Summary of Contents for Hyundai KONA N 2022

  • Page 3 Maintenance Specifications All information in this Owner’s Manual is current at the time of publication. However, HYUNDAI reserves the right to make changes at any time so that our policy of continual product improvement may be carried out. This manual applies to all models of this vehicle and includes descriptions and explanations of optional as well as standard equipment.
  • Page 4 Introduction CAUTION: MODIFICATIONS TO YOUR HYUNDAI Your HYUNDAI should not be modified in any way. Such modifications may adversely affect the performance, safety or durability of your HYUNDAI and may, in addition, violate conditions of the limited warranties covering the vehicle. Certain modifications may also be in violation of regulations established by the U.S.
  • Page 5 SAFETY AND VEHICLE DAMAGE WARNING This manual includes information titled as DANGER, WARNING, CAUTION and NOTICE. These titles indicate the following: DANGER DANGER indicates a hazardous situation which, if not avoided, will result in death or serious injury. WARNING WARNING indicates a hazardous situation which, if not avoided, could result in death or serious injury.
  • Page 6 HYUNDAI VEHICLE OWNER PRIVACY POLICY Your Hyundai vehicle may be equipped with technologies and services that use information collected, generated, recorded or stored by the vehicle. Hyundai has created a Vehicle Owner Privacy Policy to explain how these technologies and services collect use and share this information.
  • Page 7: Table Of Contents

    Table of contents Foreword Vehicle Information, Consumer Information and Reporting Safety Defects Seats & Safety System Instrument Cluster Convenient Features Driving Your Vehicle Driver Assistance System Emergency Situations Maintenance Index...
  • Page 8: Vehicle Information, Consumer Information And Reporting Safety Defects

    2. Vehicle Information, Consumer Information and Reporting Safety Defects Exterior Overview (I) ..................2-2 Exterior Overview (II) ..................2-3 Interior Overview (I) ..................2-4 Interior Overview (II) ..................2-5 Engine Compartment ..................2-6 Dimensions ......................2-7 Engine .........................2-7 Bulb Wattage ..................... 2-8 Tires and Wheels ....................2-9 Air Conditioning System ..................2-10 Volume and Weight ..................2-10 Recommended Lubricants And Capacities ............2-11...
  • Page 9 Vehicle Information, Consumer Information and Reporting Safety Defects The actual shape may differ from the illustration. OOSN011001N 1. Hood ............5-54 5. Tires and wheels ........9-34 2. Head lamp ..........9-62 6. Side view mirror ........5-48 3. DRL (Daytime Running Light) ....9-62 7.
  • Page 10 The actual shape may differ from the illustration. OOSN011002N 1. Door ............5-28 6. High mounted stop lamp .....9-64 2. Fuel filler door ........5-57 7. Rear window wiper blade ....9-29 3. Rear combination lamp......9-63 8. Rear view camera ........7-54 4.
  • Page 11 Vehicle Information, Consumer Information and Reporting Safety Defects The actual shape may differ from the illustration. OOSN011003N 1. Inside door handle ........ 5-29 7. DBC button ........... 6-30 2. Side view mirror control ....... 5-49 8. Hood release lever… ......5-54 3.
  • Page 12 The actual shape may differ from the illustration. OOSN011004N 1. Instrument cluster ........4-4 16. Drive mode knob ........6-38 2. Horn ............5-35 17. Seat warmer ...........3-16 3. Driver’s front air bag ......3-41 18. ESC off button ........6-23 4.
  • Page 13: Engine Compartment

    Vehicle Information, Consumer Information and Reporting Safety Defects ENGINE COMPARTMENT Gasoline 2.0 T-GDI The actual shape may differ from the illustration. OOSN091011L 1. Engine coolant reservoir .......9-19 5. Air cleaner ..........9-24 Engine coolant cap ....... 9-20 6. Engine oil dipstick .........9-16 2.
  • Page 14: Dimensions

    DIMENSIONS Items in. (mm) Overall length 165.9 (4215) Overall width 70.86 (1800) Overall height 61.02 (1550) / 61.61 (1565)* Front tread 235/40 R19 62.16 (1,579) Rear tread 235/40 R19 62 (1,575) Wheelbase 102.36 (2600) with roof rack *1 : ENGINE Engine 2.0 T-GDi Displacement...
  • Page 15: Bulb Wattage

    Vehicle Information, Consumer Information and Reporting Safety Defects BULB WATTAGE Light Bulb Bulb Type Wattage Headlamp High Turn signal lamp Front Side marker Turn signal lamp (side view mirror) Daytime running lamp (DRL) / position lamp Stop/Tail Rear combination Turn signal lamp Reverse lamp P21W...
  • Page 16: Tires And Wheels

    TIRES AND WHEELS Cold tire inflation Track driving * Wheel Lug nut pressure kPa(psi) Tire size Wheel size Torque [kgf.m kPa(psi) (lbf.ft,N.m)] Front Rear Front Rear 11~13 235/40 R19 8.0J X 19 255 (37) 240 (35) 240 (35) 240 (35) (79~94, 107~127) Refers to the recommended inflation pressure for the hot tire condition(state when the *1 :...
  • Page 17: Air Conditioning System

    Refrigerant 15.87 (450) ± 0.88 (25) R-1234yf oz. (g) Compressor lubricant 4.23 (120) ± 0.35 (10) oz. (g) Contact an authorized HYUNDAI dealer for more details. VOLUME AND WEIGHT 2.0 T-GDI Items Gross vehicle weight 4,431 (2010) lbs. (kg) Luggage volume (VDA) MIN : 12.75 (361)
  • Page 18: Recommended Lubricants And Capacities

    RECOMMENDED LUBRICANTS AND CAPACITIES To help achieve proper engine and powertrain performance and durability, use only lubricants of the proper quality. The correct lubricants also help promote engine efficiency that results in improved fuel economy. These lubricants and fluids are recommended for use in your vehicle. Lubricant Volume Classification...
  • Page 19: Recommended Sae Viscosity Number

    Vehicle Information, Consumer Information and Reporting Safety Defects Recommended SAE Viscosity Number CAUTION Always be sure to clean the area around any filler plug, drain plug, or dipstick before checking or draining any lubricant. This is especially important in dusty or sandy areas and when the vehicle is used on unpaved roads.
  • Page 20: Vehicle Identification Number (Vin)

    VEHICLE IDENTIFICATION VEHICLE CERTIFICATION LABEL Frame number OOSN011020N OOS087001 The vehicle certification label attached The vehicle identification number (VIN) on the driver’s (or front passenger’s) is the number used in registering your side center pillar gives the vehicle vehicle and in all legal matters pertaining identification number (VIN).
  • Page 21: Engine Number

    Vehicle Information, Consumer Information and Reporting Safety Defects ENGINE NUMBER REFRIGERANT LABEL OPDEN087012 OOSN051019N The engine number is stamped on the The refrigerant label provides engine block as shown in the drawing. information such as refrigerant type and amount. (R-1234yf) 2-14...
  • Page 22: Consumer Information

    This consumer information has been prepared in accordance with regulations issued by the National Highway Traffic Safety Administration of the U.S. Department of Transportation.Your HYUNDAI dealer will help answer any questions you may have as you read this information. HYUNDAI motor vehicles are designed and manufactured to meet or exceed all applicable safety standards.
  • Page 23: Reporting Safety Defects

    If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign. However, NHTSA cannot become involved in individual problems between you, your dealer, or HYUNDAI MOTOR AMERICA. 2-16...
  • Page 24 3. Seats & Safety System This chapter provides you with important information about how to protect yourself and your passengers. It explains how to properly use your seats and seat belts, and how your air bags work. Additionally, this chapter explains how to properly restrain infants and children in your vehicle. Important Safety Precautions ................3-2 Always Wear Your Seat Belt ..................
  • Page 25: Seats & Safety System

    Seats & Safety System IMPORTANT SAFETY PRECAUTIONS You will find many safety precautions Drivers can become distracted when and recommendations throughout this they take their eyes and attention off section, and throughout this manual. the road or their hands off the wheel to The safety precautions in this section are focus on activities other than driving.
  • Page 26: Seats

    SEATS The information provided may differ depending on which functions are applicable to your vehicle. OOSN031101N Front seat Rear seat (1) Forward and rearward (7) Armrest* (2) Seatback angle (8) Seatback folding (3) Seat height (9) Head restraints (4) Lumbar support (Driver’s seat)* (5) Seat warmer* *: if equipped (6) Head restraints...
  • Page 27: Safety Precautions

    Seats & Safety System Safety Precautions WARNING Adjusting the seats so that you are sitting To reduce the risk of serious injury or in a safe and comfortable position plays death from an inflating air bag, take the an important role for the safety of the following precautions: driver and passengers, as much as seat Adjust the driver’s seat as far to the...
  • Page 28: Front Seats

    Seat belts Front Seats Always fasten your seat belt before starting any trip. At all times, passengers WARNING should sit upright and be properly Take the following precautions when restrained. Infants and small children adjusting your seat: must be restrained in appropriate Child Restraint Systems.
  • Page 29 Seats & Safety System Power adjustment The front seat can be adjusted by using the control switches located on the outside of the seat cushion. Before driving, adjust the seat to the proper position so that you can easily control the steering wheel, foot pedals and controls on the instrument panel.
  • Page 30 Reclining seatback Sitting in a reclined position when the vehicle is in motion can be dangerous. Even when buckled up, the protections of your restraint system (seat belts and air bags) is greatly reduced by reclining your seatback. WARNING NEVER ride with a reclined seatback when the vehicle is moving.
  • Page 31: Rear Seats

    Seats & Safety System Rear Seats Folding the rear seat The rear seatbacks can be folded to facilitate carrying long items or to increase the luggage capacity of the vehicle. WARNING Never allow passengers to sit on top of the folded down seatback while OOSN031004L the vehicle is moving.
  • Page 32 OOS037019N OOSN031021L To fold down the rear seatback: 1. Set the front seatback to the upright position and if necessary, slide the front seat forward. 2. Lower the rear head restraints to the lowest position by pushing and holding the release button (1) and pushing down on the head restraint (2).
  • Page 33 Seats & Safety System WARNING Make sure the engine is off, the shift lever is in P (Park), and the parking brake is securely applied whenever loading or unloading cargo. Failure to take these steps may allow the vehicle to move if the shift lever is inadvertently moved to another position.
  • Page 34: Head Restraints

    Armrest Head Restraints The vehicle’s front and rear (second row and/or third row) seats have adjustable head restraints. The head restraints provide comfort for passengers, but more importantly they are designed to help protect passengers from whiplash and other neck and spinal injuries during an accident, especially in a rear impact collision.
  • Page 35 Seats & Safety System Front seat head restraints CAUTION When there is no occupant in the rear seats, adjust the height of the head restraints to the lowest position. The rear seat head restraints can reduce the visibility of the rear area. NOTICE To prevent damage, NEVER hit or pull on the head restraints.
  • Page 36 NOTICE OOSN031012L Removal/Reinstallation OLF034015 To remove the head restraint: If you recline the seatback towards the front with the head restraint and seat 1. Recline the seatback (2) rearward cushion raised, the head restraint may using the seatback angle lever/switch come in contact with the sunvisor or (1).
  • Page 37 Seats & Safety System Rear seat head restraint OOSN031100L To reinstall the head restraint : OOSEV038030L 1. Recline the seatback. The rear seats are equipped with head restraint in all the seating positions for 2. Put the head restraint poles (2) into the passenger’s safety and comfort.
  • Page 38 OOS037018N OOSEV038029 Adjusting the height up and down Removal/Reinstallation To raise the head restraint: To remove the head restraint: 1. Pull it up to the desired position (1). 1. Raise the head restraint as far as it can To lower the head restraint: 2.
  • Page 39: Seat Warmers

    Seats & Safety System NOTICE Seat Warmers Front seat warmers To prevent damage to the seat warmers and seats: Seat warmers are provided to warm the seats during cold weather. Never use a solvent such as paint thinner, benzene, alcohol or gasoline to clean the seats.
  • Page 40 Front seat OOSN031015N While the engine is running, push either of the switches to warm the driver's seat or front passenger's seat. During mild weather or under conditions where the operation of the seat warmer is not needed, keep the switches in the OFF position.
  • Page 41: Seat Belts

