4 is protected from over-current and over-voltage by on-board circuitry.

  • Page 23: Safety (Earth) Ground

    5. Connect the new unit to the RS-485 line only if no ground fault is found. Host Communication Connection The connection from the AAN-4 to the programming host (PC) is used for programming the panel and then monitoring the status of the system. Once a connection is established, the host software communicates with the panel and transmits the necessary configuration information.

  • Page 24: Serial

    Typically, the communication will be from a standard 16550 UART COM-port on a PC which will be connected directly to the AAN-4 in the case of RS-232 or through the use of an adapter or add-on PC card to achieve the RS-485 signal. The communications wiring must cross-over from the PC to the panel as shown in Figure 3.3.1.

  • Page 25: Network

    3.3.2 Network For connection from the host to the AAN-4, an ENI-100 Network Interface Module is used. The ENI-100 acts as a standard Ethernet network device and occupies one IP address (see Part 4 for programming instructions). The connection from the ENI to the network is made by a standard RJ-45 jack. A standard UTP network cable should be connected from the ENI-100 to the local network via a network switch, hub or other network connection device.

  • Page 26: Eni-100

    The ENI-100 Network Interface Module provides connectivity between the AAN-4 and programming host via TCP/IP interface at 100Mbps. The ENI-100 converts the output signal from the AAN-4 to TCP/IP packets and converts incoming packets, received from the host, into the proper signal.

  • Page 27: 3.3.2.1.3 Communication Configuration

    Do not preface the address with “www”. You should see the following screen where the username and password must be entered. The default username/password is blank, thus if it was not previously modified, simply click on “ENI Configuration”. © 2011 Apollo Security Inc.
  • Page 28 "Program" button to save the settings. Clicking "Reset" will change all parameters on the page to their previous values. ENI-100 Parameters: AAN-4 Standard Settings - The italicized settings below will need to be set for standard configuration for use with the AAN-4. Other settings may be necessary or desired, according to your configuration: IP Address: IP address of the ENI-100.

  • Page 29: Card Reader Wiring

    24 AWG shielded cable with 4 twisted pairs (Belden 9504 or equivalent). Do not exceed 500 feet (152 m) between the AAN-4 and reader. Connect the shield drain wire of the cable at the GND terminal of the appropriate reader connector on the AAN-4. Carefully insulate the drain wire with sleeving for a reliable installation.
  • Page 30 AAN-4 power input. There must be sufficient power to supply the load of all readers as well as for the AAN-4 itself (+12 to +24VDC @ 250 mA). If the readers have a greater total power requirement, or if there are other wiring concerns, external power supplies should be used to power the readers.

  • Page 31: Reader Input Wiring

    Reader Input Wiring The each of the four reader inputs on the AAN-4 has three input circuits (Door Contact, Exit Push Button and Auxiliary Alarm 1). These inputs can be configured as UL Grade “B” (unsupervised) or UL Grade “A”...

  • Page 32: Door Contact Input (Door Position Switch)

    AAN-4 Hardware Manual Figure 3.6 Input Supervision. The AAN-4 reader inputs can be configured for Supervised or Unsupervised. End of line resistors must be used in the supervised configuration in order for the circuits to report the correct state. 3.5.2...

  • Page 33: Exit Pushbutton Input (Request To Exit, Rex)

    Terminal Connectors: AUX, AUXR (See Table 2.1 ) Each reader input on the AAN-4 includes one Auxiliary Alarm circuit. These inputs may be used for many purposes that can be configured in the host software. The capabilities will depend on the particular software system in use.

  • Page 34: Strike Wiring, General

    A typical electric door lock (strike) will require approximately 250 mA. (.250 amps) to control. The relay contacts on all Apollo relays are capable of switching up to 24 volts DC at up to 2 amps. If the particular locking device requires more that 2 amps to control, a separate, external relay capable of switching the required amount of current must be installed.

  • Page 35: Strike Wiring, Internal Relay

    Strike Wiring, Internal Relay The AAN-4 Reader Interface includes internal relays for door strike control for each of the four reader inputs. This relay is capable of switching up to 24 volts at up to 2 amps. If the lock installed on the door requires more than 2 amps to control, an external relay must be provided.
  • Page 36 Common "C" Strike Normally Closed "NC" Figure 3.7.3.2 Strike Wiring Diagram - Fail Safe. A wiring example for Fail Safe wiring. Refer to Table 2.1 for exact locations of strike relay connections for the AAN-4. © 2011 Apollo Security Inc.

  • Page 37: Ada External High Security Relays

    Strike Wiring, External ADA-10/11, High Security Relay Use of the internal relays provided on the AAN-4 reader provides a possible security breach as described above. To prevent the possibility of illegally releasing the door by smashing open the reader and bypassing the internal relay, external, high security relays may be installed.

  • Page 38: Additional Output Relay Wiring

    Additional Output Relay Wiring Each reader input of the AAN-4 has the capability of controlling 3 output relays in addition to the strike relay. There are a total of five output relays available. The internal strike relay, an external strike relay, and the three extra output relays.

  • Page 39: Ada Dip Switches/Jumpers

    The above functions will work the same for each reader. Thus, if reader 2 is selected (S4=ON S3=OFF), and the function Strike Relay is selected (S2=OFF, S1=OFF), the ADA will function as the strike relay for Reader 2. © 2011 Apollo Security Inc.
  • Page 40 The above functions will work the same for each reader. Thus, if reader 2 is selected (1=CUT, 2=NOT, 3=CUT, 4=CUT), and the function Strike Relay is selected (G1=NOT, G2=NOT), the ADA will function as the strike relay for Reader 2. © 2011 Apollo Security Inc.

