Eggtimer Rocketry Eggtimer TRS Assembly Manual page 4

Hope RF HM-TRP Documentation (FCC test documentation)
http://www.hoperf.com/upload/rf/HM-TRP-915(20dBm)-FCC.pdf
FAA Regulations for Amateur Rocketry (Part 101)
http://www.ecfr.gov/cgi-bin/text-
idx?c=ecfr&rgn=div5&view=text&node=14:2.0.1.3.15&idno=14
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
Before You Start...
• Go to our web site at
• Go to our web site at
Guide..
• Read them thoroughly before starting... it will save you some grief later, we promise!
• Go to our web site and download the latest firmware version, if your Eggtimer TRS wasn't
shipped with the latest and greatest.
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
Thanks for buying an Eggtimer TRS Flight Computer! The Eggtimer TRS is a hobby rocketry
flight computer and GPS tracker that uses a GPS module and a 900 MHz license-free
transmitter module to broadcast your rocket's location in real-time to a computer or tablet. In
addition, it's a full-function 2-channel flight computer that can support dual-deployment and
records up to 32 flights. With appropriate GPS tracking software, which is available for free
on the Internet, you can actually track your rocket in flight, and ultimately find out exactly
where it landed. With the Eggfinder LCD receiver, you can get the real-time altitude updates
during your flight, and program the flight settings remotely without having to open up your AV
bay.
Like other Eggtimer Rocketry products, we sell it as a kit, to keep costs down and provide an
outstanding value. This means that you have to do a little work, of course, but considering that
most hobby rocketeers that would use our products have some degree of electronics expertise,
this should not be much of an impediment. If you do not have any experience soldering kits
such as the Eggtimer TRS, we recommend that you ask around... chances are that somebody in
your rocketry club would be more than happy to assist you for a small bribe (beverages work
well!).
In order to use your Eggtimer TRS Flight Computer to track your rocket, you'll need a
compatible receiver. The Eggfinder RX "dongle" receiver will allow you to download the
NMEA data stream to a computer in real-time. With a NMEA-compatible mapping program,
you can generate a track of where your rocket went, and track it in real-time.
www.Eggtimerrocketry.com
www.Eggtimerrocketry.com
and download the latest Release Notes.
and download the latest Assembly/Users