    Seats & Safety System SEAT BELTS This section describes how to use the NEVER wear a seat belt over fragile seat belts properly. It also describes objects. If there is a sudden stop or some of the things not to do when using impact, the seat belt can damage it.
  • Page 42: Seat Belt Warning Light

    Seat Belt Warning Light Seat belt warning Instrument cluster OOSN031025L Front passenger’s seat belt warning As a reminder to the front passenger, OAM032161L the front passenger’s seat belt warning Driver’s seat belt warning light will illuminate for approximately 6 As a reminder to the driver, the seat seconds each time you turn the Engine belt warning light will illuminate for Start/Stop button is in the ON position...
  • Page 43: Seat Belt Restraint System

    Seats & Safety System Seat Belt Restraint System WARNING Riding in an improper position WARNING adversely affects the front passenger’s seat belt warning system. It is important for the driver to instruct the passenger to properly be seated as instructed in this manual.
  • Page 44 Front Seat Belt – Driver’s 3point Information system with emergency locking If you are not able to smoothly pull retractor enough of the seat belt out from the retractor, firmly pull the seat belt out and release it. After release, you will be able to pull the belt out smoothly.
  • Page 45 Seats & Safety System Rear center seatbelt (3-point rear center seat belt) OHI038142 To release your seat belt: Press the release button (1) in the locking OOSEV038031L buckle. When using the rear center seat belt, the buckle with the “CENTER” mark must be Once released, the belt should used.
  • Page 46 Pre-tensioner seat belt (1) Retractor Pretensioner The purpose of the retractor pre- tensioner is to make sure that the shoulder belts fit in tightly against the occupant’s upper body in certain frontal or side collision(s). (2) Emergency Fastening Device System The purpose of the Emergency Fastening Device System is to make sure that the pelvis belts fit in tightly against the...
  • Page 47 Therefore, have the being driven, have the pre-tensioner system to be serviced by an authorized seat belts and/or SRS control module HYUNDAI dealer. inspected by an authorized HYUNDAI dealer as soon as possible. 3-24...
  • Page 48: Additional Seat Belt Safety Precautions

    Additional Seat Belt Safety Information Precautions Pre-tensioner seat belts may be Seat belt use during pregnancy activated in certain frontal or side collisions or rollover situations (if The seat belt should always be used during pregnancy. The best way to equipped with rollover sensor).
  • Page 49 Seats & Safety System Larger children WARNING Children under age 13 and who are ALWAYS properly restrain infants and too large for a booster seat should small children in a Child Restraint always occupy the rear seat and use the System appropriate for the child’s available lap/shoulder belts.
  • Page 50: Care Of Seat Belts

    This should be done even if no damage is hips to slide under the lap belt or the visible. Consult an authorized HYUNDAI passenger’s neck to strike the shoulder dealer. belt.
  • Page 51: Child Restraint System (Crs)

    Child Restraint System that meets the After an accident, have an authorized requirements of the Federal Motor HYUNDAI dealer check the child Vehicle Safety Standards (FMVSS 213). restraint system, seat belts, tether Child Restraint Systems are generally anchors and lower anchors.
  • Page 52: Selecting A Child Restraint System (Crs)

    Selecting a Child Restraint System (CRS) When selecting a Child Restraint System for your child, always: Make sure the Child Restraint System has a label certifying that it meets applicable Federal Motor Vehicle Safety Standards (FMVSS 213). Select a Child Restraint System based on your child’s height and weight.
  • Page 53: Installing A Child Restraint System (Crs)

    Seats & Safety System Installing a Child Restraint System (CRS) WARNING Before installing your Child Restraint System always: Read and follow the instructions provided by the manufacturer of the Child Restraint System. Failure to follow all warnings and OOS037029N instructions could increase the risk of Forward-facing Child Restraint System the SERIOUS INJURY or DEATH if an A forward-facing Child Restraint System...
  • Page 54 Make sure the Child Restraint System Lower Anchors and Tether for is firmly secured. After installing a Children (LATCH System) Child Restraint System to the vehicle, The LATCH system holds a Child push and pull the seat forward and Restraint System during driving and in from side-to-side to verify that it is an accident.
  • Page 55 (for example, toy, pen, wire) around the lower anchor area. Those objects may damage either the seat belt system or the Child Restraint System during the installment procedure. If necessary, have the vehicle inspected by an authorized HYUNDAI dealer. 3-32...
  • Page 56 Securing a Child Restraint System WARNING with the “LATCH Anchors System” Take the following precautions when To install a LATCH-compatible Child using the LATCH system: Restraint System in either of the rear Read and follow all installation outboard seating positions: instructions provided with your Child 1.
  • Page 57 Seats & Safety System Securing a Child Restraint System seat with “Tether Anchor” system OOS037032N To install the tether anchor: 1. Route the Child Restraint System OOS037031N top-tether strap over the seatback. First secure the child restraint with Route the tether strap under the the LATCH lower anchors or the seat head restraint and between the head belt.
  • Page 58 Securing a Child Restraint System WARNING with a lap/shoulder belt Take the following precautions when installing the top-tether: WARNING Read and follow all installation instructions provided with your Child ALWAYS place a rearward-facing Child Restraint System. Restraint System in the rear seat of the vehicle.
  • Page 59 Seats & Safety System OOS037030N OHI038145 2. Make sure to insert the belt into the Automatic locking mode guide (1) and check that the seat belt Since all passenger seat belts move is not twisted. freely under normal conditions and only lock under extreme or emergency conditions (emergency locking mode), you must manually pull the seat belt all...
  • Page 60 OHI038147 OHI038148 4. Pull the shoulder portion of the 5. Slowly allow the shoulder portion of seat belt all the way out. When the the seat belt to retract and listen for shoulder portion of the seat belt an audible "clicking" or "ratcheting" is fully extended, it will shift the sound.
  • Page 61 Seats & Safety System Information When the seat belt is allowed to retract to its fully stowed position, the retractor will automatically switch from the “Automatic Locking” mode to the emergency lock mode for normal adult usage. WARNING If the retractor is not in the “Automatic Locking”...
  • Page 62 The actual air bags in the vehicle may differ from the illustration. OOSN031034L 1. Driver’s front air bag 2. Passenger’s front air bag 3. Side air bag 4. Curtain air bag 3-39...
  • Page 63 Seats & Safety System The vehicles are equipped with a Supplemental Air Bag System for the driver’s seat and front passenger’s seats. The front air bags are designed to supplement the three-point seat belts. For these air bags to provide protection, the seat belts must be worn at all times when driving. You can be severely injured or killed in an accident if you are not wearing a seat belt.
  • Page 64: Where Are The Air Bags

    Where Are the Air Bags? The seat belt buckle sensors determine if the driver and front passenger's seat Driver’s and passenger’s front air belts are fastened. These sensors provide bags the ability to control the SRS deployment Driver’s front air bag based on whether or not the seat belts are fastened, and how severe the impact is.
  • Page 65 ON or START position as this deploy in all side impact or rollover may cause the side air bags to inflate. situations. If the seat or seat cover is damaged, have the system serviced by an authorized HYUNDAI dealer. 3-42...
  • Page 66 Curtain air bags For vehicles equipped with a rollover sensor the side and/or curtain air bags and pre-tensioners on both sides of the vehicle may deploy if a rollover or possible rollover is detected. The curtain air bags are not designed to deploy in all side impact or rollover situations.
  • Page 67: How Does The Air Bags System Operate

    The light blinks when the engine is The SRSCM (Supplemental Restraint running. System Control Module) continually Have an authorized HYUNDAI dealer monitors all SRS components while the inspect the SRS as soon as possible if Engine Start/Stop button is in the ON any of these conditions occur.
  • Page 68 During a moderate to severe frontal In addition to inflating in serious side collision, sensors will detect the collisions, vehicles equipped with a vehicle’s rapid deceleration. If the rate of rollover sensor, side and/or curtain air deceleration is high enough, the control bags will inflate if the sensing system unit will inflate the front air bags, at the detects a rollover.
  • Page 69 Seats & Safety System Driver’s front air bag (1) WARNING To reduce the risk of serious injury or death from an inflating air bag, take the following precautions: NEVER place a child restraint in the front passenger seat. Always properly restrain children under age 13 in the rear seats of the vehicle.
  • Page 70: What To Expect After An Air Bag Inflates

    Always have an authorized HYUNDAI dealer replace the air bag WARNING immediately after deployment. Air To prevent objects from becoming bags are designed to be used only dangerous projectiles when the once.
  • Page 71: Occupant Classification System (Ocs)

    Seats & Safety System Noise and smoke from inflating air Occupant Classification System (OCS) When the air bags inflate, they make a loud noise and may produce smoke and powder in the air inside of the vehicle. This is normal and is a result of the ignition of the air bag inflator.
  • Page 72 Main components of the Occupant You will find the “PASSENGER AIR BAG OFF” indicator on the overhead console Classification System panel. This system detects the conditions A detection device located within the 1-4 in the following table and activates or front passenger seat cushion.
  • Page 73 Seats & Safety System Condition and operation in the front passenger Occupant Classification System Indicator/Warning light Devices Condition detected by the “PASSENGER Front SRS warning occupant classification system AIR BAG OFF” passenger air light indicator light 1. Adult Activated 2. Infant or child restraint Deactivated system with 12 months old...
  • Page 74 WARNING Riding in an improper position or placing weight on the front passenger’s seat when it is unoccupied by a passenger adversely affects the OCS. To reduce the risk of serious injury or death: NEVER put a heavy load in the front seat or seatback pocket.
  • Page 75 Do not place any items under the front passenger seat. When changing or replacing the seat or seat cover, use original items only. The OCS has been developed based on using original HYUNDAI car seats only. Altering or changing the authentic parts may result in system malfunction and increase risk of injury when in collision.
  • Page 76 WARNING NEVER allow an adult passenger to ride in the front passenger seat when the “PASSENGER AIR BAG OFF” indicator is illuminated. During a collision, the air bag will not inflate if the indicator is illuminated. Have your passenger reposition themselves in the seat. If the “PASSENGER AIR BAG OFF”...
  • Page 77: Why Didn't My Air Bag Go Off In A Collision

    SERIOUS INJURY to the CHILD can deploy when they should. occur. Installing bumper guards with non- An inflating frontal air bag could genuine Hyundai or non-equivalent forcefully strike a child resulting in parts may adversely affect the serious injury or death. collision and airbag deployment Always properly restrain children in performance.
  • Page 78 OOSN031044N/OOSN031045L/OOSN031046N/OOS037047/OOS037077 1. SRS control module / Rollover sensor 3. Side impact sensor (Pressure) 2. Front impact sensor 4. Side impact sensor (Acceleration) 3-55...
  • Page 79 Seats & Safety System Air bag inflation conditions Side and curtain air bags Side and curtain air bags are designed to inflate when an impact is detected by side collision sensors depending on the severity, speed or angles of impact resulting from a side impact collision.
  • Page 80 Air bag non-inflation conditions OOSN031051N Front air bags may not inflate in side OOSN031052L impact collisions, because occupants In certain low-speed collisions the air move in the direction of the collision, bags may not deploy. The air bags are and thus in side impacts, front air bag designed not to deploy in such cases deployment would not provide additional because they may not provide benefits...
  • Page 81 Seats & Safety System OOSN031055L OOSN031054N Just before impact, drivers often brake Air bags may not inflate if the vehicle heavily. Such heavy braking lowers the collides with objects such as utility poles front portion of the vehicle causing it or trees, where the point of impact is to “ride”...
  • Page 82: Srs Care

    HYUNDAI dealer. Do not place objects over or near Any work on the SRS system, such as the air bag modules on the steering...
  • Page 83: Additional Safety Precautions

    Modifications to accommodate disabilities. If you require modification to your vehicle to accommodate a disability, contact the HYUNDAI Customer Connect Center at 800-633- 5151. Adding equipment to or modifying your air bag equipped vehicle If you modify your vehicle by changing your vehicle’s frame, bumper system,...
  • Page 84: Instrument Cluster

