- Page 1 Instruction Manual Smart Watch SW-500 www.denver-electronics.com Before operating this product, please read this instruction manual carefully and completely.
- Page 2 Feature • 1.3-inch IPS full screen display • Multi-Sport Mode (Running, Walking, Hiking, Biking, Indoor Run & Trail Run) • Track your sport performance • Provide comprehensive GPS location • Digital Crown integrated, rotate it to change the menu easily •...
- Page 3 4.4 or above • Different design styles for your different occasions and preferences Overview Smart Watch 1. MIC 2. Barometer sensor 3. Touch screen 4. Shortcut key for Sport mode 5. Digital crown 6. Power button 7. Speaker 8. Heart rate sensor 9.
- Page 4 Adaptor current is: 5V, 500mA. • It takes 2-hours to fully charge the smart watch, please follow steps below to charge. 1. Put charging cradle beneath watch. Make sure the POGO-pins on the cradle fit correctly onto the charging terminals on the back of smart watch.
- Page 5 • Exit: Swipe from left to right • Return to watch face interface: Short press power button on any interfaces • Sport mode shortcuts: Press the upper button • Check notifications: Swipe from left to right on watch face interface •...
- Page 6 The steps to calibrate the sensor： Temperature: Settings-> Sensor calibration-> Temperature, set up the correct temperature value and click “OK”. Pressure: Settings-> Sensor calibration-> Pressure, set up the correct pressure value and click “OK”. Altitude: Settings-> Sensor calibration-> Altitude, if you select “Manual”, set up the correct altitude value and click “OK”.
- Page 7 Temperature: You can refer to the thermometer to calibrate the watch's temperature; Pressure: If you are using iPhone, you can see the current city pressure in the Weather application Altitude: You can download an app called "GPS Recorder", open your mobile phone location service, and then refer to "Meter"...
- Page 8 Main Menu When turning on smart watch, you will see the watch face. From watch face: 1. Go to Main Menu a. Slide from right to left to enter into main menu. b. Swipe up and down (or turn the digital crown) to switch the main menu.
- Page 9 2. Go to Notification shortcut page Slide from left to right 3. Go to other shortcuts page Swipe up and down. Pair with smart phone Mobile phones requirement: Android 4.4 and above iOS7.0 and above Search and download “Orunning” app from App store or the Google Play Store on your smart phone.
- Page 10 connection. Step 2: Pairing for calling function (Only for iPhone) Go to iPhone “Settings””Bluetooth” and select your smart watch name in the list of devices for connection. Remark: • If the connection is successful, a check mark will appear next to the name of your phone •...
- Page 11 If you want to change the watch face of your smart watch, press the current watch face for 3 seconds, swipe left or right to go through the different watch faces and tap on the one you want to select and use. Shortcut 1.
- Page 12 2. GPS Meaning the status of GPS, you can click the icon to switch on/ off the GPS. Means GPS is off; Means GPS is on; Sound mode Meaning the status of Sound mode, you can click the icon to ring, vibration or mute mode; Means ring mode Means vibration mode Means mute mode...
- Page 13 “Activate on wrist flisk”, turn off GPS, set up mid-brightness and vibration mode. Airplane mode: smart watch will automatically turn on the ”Activate on wrist flisk”, turn off Bluetooth and GPS, set up mid-brightness and ring mode. Sport mode: smart watch will automatically...
- Page 14 Means high-Brightness Means mid-Brightness Means low-Brightness Sport mode 1. You can press the shortcut key of sport mode or tap below icon on main menu to enter sport mode. 2. Multi-Sport mode: with 6 sport mode as below. Slide up/ down (or turn the digital crown) to select the sport mode you want to start.
- Page 15 When turned off Calculate by steps (except Biking ) 4. Activity goal You can set up the following goals before going to activity. Distance Calories Duration Pace Free Style Remark: The watch will pop up a reminder once you achieve the goal (Pace and Free Style without reminder).
- Page 16 and show the heart rate zone. 6. GPS locate Acquiring Satellite Signals The device may need a clear view of the sky to acquire satellite signals. a. Go outdoors to an open area, The front of the device should be oriented toward the sky.
