SW-351 SMARTWATCH

User's Guide

www.denver.eu

www.facebook.com/denver.eu

ENGLISH

Need help?

Do you have a question about the SW-351 and is the answer not in the manual?

Questions and answers

Summary of Contents for Denver SW-351

Page 1 SW-351 SMARTWATCH User’s Guide www.denver.eu www.facebook.com/denver.eu ENGLISH...
Page 2 Safety information Please read the safety instructions carefully before using the product for the first time and keep the instructions for future reference. 1. This product is not a toy. Keep it out of reach of children. 2. Warning: This product includes lithium polymer battery.
Page 3 to avoid chewing and swallowing. 4. Product operating and storage temperature is from -5 degree Celsius to 40 degrees Celsius. Under and over this temperature might affect the function. 5. Never open the product. Touching the inside electrics can cause electric shock.
Page 4 7. Please remove the Smart watch in case of any leakage or excessive heat from the product to avoid burns or rash. 8. Only charge with the supplied USB cable. 9. Using other accessories than the ones delivered with the product can cause abnormal functionality.
Page 5 presence of obstacles (people, metal objects, walls, etc.) or the electromagnetic environment. 11. Microwaves emitting from a Bluetooth device may affect the operation of electronic medical devices. 1. Quick start guide Overview 1. Touch screen ENG-4...
Page 6 2. Power button 3. Heart rate sensor 4. Charging plate 5. Temperature sensor 6. Blood oxygen sensor 7. Sport mode key To charge the smart watch, connect the charging clip of the USB cable to the charging plate on the back of the smart watch.
Page 7 Install “Denver Smart Life Plus” app on the phone Search and install the “Denver Smart Life Plus” app from Google Play or App Store. Or scan the following QR code to directly install the app. ENG-6...
Page 8 Connect the smart watch with mobile phone 1. Enable Bluetooth on your smart phone. 2. Open “Denver Smart Life Plus” on your smart phone; set your profile in Settings. 3. Tap “Connect Smartwatch” in Settings. 4. Choose your smartwatch and connect it...
Page 9 Unbind the smart watch with mobile phone 1. Open “Denver Smart Life Plus” on your smart phone. 2. Tap “Disconnect Smartwatch” in Settings. 3. To disconnect your smart watch with an iPhone, please click “Disconnect Smartwatch” in “Denver Smart Life Plus Settings”,...
Page 10 Operation introduction You can raise your hand ⚫ or press the power button to light the screen. Press and hold the ⚫ watch face screen, then slide left or right to change the watch face. Press and hold the ⚫ power button to turn on the smart watch when powered off.
Page 11 seconds. Go to menu screen: Slide ⚫ left in the watch face screen. Select a function: Click on ⚫ the icon. Exit the menu: Slide the ⚫ screen from left to right. Return to the watch face: ⚫ Short press the power button in any screen.
Page 12 After turning on the smart watch, the watch face screen is displayed. When the watch face ENG-11...
Page 13 screen is displayed: 1. Go to the menu screens a. Slide left in the watch face screen to enter the menu screens. b. Slide up and down to switch the menu screens. c. Tap the icon to enter the sub menu. Slide from left to right to return to the previous menu.
Page 14 the watch face screen. 3. Go to other shortcuts screen Slide up and down in the watch face screen. 4. Functions ENG-13...
Page 15 Watch face screen You can press the power button to go to the watch face screen quickly. If you want to change the watch face of your smart watch, press and hold the current watch face for 3 seconds, then slide left and right to go through the different watch faces and choose the one you like.
Page 16 You can tap the brightness icon to adjust (+/-) the screen brightness. Find phone ⚫ If your smart watch is connected with Denver Smart Life Plus app, you can find your phone by tapping this icon and your phone will ring. Shut down ⚫...
Page 17 You can shut down your smart watch by tapping this icon. Settings ⚫ You can go settings quickly by tapping this icon. Stopwatch ⚫ You can enter stopwatch quickly by tapping this icon. Multi-Sport Tap this icon to enter the multi-sport mode.
Page 18 If you want to end the sports, slide the screen to right and tap the “√” icon to finish your sports and save the data. The smart watch displays your exercise data. If you’ve connected your smart watch with the “Denver ENG-17...