    4. Instrument Cluster Instrument Cluster .................... 4-4 Instrument Cluster Control ..................4-5 Instrument panel illumination ...................4-5 Gauges and Meters ..................... 4-6 Speedometer ......................4-6 Tachometer ........................ 4-7 Engine coolant temperature gauge ................4-7 Fuel gauge ......................... 4-8 Outside temperature gauge ..................4-9 Odometer ........................
  • Page 85 ECO Mode Indicator Light ..................4-20 Master warning light ....................4-21 N Mode Indicator Light ....................4-21 CUSTOM Mode Indicator Light ................4-21 LCD Display Messages ....................4-22 Shift to P ........................4-22 Low key battery ......................4-22 Press START button while turning wheel ...............4-22 Steering wheel not locked ..................4-22 Check Steering Wheel Lock System ...............4-22 Press brake pedal to start engine ................4-22 Key not in vehicle .....................4-22...
  • Page 86 4. Instrument Cluster LCD Display ..................... 4-28 LCD Display Control ....................4-28 View Modes ........................4-29 Trip computer mode ....................4-30 Turn By Turn (TBT) mode ..................4-30 Driving Assist mode ....................4-30 Sport view......................... 4-31 Master warning group .....................4-33 Trip Computer......................4-34 Trip modes ........................4-34 Vehicle Settings (infotainment system) ............
  • Page 87: Instrument Cluster

    Instrument Cluster INSTRUMENT CLUSTER Normal mode N mode The actual cluster in the vehicle may differ from the illustration. For more information, refer to “Gauges and meters” section in this chapter. OOSN041052N/OOSN041053N 1. Tachometer 4. Fuel gauge 2. Speedometer 5. Shift light 3.
  • Page 88: Instrument Cluster Control

    Instrument Cluster Control Type A Instrument panel illumination OOSN041017N Type B OOSN041009N When the vehicle's position lights or headlights are on, press the illumination control button to adjust the brightness of the instrument panel illumination. When pressing the illumination control button, the interior switch illumination intensity is also adjusted.
  • Page 89: Gauges And Meters

    Instrument Cluster Gauges and Meters Speedometer Normal mode MPH, km/h OOSN041018L The brightness of the instrument panel can also be adjusted from the OCN7N041131N infotainment system screen. When Engine Start/Stop button is in the ON N mode Brightness’. When ‘Auto-brightness’ is selected from the Settings menu, the brightness is automatically adjusted.
  • Page 90: Tachometer

    Tachometer Engine coolant temperature gauge Normal mode Normal mode OCN7040007 OCN7040009 N mode N mode OCN7N041133N OOSN041020N The tachometer indicates the This gauge indicates the temperature approximate number of engine of the engine coolant when the Engine revolutions per minute (RPM). Start/Stop button is in the ON position.
  • Page 91: Fuel Gauge

    Instrument Cluster Fuel gauge WARNING Normal mode Running out of fuel can expose vehicle occupants to danger. You must stop and obtain additional fuel as soon as possible after the warning light comes on or when the gauge indicator comes close to the “E (Empty) ”...
  • Page 92: Outside Temperature Gauge

    Outside temperature gauge Odometer Normal mode Normal mode OCN7N041129N OCN7040015N N mode N mode OCN7N041124N OOSN041022N The odometer indicates the total This gauge indicates the current outside distance that the vehicle has been air temperatures by 1°F (1°C). driven and should be used to determine Note that the temperature indicated when periodic maintenance should be on the LCD display may not change...
  • Page 93: Distance To Empty

    Instrument Cluster Distance to empty CUSTOM mode settings Normal mode N mode OOSN041056N OCN7N041136N The main settings of CUSTOM mode is N mode displayed at the bottom of the cluster. The CUSTOM mode can be set on the infotainment system. Information For more details on the CUSTOM mode, refer to “Drive Mode Integrated Control...
  • Page 94: Transmission Shift Indicator

    Transmission Shift Indicator Normal mode Normal mode OOSN041046N N mode OOSN041045N N mode OOSN041047N This indicator displays which shift lever OCN7N041138N position is selected. This indicator displays which shift lever position is selected. Park : P Reverse : R Neutral : N Drive : D1, D2, D3, D4, D5, D6,D7, D8 Manual shift mode : 1, 2, 3, 4, 5, 6, 7, 8 4-11...
  • Page 95: Warning And Indicator Lights

    If a brake fluid leak is found, or In this case, have the vehicle if the warning light remains on, or if inspected by an authorized HYUNDAI the brakes do not operate properly, do dealer. not drive the vehicle. Have the vehicle inspected by an authorized HYUNDAI dealer.
  • Page 96: Anti-Lock Brake System (Abs) Warning Light

    ABS. braking and stop the vehicle as soon as it If this occurs, have the vehicle is safe to do so. inspected by an authorized HYUNDAI dealer. WARNING Electronic Brake Force Parking Brake & Brake Fluid warning...
  • Page 97: Electric Power Steering (Eps) Warning Light

    If this occurs, avoid high speed driving the electric power steering. and abrupt braking. If this occurs, have the vehicle Have the vehicle inspected by an inspected by an authorized HYUNDAI authorized HYUNDAI dealer as soon as dealer. possible. Charging system warning NOTICE light...
  • Page 98: Engine Oil Pressure Warning Light

    F (Full) mark on the vehicle inspected by an authorized the dipstick. HYUNDAI dealer as soon as possible. Continued driving with the warning light on may cause engine failure. Information...
  • Page 99: Low Fuel Level Warning Light

    TPMS. then goes off. If this occurs, have the vehicle inspected Whenever there is a malfunction with by an authorized HYUNDAI dealer as either the emission control system or soon as possible. the engine or the vehicle powertrain. For more details, refer to “Tire Pressure If this occurs, have the vehicle Monitoring System (TPMS)”...
  • Page 100: Forward Safety Warning Light

    Whenever there is a malfunction with Forward Collision-Avoidance Assist. the LED headlight. If this occurs, have the vehicle inspected If this occurs, have the vehicle by an authorized HYUNDAI dealer. inspected by an authorized HYUNDAI dealer. For more details, refer to “Forward Collision-Avoidance Assist (FCA)”...
  • Page 101: Electronic Stability Control (Esc) Indicator Light

    ESC system. - The indicator light goes off after If this occurs, have the vehicle starting the engine. inspected by an authorized HYUNDAI dealer. This indicator light blinks for a few seconds: This indicator light blinks: When the smart key is not in the While ESC is operating.
  • Page 102: Downhill Brake Control (Dbc) Indicator Light

    Whenever there is a malfunction with HYUNDAI dealer. Downhill Brake Control system. If this occurs, have the vehicle inspected by an authorized HYUNDAI dealer. High beam indicator light For more details, refer to "Downhill Brake Control (DBC)“ section in chapter...
  • Page 103: Low Beam Indicator Light

    Instrument Cluster Low Beam Indicator Light Cruise Indicator Light This indicator light illuminates: This indicator light illuminates: When the headlamps are on. When Cruise Control is enabled. For more details, refer to “Cruise Control (CC)” in chapter 7. Light ON Indicator Light SPORT Mode Indicator Light (if equipped) This indicator light illuminates:...
  • Page 104: Master Warning Light

    Master warning light N Mode Indicator Light This warning light illuminates: This indicator light illuminates: When there is a malfunction in operation When you select “N” mode as drive in any of the following systems: mode. - Forward Collision-Avoidance Assist For more details, refer to “Drive Mode malfunction (if equipped) Integrated Control System”...
  • Page 105: Lcd Display Messages

    This warning message is displayed if the time you press the Engine Start/Stop steering wheel does not lock normally button, have the vehicle inspected by an while the Engine Start/Stop button authorized HYUNDAI dealer. changes to the OFF position. 4-22...
  • Page 106: Press Start Button With Key

    This message is displayed if the brake have the vehicle inspected by an switch fuse is disconnected. authorized HYUNDAI dealer. You need to replace the fuse with a new one before starting the engine. If that is not possible, you can start the...
  • Page 107: Door, Hood, Liftgate Open Indicator

    Instrument Cluster Door, Hood, Liftgate open indicator Low tire pressure OOSN041011L OCN7040026L This warning is displayed if any door or This warning message is displayed if the hood or liftgate is left open. The warning tire pressure is low. The corresponding will indicate which door is open in the tire on the vehicle will be illuminated.
  • Page 108: Lights

    Lights Heated Steering Wheel turned off (if equipped) This message is displayed if you turn off the heated steering wheel. For more details, refer to “Heated Steering Wheel” in chapter 5. Low washer fluid (if equipped) This message is displayed if the washer fluid level in the reservoir is nearly empty.
  • Page 109: Engine Overheated / Engine Has Overheated

    Lane Keeping replaced. Assist. Have the vehicle inspected by an Make sure to replace the burned out authorized HYUNDAI dealer. bulb with a new one of the same wattage For more details, refer to “Lane Keeping rating.
  • Page 110: Check Driver Attention Warning System

    This warning message is displayed if there is a problem with Driver Attention Warning. Have the vehicle inspected by an authorized HYUNDAI dealer. For more details, refer to “Driver Attention Warning (DAW)” in chapter 7. Check High Beam Assist (HBA)
  • Page 111: Instrument Cluster

    Instrument Cluster LCD DISPLAY LCD Display Control OOSN041013N The LCD display modes can be changed by using the control buttons. Switch Function MODE button for changing modes MOVE switch for changing items SELECT/RESET button for setting or resetting the selected item 4-28...
  • Page 112: View Modes

    View Modes View modes Symbol Explanation This mode displays the state of : - Lane Keeping Assist - Driver Attention Warning Driving Assist For more information, refer to "Lane Keeping Assist (LKA) ”, “Driver Attention Warning (DAW) ” in chapter 7. This mode displays driving information such as the Trip tripmeter, fuel economy, etc.
  • Page 113: Trip Computer Mode

    Instrument Cluster Trip computer mode Driving Assist mode OJX1040042E OOSN041025N The trip computer mode displays information related to vehicle driving This mode displays the state of Lane parameters including fuel economy, Keeping Assist. tripmeter information and vehicle speed. For more details, refer to each function For more information, refer to "Trip information in chapter 7.
  • Page 114: Sport View

    Sport view OBC3N040026 OOSN041026N Oil Temp./Engine Temp. This mode displays information related to your engine such as oil temperature (1) and engine temperature (2). OBC3N040027 Lap timer (1) Best lap (2) Current lap To start (A) OBC3N040025 Press the OK button shortly on the Turbo/Torque steering wheel.
  • Page 115 Instrument Cluster NOTICE If the N1(N2) button is set to '(7) Start lap timer', the N2(N1) button is automatically set to '(8) Stop & Reset lap timer' from the infotainment system. Then the driver can operate lap timer using the N1/N2 buttons as the one pair. For more details, please refer to the infotainment system manual separately supplied.
  • Page 116: Master Warning Group

    Master warning group OCN7040026L Tire Pressure OIG059097L This mode displays information related to This warning light informs the driver the Tire Pressure. following situations. For more details, refer to "Tire Pressure - Forward Collision-Avoidance Assist Monitoring System (TPMS)" in chapter malfunction (if equipped) - Blind-Spot Collision Warning malfunction (if equipped)
  • Page 117: Trip Computer

    Instrument Cluster Trip Computer The trip computer is a microcomputer- controlled driver information system that displays information related to driving. Information Some driving information stored in the trip computer (for example Average Vehicle Speed) resets if the battery is disconnected. OOSN041013N To change the trip mode, toggle the Trip modes...
  • Page 118 OTMA040012 OTMA040016 Drive info Accumulated info Trip distance (1), average fuel economy Accumulated trip distance (1), average (2), and total driving time (3) are fuel economy (2), and total driving time displayed. (3) are displayed. The information is combined for each The information is accumulated starting ignition cycle.
  • Page 119: Setting Your Vehicle

    Instrument Cluster Vehicle Settings in the infotainment Setting Your Vehicle system provides user options for a variety of settings including door lock/ unlock features, convenience features, driver assistance settings, etc. Vehicle Settings menu - Driver Assistance - Drive Mode - Cluster - Climate - Lights OOSN041010L...
  • Page 120: Convenient Features

    5. Convenient Features Accessing Your Vehicle ..................5-4 Smart Key ........................5-4 Immobilizer System ....................5-10 Hyundai Digital Key ....................5-11 Door Locks ....................... 5-28 Operating Door Locks From Outside the Vehicle ............5-28 Operating Door Locks From Inside the Vehicle............5-29 Auto Door Lock/Unlock Features ................5-30 Child-Protector Rear Door Locks ................5-31...
  • Page 121 Wipers and Washers ..................5-70 Windshield Wipers .....................5-70 Front Windshield Washers ..................5-72 Rear Window Wiper and Washer ................5-73 Automatic Climate Control System ..............5-74 Automatic Heating and Air Conditioning ..............5-75 Manual Heating and Air Conditioning ..............5-75 System Operation ....................... 5-79 System Maintenance ....................
  • Page 122 5. Convenient Features Infotainment System ..................5-101 USB Port ........................5-101 Antenna ........................5-101 Steering Wheel Remote Controls ................5-102 Bluetooth® Wireless Technology ................5-103 Voice Recognition ....................5-103 Infotainment System ....................5-103 How Vehicle Radio Works ..................5-104...
  • Page 123: Accessing Your Vehicle

