PP30 Filtration Clean & Check
NOTICE:
See MCRCD/HREC Safety section
For a list of all parts of the Power Pallet including a list of parts, definitions and all other
useful information see the PP30 Component Reference document
All tasks should be performed after every 140 run hours

Check/Replace: Filter bags

1 of 7
FILE-004472 PP30 Filter Clean & Check

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PP30 and is the answer not in the manual?

Questions and answers

Related Manuals for All Power Labs PP30

Summary of Contents for All Power Labs PP30

  • Page 1 See MCRCD/HREC Safety section For a list of all parts of the Power Pallet including a list of parts, definitions and all other useful information see the PP30 Component Reference document All tasks should be performed after every 140 run hours...
  • Page 2 PPE 2. Disconnect all gas lines, air servo wire, and pressure tubes connected to the filter 3. Remove bag slapper handle 4. Remove the filter lid and filter vessel 2 of 7 FILE-004472 PP30 Filter Clean & Check...
  • Page 3 5. Remove the bag slapper 6. Undo wing nuts and remove old bags and rings 7. Put bags into waste disposal 8. Take new bags and coat inside with CCC particulate 3 of 7 FILE-004472 PP30 Filter Clean & Check...
  • Page 4 1. Remove Vband clamp and pull out old polishing filter 2. Check the metal mesh flame arrestor is not dirty, clean if necessary with alcohol 3. Install with new filter Check basepan for condensate or particulate build up 4 of 7 FILE-004472 PP30 Filter Clean & Check...
  • Page 5 5. Disconnect all electrical connections 6. Remove Cyclone Collection Can (CCC) and Cyclone to PG HX corrugated tube Clean cyclone insides from base with scraping bar 1. Using scraping bar clean the inside 5 of 7 FILE-004472 PP30 Filter Clean & Check...
  • Page 6 8. Add a cup of 90% isopropyl alcohol 9. Place PGHX on top of PGHX Cleaning Heater 10. Tighten all san connections 11. Bolt cap to gas in port on PGHX 6 of 7 FILE-004472 PP30 Filter Clean & Check...
  • Page 7 17. Once PGHX is actuating fully shut off the PGHX Cleaning Heater and let the PGHX cool down for 30 mins 18. Once cool, undo the san clamp and move PGHX back to basepan. 19. Secure all sani connections and fill up coolant system 7 of 7 FILE-004472 PP30 Filter Clean & Check...