  • Page 41: General Alarm Inputs

    Cabinet Tamper Input: TB19 This input is for connection to a switch located on the cabinet in which the AAN-4 is installed to detect unauthorized access to the panel. This is a normally-closed contact. In the event of a tamper condition, the exit push buttons will not function on all 4 reader connections.
  • Page 42 Part Software Configuration Utilities...

  • Page 43: Part Iv Software Configuration Utilities

    Technical Support section of the Apollo Security website. Apollo's website can be found at http://www.apollo-security.com For further questions regarding obtaining these utilities, contact your Apollo support representative. ENI-100 IP Programming The ENI-100 occupies one IP address in order to connect to the network and to the programming host.

  • Page 44: Initaan

    InitAAN NOTE: In order to use the InitAAN utility for programming the ENI, ensure that you have the latest version which is available on Apollo's website at http://www.apollo-security.com. Older versions of InitAAN may not support programming the device. 1. Run the INITAAN.EXE program. A dialog box will display instructions for programming various devices.
  • Page 45 Software Configuration Utilities © 2011 Apollo Security Inc.
  • Page 46 ENI and other programs to allow programming. If one or more parts of the network does not allow broadcasting it may not be possible to configure devices using InitAAN. © 2011 Apollo Security Inc.

  • Page 47: Web Page

    <enter> to display the login screen (see the Defaults section for default address for all devices): The default user name and password are blank, so unless a username/password was previously specified, simply click on "ENI Configuration" to proceed to the main configuration screen. © 2011 Apollo Security Inc.
  • Page 48 NOTE It is highly recommended that the default user name/password should be changed on first use to secure the device from unauthorized use! © 2011 Apollo Security Inc.
  • Page 49 ENI will use the new settings. Note that if the IP address was changed it will be necessary to enter the new address in the browser address bar in order to access the web page configuration again. © 2011 Apollo Security Inc.

  • Page 50: Telnet

    5 seconds of opening the telnet session or the connection will be closed. Passwords are case-sensitive!! Upon successful connection to the ENI, the current configuration will be displayed: ENI-100/110 MAC address 00204A92AB82 Software version V1.02 (070416) CPK6101_XPTEX AES Encryption Password :- Press Enter for Setup Mode © 2011 Apollo Security Inc.
  • Page 51 Disable TFTP Firmware Update (N) ? - Enable/Disable firmware update by TFTP Disable Port 77FEh (N) ? Enable/Disable detection port for the configuration software. If disabled, the software will not be able to auto-detect the device. © 2011 Apollo Security Inc.
  • Page 52 NOTE: If Telnet Setup, Web Server/Setup and Port 77FEh are all disabled, remote configuration will be completely disabled and no changes can be made to the device settings!! Configuration will only be able to be changed by resetting the device. © 2011 Apollo Security Inc.

  • Page 53: Part V Troubleshooting

    Part Troubleshooting...

  • Page 54: Communications

    The reader function can be verified after communications are functioning properly. The host system must be configured for each of the readers on the AAN-4 to be used, and with the correct card format. The card format is determined by the actual cards that will be used. After configuring the card format at the host, placing a card in front of the reader should generate an access message on the host computer.

  • Page 55: Part Vi Specifications

    Part Specifications...
  • Page 56 Power Requirements: +12 to +24Vdc @ 250mA Dimensions: 7.5 in x 5.5 in (19 x 14 cm) Environment: Operating Temperature: -0 to 50° C Storage Temperature: -40 to 85° C Relative Humidity: 0 to 95%, non-condensing © 2011 Apollo Security Inc.
  • Page 57 Part Supplemental Figures...

  • Page 58: Part Vii Supplemental Figures

    AAN-4 Hardware Manual Supplemental Figures © 2011 Apollo Security Inc.
  • Page 59 Supplemental Figures © 2011 Apollo Security Inc.
  • Page 60 AAN-4 Hardware Manual © 2011 Apollo Security Inc.
  • Page 61 Supplemental Figures © 2011 Apollo Security Inc.
  • Page 62 AAN-4 Hardware Manual © 2011 Apollo Security Inc.
  • Page 63 Supplemental Figures © 2011 Apollo Security Inc.
  • Page 64 AAN-4 Hardware Manual © 2011 Apollo Security Inc.

  • Page 65: Part Viii Table Of Figures

    Part VIII Table of Figures...
  • Page 66 Description Page AAN-4 Diagram 3.3.1 Host to AAN-4 wiring (RS-232) 3.2.6.1 ENI-100 Hardware Layout AAN-4 Card Reader & Input Wiring Input Supervision 3.7.3.1 Strike Wiring - Fail Secure 3.7.3.2 Strike Wiring - Fail Safe 3.7.3 ADA-11 Loop and Strike Wiring 3.7.4...
  • Page 67 Part Revision History...

  • Page 68: Part Ix Revision History

    Update ADA11 switch settings; Add R. Burnside mounting holes diagram A.2.1 19 OCT 2011 Update ADA-10 jumper settings. C. Gray Remove host limiting feature for ENI. Higher resolution supplemental figures. Correct 9-pin pinout for serial wiring diagram. © 2011 Apollo Security Inc.

  • Page 69: Index

    - F - - S - Firmware Self Test - G - Specifications Start Up Mode Gateway Supervision (Input) Ground connections - T - Faults 17, 18 Saftey (Earth) Ground Terminal Connectors - H - Heartbeat © 2011 Apollo Security Inc.