    Smart Key Locking your vehicle (Touch sensor type) OOS050026N Your HYUNDAI uses a smart key, which OOS050021K you can use to lock or unlock a door (and 1. Close all of the doors, the hood and liftgate) and even start the engine even the liftgate.
  • Page 124 Even though you press the outside Unlocking your vehicle (Touch door handle button, the doors will not sensor type, When the Two Press lock and the chime will sound for three Unlock feature is off) seconds if any of the following occur: The Smart Key is in the vehicle.
  • Page 125 Convenient Features Unlocking your vehicle (Touch Two Press Unlock Feature sensor type, When the Two Press The priority for unlocking the driver door Unlock feature is on) only, or unlocking all the doors with one press may be adjusted in the Settings To unlock your vehicle using the door menu in the infotainment system screen.
  • Page 126 Remotely starting vehicle Panic button You can start the vehicle using the Press and hold the Panic button (4) for Remote Start button on the smart key. more than one second. The horn sounds and hazard warning lights blink for about To start the vehicle remotely: 30 seconds.
  • Page 127 To remove the mechanical key from the remaining key to your authorized smart key FOB: HYUNDAI dealer or tow the vehicle, if necessary. Smart key precautions The smart key may not work if any of the...
  • Page 128 If you suspect your smart key might have sustained some damage, or you feel your smart key is not working correctly, contact an authorized HYUNDAI dealer. Information An inappropriately disposed battery can be harmful to the environment and human health.
  • Page 129: Immobilizer System

    If the system repeatedly does not Operation is subject to the following three recognize the coding of the key, contact conditions: your HYUNDAI dealer. 1. This device may not cause harmful interference. Do not attempt to alter this system 2. This device must accept any or add other devices to it.
  • Page 130: Hyundai Digital Key

    Digital key (smartphone) NFC function Digital Key Application You can use the Digital Key NFC (Near To use Hyundai Digital Key mobile app, Field Communication) function after turn you should install Hyundai digital key your smartphone NFC settings on. And application.
  • Page 131 Digital key app and delete the previous saved key in your smartphone before save. ODN8A059129 ODN8A059240 Hyundai Digital Key (Smartphone) Pairing 1. Turn the vehicle on with the Smart key and make sure to keep the smart key inside the vehicle during digital key registration.
  • Page 132 6. Remove the smartphone from the pad and complete the saving process. ODN8A059130 Hyundai Digital Key (Smartphone Key) Deletion 1. Turn the vehicle on with the Smart key and make sure to keep the smart key inside the vehicle during delete OOSN051021L process.
  • Page 133 Convenient Features 3. Once the digital key delete is Set up main vehicle complete, a message will be shown You can manage multiple digital keys on the infotainment screen or cluster. from the Digital key app. From the list of 4.
  • Page 134 Note that you cannot lock your vehicle when you contact NFC antenna in the smartphone to the door handle pad if any of the following occurs: The Proximity / Smart Key is in the vehicle. The Engine Start/Stop button is in ACC or ON position.
  • Page 135 Note that you cannot lock your vehicle using the Hyundai digital key app if any of the following occurs: The Engine Start/Stop button is in ACC or ON position.
  • Page 136 Bluetooth connection or and the vehicle is off, press the Door performance degradation of the Lock button in the Hyundai Digital digital key. Key app then press the Remote Start If multiple users operate the remote button within 4 seconds.
  • Page 137 The digital key application displays If you change your smartphone or delete the vehicle information such as the Hyundai Digital Key App, please refer driving or door conditions through the to the following to set up your Digital communication with the vehicle.
  • Page 138 You should remove your NFC card of the digital key on the interior authentication pad after turning on the engine. Hyundai digital key app may not work properly when the NFC or Bluetooth communication between smartphone and car is not good.
  • Page 139 - Basic and necessary functions of work if any of the following occurs: the smartphone manufacturer are - Hyundai digital key app on the operating. (General call, urgent smartphone is deleted. (Required call, audio or NFC payment) to reinstall the app) - Wireless earphone is operating.
  • Page 140 Once the card key registration mode Digital key (Card key) save is activated, the process should be completed within 5 minutes. After 1. Install Hyundai digital key app in then, you should reactivate once main user’s smartphone and register again for registration.
  • Page 141 Convenient Features If there is no saved digital key(card key), [Delete] menu will not be activated. To delete the saved digital key (card key), the smart key must be exist inside the vehicle. The deleted digital key (card key) can be re-registered before registering a new digital key (card key).
  • Page 142 If the digital key (card key) does not work, please detach the key around 4 inches (0.1 m) from the handle authentication pad and retry to contact. The card key may be damaged by the impact. It would not work properly if the key is damaged.
  • Page 143 Convenient Features Start-up with Card key After placing your registered card key onto the interior authentication pad (wireless charger), step on the brake and press the Engine Start/Stop button. WARNING If you do not place the digital key (card key) onto the center of the interior authentication pad (wireless ODN8A059133 charger) exactly, the card key may...
  • Page 144 Personalized profile and vehicle Information settings For the digital key disable, the smart key Connect the registered digital key with must be exist inside the car. For the digital personalized profile. Then in case you key enable, the smart key is not needed. lock or unlock the door with the digital key NFC function or unlock the door CAUTION...
  • Page 145 Convenient Features PRECAUTION for vehicle profile link and Vehicle personalization operation unlink The personalization function linked with When you link or unlink the profile of digital key works as following conditions: digital key, you should be careful of the Contact the driver’s door handle with following.
  • Page 146 Vehicle personalization with digital key The available personalization function in the vehicle is as follows. System Personalization Item Lamp Blink number of one-touch signal lamps Information display on the cluster, Voice volume, Cluster Welcome sound, Theme selection Seat/Mirror Door Automatic door lock/unlock, Two Press Unlock Temperature unit, shut off outside air (interlocked Air conditioning with washer fluid), Automatic ventilation, Auto...
  • Page 147: Door Locks

    Refer to the Hyundai Digital Key section for other options. OOSN051037N Lock Touch the touch sensor on the front...
  • Page 148: Operating Door Locks From Inside The Vehicle

    Operating Door Locks From With the central door lock/unlock switch Inside the Vehicle With the door lock button OOS047004 When pressing the ( ) portion (1) on the OOS047003 switch, all vehicle doors will lock. To unlock a door, push the door lock If any door is opened, the doors will button (1) to the “Unlock”...
  • Page 149: Auto Door Lock/Unlock Features

    Convenient Features Auto Door Lock/Unlock Features WARNING Your vehicle is equipped with features Do not leave children or animals that will automatically lock or unlock unattended in your vehicle. An enclosed your vehicle based on settings you select vehicle can become extremely hot, in the infotainment system screen.
  • Page 150: Child-Protector Rear Door Locks

    Child-Protector Rear Door Locks Rear Occupant Alert (ROA) This function prevents the driver from leaving a passenger in the rear seats. If your vehicle is equipped with additional navigation, please refer to the infotainment system manual separately supplied. OOS047005N The child safety lock is provided to help prevent children seated in the rear from accidentally opening the rear doors.
  • Page 151 - A door is opened without using the will be activated. smart key , Hyundai Digital key, or If the vehicle is not disarmed with the Hyundai BlueLink service. smart key, open the doors by using the...
  • Page 152: Steering Wheel

    When the battery voltage is low, you vehicle operation, have the system might have to put more steering effort. checked by an authorized HYUNDAI However, it is a temporary condition so dealer. that it will return to normal condition after charging the battery.
  • Page 153: Tilt / Telescopic Steering

    Convenient Features Tilt / Telescopic Steering When adjusting the steering wheel to a comfortable position, adjust the steering wheel so that it points toward your chest, not toward your face. Make sure you can see the instrument cluster warning lights and gauges.
  • Page 154: Horn

    Horn OOSN051007L To sound the horn, press the area indicated by the horn symbol on your steering wheel (see illustration). The horn will operate only when this area is pressed. NOTICE Do not strike the horn severely to operate it, or hit it with your fist. Do not press on the horn with a sharp-pointed object.
  • Page 155: Inside Rearview Mirror

    Convenient Features Inside Rearview Mirror Day/night rearview mirror (if equipped) Before driving your vehicle, check to see that your inside rearview mirror is properly positioned. Adjust the rearview mirror so that the view through the rear window is properly centered. WARNING Make sure your line of sight is not obstructed.
  • Page 156 Blue Link® center Electrochromic mirror (ECM) with HomeLink® system and Blue Link® (if For USA equipped) HomeLink Indicator OOS050133N For Canada Telematics buttons HomeLink Button OOS047093N Your vehicle may be equipped with a Gentex Automatic-Dimming Mirror with a Z-Nav™ Electronic Compass Display and an Integrated HomeLink®...
  • Page 157 Convenient Features Automatic-Dimming Night Vision Safety™ WARNING (NVS®) Mirror (if equipped) Before programming HomeLink® to a The NVS® Mirror automatically reduces garage door opener or gate operator, glare by monitoring light levels in the make sure people and objects are out front and the rear of the vehicle.
  • Page 158 1) Programming Preparation 1. Programming HomeLink® The following steps show how to program HomeLink. If you have any questions or are having difficulty programming your HomeLink buttons, refer to the HomeLink website or call the HomeLink customer support tollfree number. Do this, before going back to the dealer who sold you the car.
  • Page 159 Convenient Features 2) Programming a New HomeLink® OOS040476N 2. Position the garage door opener OOS040095N remote 1 – 3 inches (2 – 8cm) away 1. Press and release the HomeLink from the HoleLink buttons. button (1), (2) or (3), you would like 3.
  • Page 160 6. At the garage door opener motor, 3) Two-Way Communication (security gate motor, etc.) locate the Programming (For select garage door “Learn”, “Smart”, “Set” or “Program” openers) button. This can usually be found If your garage door opener has the where the hanging antenna wire is ‘myQ’...
  • Page 161 Convenient Features 1. In your vehicle, press and hold the 4) Canadian Programming programmed HomeLink button for 2 Canadian radio-frequency laws require seconds, then release. Confirm that transmitter remote signals to “time- the garage door is moving. AFTER it out” (or quit) after a couple seconds of stops, you will have one minute to transmission, which may not be long complete the following steps:...
  • Page 162 2) Two-Way Communication Display 2. Operating HomeLink® Behavior 1) Operating HomeLink® OOS047099N OOS040095N 1. Press and release one of the 1. Press and release the desired programmed HomeLink buttons (1, 2 programmed HomeLink button (1, 2 or 3). or 3). Information The HomeLink indicator (7) should light green, solid or flashing, and your...
  • Page 163 Convenient Features If the indicator (4) flashes in Orange, 3) Recalling Garage Door Status it indicates that the garage door is HomeLink mirror with Two-Way “Closing”. Communication provides a way to view The indicator (4) turns solid green the last stored message from the garage once the garage door has closed.
  • Page 164 2) The following instructions will erase 3. Erasing HomeLink® Buttons ALL HomeLink® programming from 1) Erasing and Reprogramming a Single ALL buttons: HomeLink® Button: 1. Press and hold the desired HomeLink button you want to re-program. DO NOT release the button. 2.
  • Page 165 Convenient Features FCC (USA) and ISED (Canada) FCC (Htats-Unis) et ISED (Canada) This device complies with FCC rules Cet appareil est conforme aux part 15 and Innovation, Science, and règlements de la FCC, section 15, et Economic Development Canada RSS- au CNR-210 d’Innovation, Sciences et 210.
  • Page 166 HomeLink 5 Programing Flow Chart OOS040475N 5-47...
  • Page 167: Side View Mirrors

    Convenient Features Side View Mirrors WARNING Do not adjust or fold the side view mirrors while driving. This may cause loss of vehicle control resulting in an accident. NOTICE Do not scrape ice off the mirror face; this may damage the surface of the glass.
  • Page 168 Adjusting the side view mirrors Folding the side view mirror OOS047013 OOS047014 1. Move the lever (1) either to the L (left To fold the side view mirror, grasp the side) or R (right side) to select the side housing of the mirror and then fold it view mirror you would like to adjust.
  • Page 169: Windows