Page 19 Smart Life Plus” app via Bluetooth, you can also check your exercise data in the app. Note: Too little exercise data will not be saved. Body temperature monitor Tap the body temperature ENG-18...
Page 20 icon to monitor your current body temperature. To exit the body temperature monitor, slide the screen to right. Please notice – this is not medical grade. If you are unsure, always use a standard thermometer. Measurement tolerance 0.4 degrees Celsius. Blood oxygen monitor Tap the blood oxygen icon ENG-19...
Page 21 Tap this icon to monitor your current heart rate. To exit the heart rate monitor, slide the screen to right. If you’ve connected your smart watch with the “Denver Smart Life Plus” app via Bluetooth, you can also check your heart rate ENG-20...
Page 22 data in the app. Sleep monitor The smart watch automatically monitors your sleep between 9:00 p.m. and 9:00 a.m. When you get up the next day, the smart watch displays your sleep report about the time of total sleep, light sleep and deep ENG-21...
Page 23 If you’ve connected your smart watch with the “Denver Smart Life Plus” app via Bluetooth, you can also check more detailed sleep report in the app. Alarm You can set reminders in both “Denver Smart Life Plus” app and smart watch itself.
Page 24 watch vibrates. Messages Slide the watch face from left to right, and then you can check your phone calls, SMS, QQ, WeChat, Whatsapp, Facebook and Twitter notifications, etc. The messages will be automatically deleted after reading. ENG-23...
Page 25 Weather If you’ve connected your smart watch with the “Denver Smart Life Plus” app via Bluetooth, the smart watch displays the weather forecast. Camera After connecting with the ENG-24...
Page 26 app, you can take pictures remotely from your smart watch. Music playback control Tap the music icon to enter the music playback control interface. You can select the previous/next song, and play/pause music. To exit music playback control, slide the screen from left to right.
Page 27 Sedentary reminder Go to the “Settings” in the “Denver Smart Life Plus” app to set the time intervals (minutes), start time and end time. Turn on/off sedentary reminder on smart watch or app. Slide the screen to right to exit.
Page 28 Tap this icon to enter the settings menu. ⚫ Find phone If your smart watch is connected with Denver Smart Life Plus app, you can find your phone by tapping this icon and your phone will ring. ⚫ Dial Switch...
Page 29 the different watch faces and choose the one you like. ⚫ Screen brightness You can tap the brightness icon to adjust (+/-) the screen brightness. ⚫ System You can check the system of your smart watch by tapping this icon. ⚫...
Page 30 You can shut down your smart watch by tapping this icon. ⚫ Reset You can reset your smart watch by tapping this icon. ⚫ Display Off You can set time to turn off display. ⚫ Temperature settings You can set temperature unit here.
Page 31 Please notice - All products are subject to change without any notice. We take reservations for errors and omissions in the manual. ALL RIGHTS RESERVED, COPYRIGHT DENVER A/S Electric and electronic equipment and included batteries contains materials, components and substances that can be...
Page 32 and the environment, if the waste material (discarded electric and electronic equipment and batteries) is not handled correctly. Electric and electronic equipment and batteries is marked with the crossed out trash can symbol, seen below. This symbol signifies that electric and electronic equipment and batteries should not be disposed of with other household...
Page 33 As the end user it is important that you submit your used batteries to the appropriate and designated facility. In this manner you make sure that the batteries are recycled in accordance with legislature and will not harm the environment. All cities have established collection points, where electric and electronic...
Page 34 Hereby, DENVER A/S declares that the radio equipment type SW-351 is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: www.denver.eu, and then...
Page 35 Write model number: SW-351. Now enter product page, and red directive is found under downloads/other downloads. Operating Frequency Range: 2.402GHz—2.480GHz Max Output Power: 3.3dBm Warning Lithium battery inside DENVER A/S Omega 5A, Soeften...
Page 36 Denmark www.facebook.com/denver ENG-35...
