- Page 1 Courtesy of:DiscountCarStereo.com BT45-CDR30 Quick Start Bluetooth Install Guide for Porsche CDR30 & CDR30 Radios Created December 22, 2016 Revised: February 2, 2019...
- Page 2 Bluetooth kit is essential to reducing driver distraction. If your vehicle is fitted with Porsche CDR30 or CDR31 radio, our BT45-CDR30 is the kit you need to upgrade to Bluetooth features without changing the radio. This kit is compatible with virtually all Bluetooth phones, and sounds great whether using it for mobile conversations, streaming music.
- Page 3 Vehicle with premium sound (amplifiers) must transfer orange fiber plug from factory plug to installation harness Quadlock labelled (to radio). Failure to perform this step will result in no sound Fig. 2 Alert! Factory 12-pin micro-Quadlock (Green for AUX and Blue for Bluetooth) may or may not be present in your vehicle;...
- Page 4 Connect 3.5mm plug from installation harness (See Fig. 5) to Module. (See Fig. 6) Fig. 5 3.5mm male plug Connect 6-pin plug from installation harness to input on Module (See Fig. 8 and 9) Fig. 8 Fig. 9 Fig. 6 Bluetooth Module Secure module and pro Initial Radio Setup...
- Page 5 Wireless Remote Control This is a one-time process that will not have to be repeated. After initial pairing, Twist open remote-control bottom cap the BT45-CDR30 will automatically reconnect with paired phone after entering vehicle. Close cap Use enclosed double-side tape and place remote control at a location that is most convenient for you.
- Page 6 Wireless Remote-Control Functions Hands-Free Phone Call Operation Answer and end calls. To answer call, press the b button on remote control or answer directly on phone* To reject call or end press the button on remote control Phone call audio can be adjusted by remote control, phone control, radio volume or steering wheel control buttons (if so equipped) *if you answered call directly from your phone, phone audio will go through the phone.
- Page 7 × 2. Does the BT45-CDR30 work on all Porsche Radios? 3.5mm AUX input ✓ ✓ the BT45-CDR30 works on Porsche CDR30 and CDR31 radios only. USB Charging Port ✓** ✓ 3. Can I control Smartphone from the radio buttons? Mute Audio System ✓*...