    Convenient Features WINDOWS OOSN051034N (1) Driver’s door power window switch (5) Window opening and closing (2) Front passenger’s door power (6) Automatic power window window switch (7) Power window lock switch (3) Rear door (left) power window switch (4) Rear door (right) power window switch 5-50...
  • Page 170: Power Windows

    Power Windows Window opening and closing The Engine Start/Stop button must be in the ON position to be able to raise or lower the windows. Each door has a Power Window switch to control that door’s window. The driver has a Power Window Lock switch which can block the operation of passenger windows.
  • Page 171 If the power windows do not operate will stop upward movement then lower properly after resetting, have the system approximately 1 in. (2.5 cm). checked by an authorized HYUNDAI If the power window switch is pulled dealer. up continuously again within 5 seconds...
  • Page 172 Power window lock button Information The automatic reverse feature is only active when the “Auto Up” feature is used by fully pulling up the switch to the second detent. NOTICE Do not install any accessories on the windows. The automatic reverse feature may not operate.
  • Page 173: Exterior Features

    Convenient Features EXTERIOR FEATURES Hood Opening the hood OOS047026 4. Pull out the support rod and hold the hood open with the support rod (1). OOSN051009L 1. Park the vehicle and set the parking WARNING brake. 2. Pull the release lever to unlatch the When handling the support rod, hood.
  • Page 174: Liftgate

    Closing the hood Liftgate Opening the liftgate 1. Before closing the hood, check in and around the engine compartment to ensure the following: - Any tools or other loose objects are removed from the engine room area or hood opening area - All glove, rags, or other combustible material is removed from the engine compartment...
  • Page 175 Convenient Features Closing the liftgate WARNING OOSN051012N OOSN051103N Lower the liftgate lid and press down Do not hold the part (gas lifter) that until it locks. To be sure the liftgate lid is supports the liftgate. Be aware that securely fastened, always check by trying the deformation of the part may cause to pull it up again without pressing the vehicle damage and a risk of injury.
  • Page 176: Fuel Filler Door

    Emergency liftgate safety release Fuel Filler Door Opening the fuel filler door OOSN051013N Your vehicle is equipped with an OOSN051014L emergency liftgate safety release lever The fuel filler door is opened from inside located on the bottom of the liftgate the vehicle using the fuel filler door inside the vehicle.
  • Page 177 Convenient Features Do not get back into a vehicle Information once you have begun refueling. If the fuel filler door does not open You can generate a buildup of because ice has formed around it, tap static electricity by touching, lightly or push on the door to break the rubbing or sliding against any item ice and release the door.
  • Page 178 If the fuel filler cap requires replacement, use only a genuine HYUNDAI cap or the equivalent specified for your vehicle. An incorrect fuel filler cap can result in a serious malfunction of the fuel system or emission control system.
  • Page 179: Lighting

    Convenient Features LIGHTING Exterior Lights Lighting control To operate the lights, turn the knob at the end of the control lever to one of the following positions: OOS047050N AUTO headlamp position The position lamp and headlamp will be turned ON or OFF automatically depending on the amount of daylight as measured by the ambient light sensor (1) at the upper end of the windshield glass.
  • Page 180 High beam operation OOS047405N Position lamp position ( OOS047407N The position lamp, license plate lamp To turn on the high beam headlamp, and instrument panel lamp are turned push the lever away from you. The lever will return to its original position. The high beam indicator will light when the headlamp high beams are switched To turn off the high beam headlamp, pull...
  • Page 181 Convenient Features Turn signals and lane change signals OOS047408N To flash the high beam headlamp, pull OOS047410N the lever towards you, then release the To signal a turn, push down on the lever lever. The high beams will remain ON as for a left turn or up for a right turn in long as you hold the lever towards you.
  • Page 182 Battery saver function Headlamp delay function (if equipped) The purpose of this feature is to prevent the battery from being discharged. If the Engine Start/Stop button is in the The system automatically turns off the ACC position or the OFF position with position lamp when the driver turns the the headlamps ON, the headlamps (and/ vehicle off and opens the driver-side...
  • Page 183: Interior Lights

    Convenient Features Interior Lights Front lamps WARNING Do not use the interior lights when driving in the dark. The interior lights may obscure your view and cause an accident. NOTICE Do not use the interior lights for extended periods when the vehicle is OOS047052 turned off or the battery will discharge.
  • Page 184 Rear lamps Vanity mirror lamp OOS047321 OCN7050058 Rear room lamp switch : Push the switch to turn the light on or off. : The lamp will turn on if this Press this button to turn the room lamp on and off. button is pressed.
  • Page 185: Luggage Compartment Lamp

    Convenient Features Luggage Compartment Lamp Welcome System Welcome light Interior lamp When the interior lamp switch is in the DOOR position and all doors are closed and locked, the room lamp will come on for 30 seconds if any of the below is performed.
  • Page 186: High Beam Assist Setting

    High Beam Assist Setting Setting features OOS047409N High Beam Assist will automatically adjust the headlamp range (switches OOSN051031L between high beam and low beam) depending on the brightness of detected Beam Assist’ from the Settings menu to vehicles and certain road conditions. turn on High Beam Assist and deselect to turn off the function.
  • Page 187: High Beam Assist Operation

    Convenient Features High Beam Assist Operation When High Beam Assist is operating, high beam switches to low beam if Display and control any of the following conditions occur: After selecting ‘High Beam Assist’ - When the headlamp of an in the Settings menu, High Beam oncoming vehicle is detected.
  • Page 188: High Beam Assist Malfunction And Limitations

    Collision-Avoidance Assist (FCA)” section illuminate on the cluster. Have the in chapter 7. vehicle inspected by an authorized HYUNDAI dealer. WARNING Limitations of High Beam Assist At times, High Beam Assist may not High Beam Assist may not work properly work properly.
  • Page 189: Wipers And Washers

    Convenient Features WIPERS AND WASHERS Windshield Wipers Front windshield wiper/washer Operates as follows when the Engine Start/Stop button is in the ON position. MIST : For a single wiping cycle, move the lever upward and release it. The wipers will operate continuously if the lever is held in this position.
  • Page 190 AUTO (Automatic) control WARNING (if equipped) To avoid personal injury from the windshield wipers, when the engine is running and the windshield wiper switch is placed in the AUTO mode: Do not touch the upper end of the windshield glass facing the rain sensor.
  • Page 191: Front Windshield Washers

    Convenient Features Front Windshield Washers WARNING When the outside temperature is below freezing, ALWAYS warm the windshield using the defroster to help prevent the washer fluid from freezing on the windshield and obscuring your vision which could result in an accident and serious injury or death.
  • Page 192: Rear Window Wiper And Washer

    Rear Window Wiper and Washer Auto rear wiper (if equipped) The rear wiper will operate while the vehicle is in reverse with the front wiper ON by selecting the function from the Settings menu on the LCD display. Select: Rear Wiper (in R) OTLE045165 The rear window wiper and washer switch is located at the end of the wiper...
  • Page 193 Convenient Features OOS050103L 1. Temperature control knob 6. Front windshield defroster button 2. Fan speed control knob 7. Mode selection button 3. AUTO (automatic control) button 8. Rear window defroster button 4. Air conditioning button 9. Air intake control button 5.
  • Page 194: Automatic Heating And Air Conditioning

    Automatic Heating and Air Conditioning The Automatic Climate Control System is controlled by setting the desired temperature. 1. Press the AUTO button. (3) The modes, fan speeds, air intake and air-conditioning will be controlled automatically by the temperature setting you select. OOSH059075L 2.
  • Page 195 Convenient Features Mode selection The actual shape of air conditioner may differ from the illustration. OOSN051100L The mode selection button controls the direction of the air flow through the ventilation system. 5-76...
  • Page 196 Face-Level (B, D) Air flow is directed toward the upper body and face. Additionally, each outlet can be controlled to direct the air discharged from the outlet. Bi-Level (B, C, D, E) Air flow is directed towards the face and OOSN051101L the floor.
  • Page 197 Convenient Features Air intake control (9) Information This is used to select the outside (fresh) Using the system in the fresh air position is air position or recirculated air position. recommended. To change the air intake control position, Prolonged operation of the heater in the push the control button.
  • Page 198: System Operation

    Fan speed control (2) System Operation Ventilation The fan speed can be set as desired by turning the fan speed control knob. 1. Set the mode to the position. More air is delivered with higher fan 2. Set the air intake control to the speeds.
  • Page 199 Convenient Features NOTICE Air conditioning HYUNDAI Air Conditioning Systems are When using the air conditioning filled with R-1234yf refrigerant. system, monitor the temperature gauge closely while driving up 1. Start the engine. Push the air hills or in heavy traffic when conditioning button.
  • Page 200: System Maintenance

    Have the cabin air filter replaced by an that of the windshield could cause authorized HYUNDAI dealer according to the outer surface of the windshield to the maintenance schedule. If the vehicle fog up, causing loss of visibility. In this...
  • Page 201 Overfilling also reduces the performance of the air conditioning system. Therefore, if abnormal operation is found, have the system inspected by an authorized HYUNDAI dealer. OOSN051019N NOTICE Air Conditioning refrigerant label It is important that the correct type and You can find out which air conditioning amount of oil and refrigerant is used.
  • Page 202: Windshield Defrosting And Defogging

    WINDSHIELD DEFROSTING AND DEFOGGING Automatic Climate Control WARNING System Windshield heating To defog inside windshield Do not use the position during cooling operation in extremely humid weather. The difference between the temperature of the outside air and that of the windshield could cause the outer surface of the windshield to fog up, causing loss of visibility could cause an accident resulting in serious injury...
  • Page 203: Auto Defogging System (Only For Automatic Climate Control System)

    Convenient Features To defrost outside windshield Auto Defogging System (only for automatic climate control system, if equipped) Auto defogging help reduce the possibility of fogging up the inside of the windshield by automatically sensing the moisture on inside the windshield. The auto defogging system operates when the heater or air conditioning is on.
  • Page 204 To cancel or reset the Auto Defogging When the Auto Defogging System System operates, the indicator will illuminate. Press the front windshield defroster button for 3 seconds when the Engine Strat/Stop button is in the ON position. If a high amount of humidity is detected When the Auto Defogging System is in the vehicle, the Auto Defogging canceled, the ADS OFF symbol will blink...
  • Page 205: Defroster

    Convenient Features Defroster Rear window defroster Automatic climate control system NOTICE To prevent damage to the rear window defroster conducting elements bonded to the inside surface of the rear window, never use sharp instruments or window cleaners containing abrasives to clean the window.
  • Page 206: Automatic Ventilation

    Automatic Ventilation Inside Air Circulation While (if equipped) Operating the Washer Fluid To increase cabin air quality and reduce When the washer liquid is sprayed, it is windscreen misting, air recirculation changed and maintained for a certain mode switches off automatically after period of time to prevent the smell of about 5 minutes, depending on outside washer liquid from entering the room.
  • Page 207: Center Console Storage

    Convenient Features Center Console Storage WARNING Never store cigarette lighters, propane cylinders, or other flammable/explosive materials in the vehicle. These items may catch fire and/or explode if the vehicle is exposed to hot temperatures for extended periods. WARNING ALWAYS keep the storage compartment covers closed securely while driving.
  • Page 208: Sunglass Holder

    Sunglass Holder Multi Box OOS047058 OOSN051105L To open: Small things may be placed in the multi box. Push and release the cover and the holder will slowly open. Place your sunglasses in the compartment door WARNING with the lenses facing out. Do not keep objects that can be thrown To close: from the multi box and severely injure...
  • Page 209: Luggage Tray

    Convenient Features Luggage Tray (if equipped) To increase luggage space OOS047320 OOS047070 You can place a first aid kit, a reflector triangle (front tray), tools, etc. in the box for easy access. Grasp the handle on the top of the cover and lift it.
  • Page 210: Interior Features

    INTERIOR FEATURES Cup Holder WARNING Avoid abrupt starting and braking when the cup holder is in use to prevent spilling your drink. If hot liquid spills, you could be burned. Such a burn to the driver could cause loss of vehicle control resulting in an accident.
  • Page 211: Sunvisor

