- Page 1 40-INCH EXERCISE TRAMPOLINE WITH HANDRAIL MODEL# 9040MTH PRODUCT MANUAL - VERSION 5.21.01 FOR AGES: WEIGHT LIMIT: TO BUILD: TOOLS NEEDED: 100 Kgs CUSTOMER SERVICE GQBrands.com • CustomerService@GQBrands.com • 1-866-498-5269 • 4401 Samuell Blvd, Ste 150, Mesquite, TX 75149...
-
Page 2: Customer Service Information
Most up to date manuals, warnings and product information can be found at: WITH HANDRAIL https://www.globalqualitybrands.com/warnings MODEL# 9040MTH To register you product please visit: www.globalqualitybrands.com/product- If you have an issue with your item, do not return. Please report items... -
Page 3: Important Message
WARNINGS IMPORTANT MESSAGE Please read all of the warnings and directions below prior to assembly. This trampoline comes equipped with warnings and instructions for the assembly, care, maintenance and use of the trampoline. This information must be read by all trampoline supervisors and users before any person is allowed to jump on the trampoline. - Page 4 - Use trampoline only with mature, using. knowledgeable supervision. - Replace label if illegible or removed. 220 LBS MAX WEIGHT MODEL# 9040MTH Global Quality Brands - PureFun.net 4401 Samuell Blvd, Ste 150 Mesquite, TX 75149 MADE IN CHINA CustomerService@GQBrands.com Global Quality Brands - PureFun.net CustomerService@GQBrands.com...
- Page 5 WARNINGS & SAFETY INFORMATION Please read these warnings and the information in this manual in its entirety. Failure to comply with the following instructions may increase the risk of serious injury and/or death: • This unit is designed only for jogging in place •...
-
Page 6: Safety Information
SAFETY INFORMATION • Safety Information: This trampoline is designed and • IMPORTANT: manufactured to provide you and your family with You must not use the trampoline if you have a many years of fun and exercise, but for your benefit medical history of neck or back injuries or certain and safety, please read this manual carefully and in mental or physical conditions –... -
Page 7: Basic Trampoline Skills
BASIC TRAMPOLINE SKILLS Jumping Jacks Tuck Jumps Stand with your feet together and your arms alongside From standing, jump up and tuck your knees into your body. your chest. Lift your arms overhead as you jump your feet apart. Upon landing, do a recovery jump. Then jump back to the starting position. -
Page 8: Parts List
PARTS LIST Frame Jumping Mat Spring T-Section Piece Cross-Section Piece 40mm Carriage Bolt W-Hook 50mm Carriage Bolt 11 - 10 - Washer 12 - Frame Pad Leg with Cap 13 - 15 - Straight Pole 14 - Handle Bar with Foam Grip Large Square Washer GQBrands.com CustomerService@GQBrands.com... - Page 9 Make sure that the spring ends are facing up, and the logo printed on the Jumping Mat is facing the floor. T-Section Locations Identify all openings on the Frame Pad. There are four sections with 1 opening (A), and two sections with 2 openings (B). MODEL# 9040MTH...
- Page 10 ASSEMBLY INSTRUCTIONS STEP 2: Parts: Part 5 (x8) T-Section Piece Part 7 (x4) 40mm Square Neck Bolts Part 9 (x4) Nuts Part 15 (x4) Large Square Washer Locate the (A) openings in the frame (Shown in Page 5) to begin installing the T-Sections Pieces into the Frame.
- Page 11 Repeat this process to assemble the second Cross-Section on the Frame. NOTE: (15) Make sure Bolt is fully inserted and the Nut is not fully tightened. This will help (15) inserting the Legs in Step 6. Tighten Loosely MODEL# 9040MTH...
- Page 12 ASSEMBLY INSTRUCTIONS STEP 4: Parts: Part 11 (x1) Frame Pad Flip the Assembled Frame in order to place the Frame Pad (11). Two openings are assigned for the Cross- Section Pieces. Place on top Frame to cover the Frame & Jumping Mat. (11) Once the Frame Pad is placed, flip the frame again so the Jump Mat faces the...
- Page 13 (10) (9) B. Repeat this process until all legs in T-Sections are installed properly and securely. NOTE: Tighten Do not Tighten any Nuts from the Cross- Section Pieces. Doing so will make it difficult to install the Straight Poles. MODEL# 9040MTH...
- Page 14 ASSEMBLY INSTRUCTIONS STEP 8: Parts: Part 7 (x2) 40mm Square Neck Facing Facing Bolts Part 9 (x2) Nuts Center Center Part 10 (x2) Washers Part 13 (x2) Straight Pole A. Insert x2 Straight Poles (13) into the upper openings of the Cross-Sections. NOTE: Straight poles upper openings must face the center of the trampoline.
- Page 15 IMPORTANT: Handle Bar must be snapped on the same height for both openings. Failure to do this will cause the Poles to bend, snap, or break. Failure to do so may result in injury to the user. MODEL# 9040MTH...
-
Page 16: Frequently Asked Questions
FREQUENTLY ASKED QUESTIONS • Question: “One of my trampoline legs has • Question: “I had a part missing from my • Question: “How do I remove the black broken” or “The trampoline padding or box” or “something was damaged during caps on the frame of the trampoline?”...
