- Page 1 Bastutunna Brage Sauna 280, Ø235 Please read the whole manual before start. All given measurements are in millimeters.
- Page 2 SAUNA 280, Ø 235 Details List Nr. 1 Glass walls installation manual is on extra pages!
- Page 3 SAUNA 280, Ø 235 Details List Nr. 2 x1 kmp. x4 pkg. ~1kg x160...
- Page 4 Sauna 280, Ø235 mm=mm DET 1 1700 2xDET A DET 1...
- Page 5 Sauna 280, Ø235 4 x DET 3a 4 x DET 3b mm=mm mm=mm 2x M 1x DET 2...
- Page 6 Sauna 280, Ø235 16x M...
- Page 7 Sauna 280, Ø235 2xDET P Drill holes Ø10 mm into DET 2, outside 90°...
- Page 8 Sauna 280, Ø235 6x I Drill holes Ø4mm before screws Back 2x M Cut boards from pallet ca 2100mm. NB! Check front glass installation manual on extra pages! Front...
- Page 9 Sauna 280, Ø235 4x H 4x H 1xDET 3a 1xDET 3b Fix temporarily to support walls. ~7mm Use waterlevel Important! Keep distance!
- Page 10 Sauna 280, Ø235 See page 6A 20 x H 13x DET 3b 12x DET 3a Remove 18xH 9x DET 3a 18xH 9x DET 3b...
- Page 11 Sauna 280, Ø235 Glue Use wood glue between boards DET 6b 6xH(M) DET 6a...
- Page 12 Sauna 280, Ø235 DET B1 DET B1 ~240 mm DET B DET B 3x DET B Remove Remove all screws ~100 Use strap NB! Remove all screws and use them on further sauna installation During assembly and retightening the threaded rods, use oil (Würth HPS 1400 or similar) to avoid "cold welding"...
- Page 13 Sauna 280, Ø235 1xDET G 3x K 1xDET F Back 3x K Remove all brackets 2xDET F 3x K 3x K...
- Page 14 Sauna 280, Ø235 Front Back 2x DET 8 2x DET 11 Drill holes Ø4mm before screws 10x H 2x DET 9...
- Page 15 Sauna 280, Ø235 NB! Be careful, do not hit the glass. Drill holes Ø4mm 4x H before screws Drill holes Ø4mm before screws 2x H 4x H 4x DET 11 4x DET 13 Cut on right size Drill holes Ø4mm Drill holes Ø4mm before screws before screws...
- Page 16 Sauna 280, Ø235 2x DET 14 2x DET 15 Drill holes Ø4mm before screws 4x M 8x H Drill holes Ø4mm before screws 2x DET 15...
- Page 17 Sauna 280, Ø235 1xDET 16 minerit 2x H 1xDET 18b 1xDET 17 minerit 1xDET 18a 8x J(K) 2x DET L NB! If Your sauna equipped with electrical heater, fix DET 17 directly to the wall without 8x H DET L. Then use screws K.
- Page 18 Sauna 280, Ø235 Drill holes Ø3mm 2X DET 21 before screws 4x DET 20 4x H 2x I Cut on right size 1x DET 22 NB: Place heater Drill holes Ø4mm first. Backrests is optional. before screws 2x DET 23 6x H 4x H...
- Page 19 Sauna 280, Ø235 Push door against wall and fix it from inside 2x DET 19a 2x DET 19b 8x H 16x J Use waterlevel for door installation. NB! Place door from inside 2x M 1x DET 19 2x DET 19c 2x DET 19d 16x H Drill holes Ø4mm...
- Page 20 Sauna 280, Ø235 2x DET 24a Drill holes Ø4mm before screw 4x DET 24b 4x M Be careful, do not 1x DET 11 hit the glass. 1x DET 11 1x M 1x M 4x H 4x H Drill holes Ø4mm before screw.
- Page 21 Sauna 280, Ø235 DET N NB! Check also shingles installation manual inside shingles package! ~10mm 12x H 2x DET 26...
- Page 22 Sauna 280, Ø235 9x DET 27 9x DET 27 NB! Check also shingles installation manual inside shingles package! Shingles overlap on the top Remove 18x H 18x H DET A DET N DET O Cut and use Cut off it on other side.
- Page 23 Glass Wall mounting Ø226 Thickness 15 mm. Thickness 28 mm. Thickness 15 mm for wall 42 mm. x40/64 Apply waterproof Baseframe 28mm. DET 1 silicone to the groove Use piece of wood to protect plywood DET 4a DET 3b DET 3a DET 4b DET 2...
- Page 24 Glass Wall mounting Ø226 Mount carefully glasses. ~2mm Coverframe 15mm. Apply waterproof silicone Use piece of wood to protect plywood DET 3 DET 1 DET 4 DET 2...
- Page 25 Glass Wall mounting Ø226 DET X ONLY if Your sauna wall thickness is 42 mm. 3*40 (40 stk.) min.20mm 24x J Please be careful!!! Do not hit the glass with the screw. 8x DET X...