    Convenient Features Sunvisor Power outlet OOS047062 OOSN051020N To use the sunvisor, pull it downward. The power outlet is designed to provide power for mobile telephones or other To use the sunvisor to block the sun devices designed to operate with vehicle from the side window, pull it downward, electrical systems.
  • Page 212: Usb Charger

    USB Charger CAUTION To prevent damage to the power outlets: Use the power outlet only when the engine is running and remove the accessory plug after use. Using the accessory plug for prolonged periods of time with the engine off could cause the battery to discharge.
  • Page 213: Wireless Smart Phone Charging System

    Convenient Features Wireless Smart Phone Charging To charge a cellular phone System The wireless smart phone charging system charges only the Qi-enabled smart phones ( ). Read the label on the smart phone accessory cover or visit your smart phone manufacturer’s website to check whether your smart phone supports the Qi technology.
  • Page 214 The wireless charging process may Information temporarily stop when there is For some manufacturers’ cellular phones, any metallic item, such as a coin, the system may not warn you even though between the wireless smart phone the cellular phone is left on the wireless charging system and smart phone.
  • Page 215: Clock

    Convenient Features Clock Information If the Engine Start/Stop button is in the WARNING OFF position, the charging also stops. Do not attempt to adjust the clock while driving. Doing so may result in Information distracted driving which may lead to This device complies with part 15 of the an accident involving personal injury or FCC Rules.
  • Page 216: Clothes Hanger

    Clothes Hanger Floor Mat Anchor(s) OOS047065 OOSN051022L These hooks are not designed to hold ALWAYS use the Floor Mat Anchors to large or heavy items. attach the front floor mats to the vehicle. The anchors on the front floor carpet keep the floor mats from sliding forward.
  • Page 217: Luggage Net Holder

    If necessary, contact your authorized mat). Only a single floor mat should HYUNDAI dealer to obtain a luggage net. be installed in each position. IMPORTANT - Your vehicle was manufactured with driver’s side floor...
  • Page 218: Cargo Area Cover

    Cargo Area Cover OOSN051039N Use the cover to hide items stored in the cargo area. The cargo area cover will lift when the liftgate is opened. Disconnect the strap (1) from the holder if you want to return the cover to the original position.
  • Page 219: Exterior Features

    The roof side rails crossbars are an the roof side rails. Avoid sudden accessory and are available at your starts, braking, sharp turns, abrupt HYUNDAI dealer. maneuvers or high speeds that may result in loss of vehicle control or rollover resulting in an accident.
  • Page 220: Usb Port

    NOTICE Antenna Shark fin antenna If you install an aftermarket HID head lamp, your vehicle’s audio and electronic devices may not function properly. Prevent chemicals such as perfume, cosmetic oil, sun cream, hand cleaner, and air freshener from contacting the interior parts because they may cause damage or discoloration.
  • Page 221: Steering Wheel Remote Controls

    Convenient Features Steering Wheel Remote Controls VOLUME ( + / - ) (1) Move the VOLUME toggle switch up to increase volume. Move the VOLUME toggle switch down to decrease volume. SEEK/PRESET ( ) (2) If the SEEK/PRESET toggle switch is moved up or down and held for 0.8 seconds or more, it will function in the following modes.
  • Page 222: Bluetooth® Wireless Technology

    Bluetooth® Wireless Technology Voice Recognition OOSN051027L OOSN051028L You can operate the voice recognition function through voice commands. For detailed information, refer to the separately supplied infotainment system manual. Infotainment System Detailed information for the infotainment system is described in a separately supplied manual.
  • Page 223: How Vehicle Radio Works

    Convenient Features How Vehicle Radio Works AM (MW, LW) reception FM reception OJF045309L AM broadcasts can be received at OJF045308L greater distances than FM broadcasts. AM and FM radio signals are broadcast This is because AM radio waves are from transmitter towers located around transmitted at low frequencies.
  • Page 224 FM radio station Flutter/Static - Weak FM signals or large obstructions between the transmitter and your radio can disturb the signal causing static or fluttering noises to occur. Reducing the treble level may lessen this effect until the disturbance clears. OJF045310L FM broadcasts are transmitted at high frequencies and do not bend to follow...
  • Page 225 Bluetooth SIG, Inc. and any use of such from the audio system. This does not marks by HYUNDAI is under license. mean that something is wrong with the Other trademarks and trade names are audio equipment.
  • Page 226: Driving Your Vehicle

    6. Driving your vehicle Before Driving ....................6-4 Before Entering the Vehicle ..................6-4 Before Starting ......................6-4 Engine Start/Stop button ................. 6-5 Engine Start/Stop Button Positions ................6-6 Starting the Engine ...................... 6-7 Turning Off the Engine ....................6-8 Remote Start ........................
  • Page 227 Performance Option ..................6-44 Performance Option Settings ................... 6-44 Launch Control ......................6-44 Shift Light ........................6-46 N Track Sense Shift ....................6-47 N Power Shift ......................6-49 N Road Sense ......................6-49 Maximum Performance Driving (How to drive with Octane Number Learning) ... 6-51 Special Driving Conditions ................
  • Page 228 If you hear a change in the sound of the exhaust or if you drive over something that strikes the underneath side of the vehicle, have the exhaust system be checked as soon as possible by an authorized HYUNDAI dealer. Do not run the engine in an enclosed area.
  • Page 229: Before Driving

    Driving your vehicle BEFORE DRIVING Before Entering the Vehicle WARNING Be sure all windows, outside mirror(s), To reduce the risk of SERIOUS INJURY or and outside lights are clean and DEATH, take the following precautions: unobstructed. ALWAYS wear your seat belt. All Remove frost, snow, or ice.
  • Page 230: Engine Start/Stop Button

    ENGINE START/STOP BUTTON WARNING NEVER press the Engine Start/Stop button while the vehicle is in motion except in an emergency. This will result in the vehicle turning off and loss of power assist for the steering and brake systems. This may lead to loss of directional control and braking function, which could cause an accident.
  • Page 231: Engine Start/Stop Button Positions

    Driving your vehicle Engine Start/Stop Button Positions Button Position Action Notes To turn off the engine, press If the steering wheel is not locked the Engine Start/Stop button properly when you open the driver’s with the vehicle shifted to P door, the warning chime will sound.
  • Page 232: Starting The Engine

    Starting the Engine Starting the gasoline engine 1. Always carry the smart key, the Digital key, or the Card key with you. WARNING 2. Make sure the parking brake is Always wear appropriate shoes when applied. operating your vehicle. Unsuitable 3.
  • Page 233: Turning Off The Engine

    Driving your vehicle NOTICE To prevent damage to the vehicle: If the engine stalls while you are in motion, do not attempt to shift the gear to the P (Park) position. If traffic and road conditions permit, you may put the gear in N (Neutral) while the vehicle is still moving and press the Engine Start/Stop button in an attempt to restart the engine.
  • Page 234: Remote Start

    Remote Start You can start the vehicle using the Remote Start button of the smart key. To start the vehicle remotely: 1. Press the door lock button within 10 m (32 feet) from the vehicle. 2. Press the remote start ( ) button for over 2 seconds within 4 seconds after locking the doors.
  • Page 235: Dual Clutch Transmission

    Driving your vehicle DUAL CLUTCH TRANSMISSION OOSN061001 Depress the brake pedal and press the shift button ahead of the shift lever while moving the shift lever. Press the shift button while moving the shift lever. The shift lever can freely operate. Dual Clutch Transmission Operation The dual clutch transmission has eight forward speeds and one reverse speed.
  • Page 236 The dual clutch transmission can be When rapidly accelerating from a thought of as an automatically shifting lower vehicle speed, the engine manual transmission. It gives the RPM may increase dramatically as a driving feel of a manual transmission, result of clutch slip as the dual clutch yet provides the ease of a fully transmission selects the correct gear.
  • Page 237 (D, P) on the instrument cluster will blink. If the LCD warning is active, the foot Contact authorized HYUNDAI dealer brake must be applied. and have the system checked. Ignoring the warnings can lead to damage to the transmission.
  • Page 238 If any of the warning messages in the condition may become worse. You LCD display continue to blink, for your may experience abrupt shifts, or safety, contact an authorized HYUNDAI Jerkiness. To return to the normal dealer and have the system checked. driving condition, stop the vehicle and apply the foot brake or shift into P (Park).
  • Page 239 Driving your vehicle Transmission ranges R (Reverse) Use this position to drive the vehicle The indicator in the instrument cluster backward. displays the shift lever position when the Engine Start/Stop button is in the ON position. NOTICE Always come to a complete stop before P (Park) shifting into or out of R (Reverse);...
  • Page 240 D (Drive) Information This is the normal driving position. The Only the eight forward gears can be transmission will automatically shift selected in Manual Shift Mode. To through a 8-gear sequence, providing reverse or park the vehicle, move the the best fuel economy and power. shift lever to the R (Reverse) or P For extra power when passing another (Park) position as required.
  • Page 241 Driving your vehicle Paddle shifter Shift-lock system For your safety, the dual clutch transmission has a shift-lock system which prevents shifting the transmission from P (Park) to R (Reverse) unless the brake pedal is depressed. To shift the transmission from P (Park) into R (Reverse): 1.
  • Page 242: Parking

    6. Remove the tool from the shift-lock release access hole then install the cap. 7. Depress the brake pedal, and then restart the engine. If you need to use the shift-lock release, have your vehicle inspected by an authorized HYUNDAI dealer immediately. 6-17...
  • Page 243: Good Driving Practices

    Instead, slow down before pulling are outside of the allowable range. back into the travel lanes. When driving with shifter paddles, HYUNDAI recommends you follow all slow down before shifting to a lower posted speed limits. gear. Otherwise, the lower gear may not be engaged if the engine RPMs are outside of the allowable range.
  • Page 244: Braking System

    BRAKING SYSTEM Power-Assist Brakes Wet brakes may impair the vehicle's ability to safely slow down; the Your vehicle has power-assisted brakes vehicle may also pull to one side that adjust automatically through normal when the brakes are applied. usage. Applying the brakes lightly will If the engine is not running or is turned indicate whether they have been off while driving, the power assist for...
  • Page 245: High Performance Brake

    We Firmly depress the brake pedal. recommend that the vehicle be checked by an authorized HYUNDAI Pull up the parking brake lever as far as dealer. possible. If the vehicle has continuous...
  • Page 246 This light will be illuminated when the HYUNDAI dealer. parking brake is applied with the Engine Start/Stop button in the START or ON position.
  • Page 247: Anti-Lock Brake System (Abs)

    Driving your vehicle Anti-Lock Brake System (ABS) Using ABS To obtain the maximum benefit from your ABS in an emergency situation, WARNING do not attempt to modulate your brake Anti-Lock Braking System (ABS) or pressure and do not try to pump your Electronic Stability Control (ESC) brakes.
  • Page 248: Electronic Stability Control (Esc)

    ABS. Your power brakes will work normally. To reduce the risk of serious injury or death, contact your authorized HYUNDAI dealer as soon as possible. NOTICE When you drive on a road having poor traction, such as an icy road, and apply...
  • Page 249 When you apply your brakes under illuminates have the vehicle be checked conditions which may lock the wheels, by an authorized HYUNDAI dealer as you may hear sounds from the brakes, soon as possible. or feel a corresponding sensation in The ESC OFF indicator light comes on the brake pedal.
  • Page 250 Deactivating / Activating ESC In the following situations, it may be better to activate ESC SPORT or deactivate ESC (ESC OFF): When using snow chains Driving in deep snow Driving in sand or gravel Driving on specially designed roads where oversteering and understeering characteristics are desired We recommend only qualified and experienced drivers to drive the vehicle...
  • Page 251 Driving your vehicle To deactivate ESC (ESC OFF) Press and hold the ESC OFF button continuously for more than 3 seconds. The ESC OFF indicator light and message "Traction & Stability Control disabled" illuminates and a warning chime sounds. In this state, both the traction control function of ESC (engine management) and the brake...
  • Page 252 ESC OFF usage Drive mode selection When Driving When the ESC is on, the characteristic of ESC varies according to which drive The ESC OFF mode should only be used mode is selected by pressing the DRIVE briefly to help free the vehicle if stuck in MODE or N1 or N2 button on the steering snow or mud, by temporarily stopping wheel.
  • Page 253: Vehicle Stability Management (Vsm)

