KAMEHA KA054 User Manual

Connection instruction:
1）Connect HDMI input with HDMI output of source device.
2) Connect RJ45 port with RJ45 input port of HDMI extender RX.
3) Connect HDMI output of HDMI extender RX to HDMI input of HDTV
and set the TV source input to correct HDMI input channel.
4) Power on the device and it works.
8、 Specification
Item Specification
HDMI Signal HDMI 1.3，HDCP1.2
Input Port 8 x HDMI
Output Port 8 x RJ45
Transport Protocol HDbitT
480i@60Hz, 480p@60Hz, 576i@50Hz, 576p@50Hz,
Support Resolution
720p@50/60Hz,1080i@50/60Hz, 1080p@50/60Hz
Transmission Up to 120meters transmission distance for 1080p full HD
Distance over single CAT6
Working
0℃～60℃
Temperature
Power supply AC100-240V
Power
Consumption
Dimension 483(L) x 240.5(W) x 133(H) mm
Weight
Color
Black
Disclaimer
The product name and brand name may be registered trademark of related
manufacturers.TM and ® may be omitted on the user manual. The pictures
on the user manual are just for reference,and there may be some slight
difference with the real products.
We reserve the rights to make changes without further notice to a product
or system described herein to improve reliability, function or design.
8×8 HDbitT HDMI Matrix
User Manual