- Page 17 1. Distance 2. Duration 3. Pace 4. Calories 6. Target 5. Dynamic heart rate 7. Current progress value time status 8. Altitude (works on Trail 9. GPS 10. Heart running, Hiking, Biking status rate zone mode only) GPS off Searching GPS signal GPS located successfully Heart rate range: the watch will automatically calculate your heart rate interval according to your...
- Page 18 Aerobic - Medium intensity training to improve aerobic capacity. Help to strengthen the heart and lung and blood vessels Threshold - Improve lactic acid tolerance, enhance high-speed exercise strength and endurance Maximum - Show breathing and muscle strength treatment of anaerobic state.
- Page 19 You can check your sport records at the bottom of the sport mode. Including the percentage of goals, exercise time, movement distance, calories, the average pace, average heart rate value. Delete record: Check the record, then tap “Delete” or long press the corresponding data. Heart rate Fasten the watch, make sure it fits closely on your wrist when measuring your heart rate.
- Page 20 Goals Set daily pedometer goals, including steps, distance, calories, exercise duration. If you achieve the goal you set up, the watch will pop up a reminder.
- Page 21 Notification See app notifications from a connected smart phone, including notifications of incoming and missed calls, SMS, email, social media activity, etc.. SETTING UP NOTIFICATIONS FOR ANDROID USERS Go to the Settings of your Android device: Tap Notifications in Settings. Select which type of notifications you want to receive on Smart Watch Enable Show in Notifications to receive the...
- Page 22 Sedentary reminder When you set up the sedentary reminder, the watch will automatically detect whether you are sedentary and pop up “Move up now” with ring and vibration if yes. Sleep monitor Slide from right to left to set up the bed time and wake time.
- Page 23 Your sleep data will be synchronized to APP once you paired the watch with your smart phone. You can check your sleep data of last night as well. Reminder Support multiple reminders. With 6 different interfaces to remind you.
- Page 24 You can check and turn/ off your next reminder on shortcut menu (from watch face interface, slide from down to up). Voice Trigger the Siri assistant/ Google Talk when connected to your iPhone/ Android phone. Examples of what you can ask or do: Call (name of your contact)
- Page 25 Send a SMS to (name of your contact) What’s the weather like? Set an alarm for tomorrow 5 am Weather When you paring the watch with your smart phone in the case of your phone have Internet, the watch will sync your local weather forecast (Max/ Min temperature of the day) as below.
- Page 26 (Shortcuts: from watch face interface, slide from down to up) Altitude With the smart watch, you can check the current altitude. If you need to calibrate altitude， please press “Cal” to enter altitude calibration. (Shortcuts: from watch face interface, slide from down to up)
- Page 27 Location If you turned on GPS of your smart watch and located your position successfully, there will show the current latitude and longitude. If you close the GPS or enter indoor, the watch will keep latest latitude and longitude. (Shortcuts: from watch face interface, slide from down to up) Remote capture To enjoy this feature, make sure the camera of your...
- Page 28 Dialer The watch allows you to make and receive calls in case of connected smart watch with your phone via Bluetooth) Making a call Receive call When your phone receive FROM THE PHONE a call, the watch will pop MENU Go to the Phone menu, INCOMING-CALL enter a number with...
- Page 29 View SMS messages from a connected Android phone. QUICK REPLY You can reply through the SMS template (Android only) The SMS of iPhone will be displayed in Notification menu. BT music Control the music player app of a connected smart phone.
- Page 30 Settings Use the Settings panel to configure the settings of your Smart Watch I Profile：Set up Gender, Height, Weight, Birthday I Bluetooth ： Turn Bluetooth on/off and visibility on/off I GPS：Turn GPS on / off I Sensor Calibration: You can manually calibrate the watch's temperature, altitude, and atmospheric pressure I Time and date：Set up the clock type on the display...
- Page 31 I Language：Multi-languages (You can turn “Auto sync” off to select the languages you need) I Power display：Displays the current power status I Restore to Factory：Reset to factory default...
- Page 32 Additional information is available at the technical department of your city. Hereby, Inter Sales A/S declares that the radio equipment type SW-500 is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: http://www.denver-electronics.com/denver-sw-500/...