    Driving your vehicle Vehicle Stability Management CUSTOM mode (VSM) You may select the drive mode you prefer from the infotainment system Vehicle Stability Management is a screen. function of the Electronic Stability Select CUSTOM mode by pressing Control (ESC) system. It helps the vehicle the N button on the steering wheel.
  • Page 254 When the warning light illuminates due to system self-diagnostics and an have the vehicle be checked by an assumption of a sensor failure. In the authorized HYUNDAI dealer as soon as next ignition cycle, the ESC system is possible. available again.
  • Page 255: Hill-Start Assist Control (Hac)

    Driving your vehicle Hill-Start Assist Control (HAC) Downhill Brake Control (DBC) Hill-Start Assist Control helps prevent the vehicle from rolling backwards when starting a vehicle from a stop on a hill. The system operates the brakes automatically for approximately 2 seconds and releases the brake after 2 seconds or when the accelerator pedal is depressed.
  • Page 256 DBC operation Mode Indicator light Description Press the DBC button when vehicle speed is under 25 mph (40 km/h). The DBC system will turn ON and Standby enter the standby mode. The system does not turn ON if vehicle speed is over 25 mph (40 km/h).
  • Page 257 If the DBC red indicator light illuminates, the system may have overheated or have malfunctioned. When the warning light illuminates even though the DBC system has cooled off, have your vehicle checked by an authorized HYUNDAI dealer as soon as possible. 6-32...
  • Page 258: Good Braking Practices

    Engine Start/Stop button to do so and call an authorized HYUNDAI to the OFF position. dealer for assistance. Vehicles parked with the parking brake...
  • Page 259 System malfunction OOSN061011L Check Electronic Suspension If the ECS warning message comes on, you may have a problem with the ECS system. We recommend that you have the system checked by an authorized HYUNDAI dealer. 6-34...
  • Page 260: Electronic Limited Slip Differential

    ELECTRONIC LIMITED SLIP DIFFERENTIAL Electronic Limited Slip Differential refers CUSTOM mode to a feature equipped with a mechanism You may select the drive mode you that controls the differential functions of prefer from the infotainment system the wheels. screen. Select CUSTOM mode by pressing the The Electronic Limited Slip Differential N1 or N2 button on the steering wheel.
  • Page 261: Warning Messages

    Wait until the Limited Slip Differential system. We vehicle cools down. recommend that you have the system checked by an authorized HYUNDAI dealer OOSN061014L Tire size mismatch. Check all tire sizes If your vehicle is equipped with different tires (size, type, etc.) on the front,...
  • Page 262: N Button

    N BUTTON N1/N2 Button Settings N1 button N1 button OOSN061022L N2 button OOSN061020L N2 button OOSN061023L Each of the N1/N2 button can be set: OOSN061021L 1. N N1 button: Left N button, N2 button: Right N button 2. CUSTOM 1 The driver can set the N1/N2 button 3.
  • Page 263: Drive Mode Integrated Control System

    Driving your vehicle DRIVE MODE INTEGRATED CONTROL SYSTEM Drive Mode The drive mode may be selected according to the driver’s preference or Drive mode knob road condition. The system resets to be in the NORMAL mode, when the engine is restarted. The mode changes, whenever the N1 or N2 button on the steering wheel or the Drive mode knob is turned.
  • Page 264 When the Drive Mode is set Limitation of ECO mode operation: to ECO mode, the engine and If the following conditions occur while transmission control logic are ECO mode is operating, the system changed to maximize fuel operation is limited even though there is efficiency.
  • Page 265: N Mode

    Driving your vehicle SPORT mode N mode SPORT mode manages N1 button the driving dynamics by automatically adjusting the steering effort, the engine and transmission control logic for enhanced driving performance. When SPORT mode is selected by pressing the DRIVE MODE knob, the SPORT indicator will illuminate.
  • Page 266 N mode CUSTOM mode N mode selects the proper The driver can set the two driving mode among SPORT types of CUSTOM mode and SPORT+ for each (CUSTOM 1/CUSTOM 2). In components that will effect CUSTOM mode, they can the performance of a high- select the drive mode for each performance vehicle.
  • Page 267: Ngs (N Grin Shift)

    Driving your vehicle NGS (N Grin Shift) Activated Non-operating Controls engine / transmission to maximum performance when pressing NGS button on the steering wheel remote control in situations where rapid acceleration is required. Functional description and operating conditions OJSN040333 OOSN061052N CAUTION The driver should hold the responsibility to safely drive and...
  • Page 268: Vehicle Characteristic

    Vehicle Characteristic The characteristic of each components varies according to which drive mode is selected by pressing the N1 or N2 button on the steering wheel or the DRIVE MODE knob. DRIVE MODE Knob Component ECO mode NORMAL mode SPORT mode Engine NORMAL SPORT...
  • Page 269: Performance Option Settings

    Driving your vehicle Launch Control CAUTION Launch Control provides maximum Please note that using high acceleration on dry asphalt roads. performance exhaust sound in a Launch Control should not be used on crowded public area, closed parking any other surface. Excessive slip might spaces, and/or residential area can occur and harm your vehicle.
  • Page 270 control’ to set engine RPM from the Infotainment system screen. After setting RPM, press ‘Activate’. 5. Align the steering wheel straight. 6. Depress the brake pedal to the maximum with your left foot. 7. While depressing the brake pedal with your left foot, quickly and fully depress the accelerator pedal with your right foot.
  • Page 271: Shift Light

    Driving your vehicle Shift Light N mode OOSN061026L 1. Press ‘Shift light’ tab in Performance OCN7N061248N options. When engine is operating in a high 2. Select drive mode to activate shift RPM area, it is indicated on the cluster indicator. (ECO/NORMAL/SPORT/N/ according to the corresponding engine CUSTOM) RPM.
  • Page 272: N Track Sense Shift

    Shift Light operation table Blinking of all 5 LEDs, works only in the fixed shift mode where manual upshift is required. Shift lever LED step All LED blink (upshift Shift mode position lighting shift notification) Automatic shift mode N Grin Shift operation N Track Shift operation Temporary manual shift mode (enter D stage paddle shifter...
  • Page 273 Driving your vehicle Operating condition Non-operating conditions N Track Sense Shift is enabled in the N Track Sense Shift is disabled in Performance Options settings Performance Options settings Shift lever in D (Drive) position Shift lever position is in P/R/N Transmission mode is SPORT or Changing Transmission mode during SPORT+ (Including SPORT or N Riding...
  • Page 274: N Power Shift

    N Power Shift N Road Sense N Road Sense is the function that suggests the driver to use the N mode when a double curved sign is sensed. Detecting sensor OOSN061029L When the driver depresses the accelerator pedal fully (100%) in N mode for faster acceleration, it controls by (up- ) shifting with minimal energy loss.
  • Page 275 Driving your vehicle OOSN061024L OBC3N060028 1. Press the ‘N Road Sense’ tab. 3. When the front view camera detects a double curved road sign, the ‘S-bend 2. Press ‘Activate’ to activate N Road ahead’ message will appear on the Sense. cluster.
  • Page 276: Maximum Performance Driving (How To Drive With Octane Number Learning)

    Maximum Performance Driving (How to drive with Octane Number Learning) When the vehicle is refueled, ECU recognizes fueling conditions and determines the octane rating of the fuel. Maximum boost pressure is limited to protect the engine until the fuel is identified as premium fuel.
  • Page 277: Special Driving Conditions

    Driving your vehicle SPECIAL DRIVING CONDITIONS Hazardous Driving Conditions Rocking the Vehicle When hazardous driving elements If it is necessary to rock the vehicle to are encountered such as water, snow, free it from snow, sand, or mud, first turn ice, mud and sand, take the following the steering wheel right and left to clear precautions:...
  • Page 278: Smooth Cornering

    NOTICE Driving in the Rain If you are still stuck after rocking the Rain and wet roads can make driving vehicle a few times, have the vehicle dangerous. Here are a few things to pulled out by a tow vehicle to avoid consider when driving in the rain or on engine overheating, possible damage to slick pavement:...
  • Page 279: Driving In Flooded Areas

    Driving your vehicle Driving In Flooded Areas Reducing the Risk of a Rollover Avoid driving through flooded areas Your multi-purpose passenger vehicle is unless you are sure the water is no defined as a Sports Utility Vehicle (SUV). higher than the bottom of the wheel hub. SUV’s have higher ground clearance Drive through any water slowly.
  • Page 280: Winter Driving

    WINTER DRIVING The severe weather conditions of winter Snow tires quickly wear out tires and cause other problems. To minimize winter driving WARNING problems, you should take the following suggestions: Snow tires should be equivalent in size and type to the vehicle’s standard tires. Snow or Icy Conditions Otherwise, the safety and handling of your vehicle may be adversely affected.
  • Page 281 M+S tires. HYUNDAI vehicle. Be sure to follow the guidelines and installation instructions provided from the tire chain manufacturer.
  • Page 282 Chain Installation WARNING When installing tire chains, follow the The use of tire chains may adversely manufacturer’s instructions and mount affect vehicle handling: them as tightly possible. Drive slowly Drive less than 20 mph (30 km/h) (less than 20 mph (30 km/h)) with or the chain manufacturer's chains installed.
  • Page 283: Winter Precautions

    9. The being frozen, add authorized window battery charging level can be checked washer anti-freeze solution, as specified by an authorized HYUNDAI dealer or in a on the window washer container. service station. Window washer anti-freeze solution is...
  • Page 284 Do not let your parking brake freeze Under some conditions your parking brake can freeze in the engaged position. This is most likely to happen when there is an accumulation of snow or ice around or near the rear brakes or if the brakes are wet.
  • Page 285: Vehicle Load Limit

    Driving your vehicle VEHICLE LOAD LIMIT Two labels on your driver’s door sill show GAWR (Gross Axle Weight Rating) how much weight your vehicle was This is the maximum allowable weight designed to carry: the Tire and Loading that can be carried by a single axle (front Information Label and the Certification or rear).
  • Page 286: The Loading Information Label

    The Loading Information Label Vehicle capacity weight 5 persons : 860 lbs. (390 kg) Vehicle capacity weight is the maximum combined weight of occupants and cargo. If your vehicle is equipped with a trailer, the combined weight includes the tongue load. Seating capacity Total : 5 persons (Front seat : 2 persons, Rear seat : 3 persons)
  • Page 287 Driving your vehicle Towing capacity Steps for determining correct load limit We do not recommend using this vehicle for trailer towing. 1. Locate the statement "The combined weight of occupants and cargo should Cargo capacity never exceed XXX kg or XXX lbs." on your vehicle's placard.
  • Page 288 Example 1 Maximum Load Passenger Weight Cargo Weight (1400 lbs.) (150 lbs. × 2 = 300 lbs.) (1100 lbs.) (635 kg) (68 kg × 2 = 136 kg) (499 kg) Example 2 Maximum Load Passenger Weight Cargo Weight (1400 lbs.) (150 lbs.
  • Page 289 Driving your vehicle Certification label WARNING Overloading Never exceed the GVWR for your vehicle, the GAWR for either the front or rear axle and vehicle capacity weight. Exceeding these ratings can affect your vehicle's handling and braking ability, and cause an accident.
  • Page 290: Trailer Towing

    TRAILER TOWING We do not recommend using this vehicle for trailer towing. 6-65...
  • Page 291: Driver Assistance System

    7. Driver Assistance System Driving Safety Forward Collision–Avoidance Assist (FCA) (Front view camera only) ....7-2 Lane Keeping Assist (LKA) ..................7-14 Blind-Spot Collision-Avoidance Assist (BCA) ............7-20 Safe Exit Warning (SEW) ..................7-33 Driver Attention Warning (DAW) ................7-39 Driving Convenience Cruise Control (CC) ....................7-46 Lane Following Assist (LFA) ..................7-50 Parking Safety...
  • Page 292 If the detecting sensor has been replaced or repaired, have your vehicle inspected by an authorized OTM070237 HYUNDAI dealer. Forward Collision-Avoidance Assist is Never install any accessories or designed to help detect and monitor the stickers on the front windshield, or vehicle ahead or detect a pedestrian in tint the front windshield.
  • Page 293 If ‘Warning Only’ is selected, braking is Avoidance Assist On/Off status from the not assisted. Settings menu. If the warning light remains On when Forward Collision- Avoidance Assist is On, have the vehicle be inspected by an authorized HYUNDAI dealer.
  • Page 294: Forward Collision-Avoidance Assist (Fca) (Front View Camera Only)

    Driver Assistance System When the vehicle is first delivered, Information Forward Collision-Avoidance Assist change the Warning Timing, the Warning will turn off when ESC is turned off Timing of other Driver Assistance by pressing and holding the ESC OFF systems may change. button.
  • Page 295 Forward Collision-Avoidance Assist Operation Warning and control The basic feature of Forward Collision- Avoidance Assist is to warn and help control the vehicle depending on OOSN071017L Emergency Braking To warn the driver that emergency braking will occur, the ‘Emergency on the cluster and an audible warning will sound.
  • Page 296 Driver Assistance System Forward Collision-Avoidance Assist does not operate in all situations or cannot avoid all collisions. The driver should hold the responsibility to control the vehicle. Do not solely depend on Forward Collision-Avoidance Assist. Rather, maintain a safe braking distance, and, if necessary, depress the brake pedal to reduce driving speed or to stop the vehicle.
  • Page 297 Have the vehicle inspected by an authorized Information HYUNDAI dealer. In a situation where collision is imminent, braking may be assisted by Forward Collision-Avoidance Assist when braking is insufficient by the driver.
  • Page 298 An object is placed on the dashboard obstruction (snow, rain, or foreign Your vehicle is being towed material) is removed, have the vehicle The surrounding is very bright inspected by an authorized HYUNDAI dealer. The surrounding is very dark, such as in a tunnel, etc. WARNING...
  • Page 299 Driving through steam, smoke or You are departing or returning to the shadow lane Only part of the vehicle, or pedestrian Unstable driving is detected You are on a roundabout and the The vehicle in front is a bus, heavy vehicle in front is not detected truck, truck with an unusually shaped You are continuously driving in a circle...
  • Page 300 Driver Assistance System There is a group of pedestrians or a WARNING large crowd in front Driving on a curved road The pedestrian is wearing clothing that easily blends into the background, making it difficult to detect The pedestrian is difficult to distinguish from the similarly shaped structure in the surroundings You are driving by a pedestrian,...
  • Page 301 Driving on an inclined road OADAS006 OADAS005 Forward Collision-Avoidance Assist OADAS009 may detect a vehicle or pedestrian in the next lane or outside the lane when driving on a curved road. If this occurs, Forward Collision- Avoidance Assist may unnecessarily warn the driver and control the brake.
  • Page 302 Driver Assistance System Changing lanes OADAS033 [A] : Your vehicle, OADAS032 [B] : Lane changing vehicle, [A] : Your vehicle, [C] : Same lane vehicle [B] : Lane changing vehicle When a vehicle in front of you When a vehicle moves into your lane merges out of the lane, Forward from an adjacent lane, it cannot Collision-Avoidance Assist may not...
  • Page 303 Detecting vehicle WARNING When you are towing a trailer or another vehicle, we recommend that Forward Collision-Avoidance Assist is turned off due to safety reasons. Forward Collision-Avoidance Assist may operate if objects that are similar in shape or characteristics to vehicles and pedestrians are detected.
  • Page 304 Driver Assistance System Lane Keeping Assist is designed to help Lane Keeping Assist Settings detect lane markings (or road edges) Setting features while driving over a certain speed. Lane Keeping Assist will warn the driver if the vehicle leaves the lane without using the turn signal, or will automatically assist vehicle from departing the lane.
  • Page 305 Driving Safety Off in N mode OOSN071035L Turning Lane Keeping Assist On/Off OOSN071046N With the engine on, press and hold the With the engine on, select ‘Driver Lane Driving Assist button located on the steering wheel to turn on Lane Keeping Assist.
  • Page 306 Driver Assistance System Lane Keeping Assist Operation Lane Keeping Assist Warning and control To warn the driver that the vehicle is departing from the projected lane Lane Keeping Assist will warn and help in front, the green indicator control the vehicle with Lane Departure light will blink on the cluster, and the Warning and Lane Keeping Assist.
  • Page 307 WARNING Information The steering wheel may not be For more details on setting the assisted if the steering wheel is held functions in the infotainment system very tight or the steering wheel is Vehicle Settings, refer to “Vehicle steered over a certain degree. Settings”...
  • Page 308 - The shadow is on the lane marking occurs, have the vehicle inspected by an (or road edge) by a median strip, authorized HYUNDAI dealer. trees, guardrail, noise barriers, etc. The lane number increases or decreases, or the lane markings (or...
  • Page 309 If any other system’s warning Information message is displayed or audible For more details on the limitations of the warning is generated, Lane Keeping front view camera, refer to “Forward Assist warning message may not be Collision-Avoidance Assist (FCA)” section displayed and audible warning may in chapter 7.
  • Page 310: Blind-Spot Collision-Avoidance Assist (Bca)

    Driver Assistance System Blind-Spot Collision-Avoidance Assist is designed to help detect and monitor blind spot area and warn the driver of a possible collision with a warning message and audible warning. In addition, if there is a risk of collision when changing lanes or driving forward out of a parking space, Blind-Spot Collision-Avoidance Assist can help avoid...
  • Page 311 HYUNDAI dealer. collision by applying the brake. If the rear corner radars have been replaced or repaired, have the...
  • Page 312 Driver Assistance System Blind-Spot Collision-Avoidance Assist Settings Setting features OTM070097N When the engine is restarted with Blind- Spot Collision-Avoidance Assist off, OOSN071029N message will appear on the cluster. Blind-Spot Safety With the engine on, select or deselect warning light on the side view mirror will from the Settings menu to set whether to blink for three seconds.
  • Page 313 Driving Safety Off in N mode OOSN071026N Warning Timing OOSN071046N With the engine on, select ‘Driver With the engine on, select ‘Driver Settings menu to change the initial warning activation time for Blind-Spot whether to use the function. Collision-Avoidance Assist. When the vehicle is first delivered, is selected, Blind-Spot Collision- Avoidance Assist turns off...
  • Page 314 Driver Assistance System Blind-Spot Collision-Avoidance Assist Operation Warning and control OOSN071027N Warning Volume With the engine on, select ‘Driver OOS057024 Settings menu to change the Warning Vehicle detection Blind-Spot Collision-Avoidance Assist. To warn the driver, a vehicle is detected, the warning light on the If you change the Warning Volume, side view mirror and head-up display the Warning Volume of other Driver...
  • Page 315 Collision warning Information Collision Warning will operate when If the driver's seat is on the left side, the the turn signal is turned on in the collision warning may occur when you direction of the detected vehicle. turn left. Maintain a proper distance with the vehicles in the left lane.
  • Page 316 Driver Assistance System WARNING Collision-avoidance assist will be canceled under the following circumstances: - Your vehicle enters the next lane by a certain distance - Your vehicle is away from the collision risk - The steering wheel is sharply steered OOSN071006L - The brake pedal is depressed Collision-avoidance assist (while...
  • Page 317 Blind-Spot Collision-Avoidance Assist may not operate if the driver applies the brake pedal to avoid collision. When Blind-Spot Collision-Avoidance Assist is operating, braking control by the function will automatically cancel when the driver excessively depresses the accelerator pedal or sharply steers the vehicle. During Blind-Spot Collision- OOSN071018L Avoidance Assist operation, the...
  • Page 318 Assist malfunction for several seconds, and the master ) warning light will illuminate on the cluster. If this occurs, have the vehicle inspected by an authorized HYUNDAI dealer. OTM070099N When Blind-Spot Collision-Avoidance Assist is not working properly, the ‘Check...
  • Page 319 The rear corner radar is covered with an authorized HYUNDAI dealer. snow, rain, dirt, etc. The temperature around the rear corner radar is high or low...
  • Page 320 Driver Assistance System The road pavement (or the peripheral Blind-Spot Collision-Avoidance Assist ground) abnormally contains metallic may not operate properly, or it may components (for example, possibly operate unexpectedly when the due to subway construction) following objects are detected: There is a fixed object near the A motorcycle or bicycle is detected vehicle, such as sound barriers, A vehicle such as a flat trailer is...
  • Page 321 Driving where the road is merging/ WARNING dividing Driving on a curved road OJX1079059 OJX1079057 Blind-Spot Collision-Avoidance Blind-Spot Collision-Avoidance Assist may not operate properly Assist may not operate properly when driving where the road merges when driving on a curved road. The or divides.
  • Page 322 Driver Assistance System Driving where the heights of the Information lanes are different This device complies with Part 15 of the FCC rules. Operation is subject to the following three conditions: 1. This device may not cause harmful interference, and 2.
  • Page 323 Detecting sensor OOS070026K After the vehicle stops, when an OOSN071002N approaching vehicle from the rear area [1] : Rear corner radar is detected after a passenger opens Refer to the picture above for the the door, Safe Exit Warning will warn detailed location of the detecting the driver with a warning message and sensors.
  • Page 324: Safe Exit Warning (Sew)

    Driver Assistance System Safe Exit Warning Settings Setting features OOSN071026N Warning Timing With the engine on, select ‘Driver OOSN071030N Safe Exit Warning Settings menu to change the initial With the engine on, select ‘Driver warning activation time for Safe Exit Warning.
  • Page 325 Safe Exit Warning operation Warning OOSN071027N Warning Volume With the engine on, select ‘Driver OOSN071022L Collision Warning when exiting vehicle Settings menu to change the Warning When an approaching vehicle from the rear is detected at the moment a Safe Exit Warning. If you change the Warning Volume, warning message will appear on the the Warning Volume of other Driver...
  • Page 326 If the master warning light Exit Warning. Doing so may lead to illuminates, have the vehicle inspected serious injury or death. by an authorized HYUNDAI dealer. Safe Exit Warning does not operate if there is a problem with Blind- Spot Collision-Avoidance Assist. The...
  • Page 327 If the master warning light temporarily limit or disable Safe Exit illuminates, have the vehicle inspected Warning. by an authorized HYUNDAI dealer. If this occurs, the ‘Blind-Spot Safety message will appear on the cluster. Safe Exit Warning will operate properly when such foreign material or trailer, etc., is removed, and then the engine is...
  • Page 328 Driver Assistance System Limitations of Safe Exit Warning WARNING Safe Exit Warning may not operate Even though the warning message properly, or it may operate unexpectedly does not appear on the cluster, under the following circumstances: Safe Exit Warning may not properly Getting out of the vehicle where trees operate.
  • Page 329: Driver Attention Warning (Daw)

    Basic function Driver Attention Warning Settings Driver Attention Warning can help determine the driver's attention level Setting features by analyzing driving pattern and driving time while the vehicle is driven. Driver Attention Warning will recommend a falls below a certain level. Leading Vehicle Departure Alert function Leading Vehicle Departure Alert function...
  • Page 330 Driver Assistance System Driving Safety Auto Off in N mode OOSN071026N Warning Timing OOSN071032N With the engine on, select ‘Driver With the engine on, select ‘Driver the Settings menu to change the initial warning activation time for Driver whether to use the function. Attention Warning.
  • Page 331 Driver Attention Warning on the scale of 1 to 5. The lower the Operation level is, the more inattentive the driver Basic function Display and warning The level decreases when the driver The basic function of Driver Attention does not take a break for a certain Warning is to inform the driver of their period of time.
  • Page 332 Driver Assistance System Leading Vehicle Departure Alert CAUTION function Driver Attention Warning may suggest a break depending on the driver’s driving pattern or habits, even if the driver doesn’t feel fatigued. Driver Attention Warning is a supplemental function and may not be able to determine whether the driver is inattentive.
  • Page 333 ) warning light will illuminate on the cluster. If this occurs, have the vehicle inspected by an authorized HYUNDAI dealer. OADAS021 OADAS022 [A] : Your vehicle, [B] : Front vehicle...
  • Page 334 Driver Assistance System When the vehicle ahead sharply steers When a pedestrian or bicycle is between your vehicle and the vehicle ahead OADAS034 [A] : Your vehicle, [B] : Front vehicle OADAS025 If the vehicle in front makes a sharp If there is a pedestrian(s) or bicycle(s) turn, such as to turn left or right or in between your vehicle and the...
  • Page 335 When driving at a tollgate or intersection, etc. OADAS026 If you pass a tollgate or intersection with lots of vehicles or you drive where lanes are merged or divided frequently, Leading Vehicle Departure Alert may not operate properly. Information For more details on the precautions of the front view camera, refer to “Forward Collision-Avoidance Assist (FCA)”...
  • Page 336 Driver Assistance System Cruise Control Operation Setting set speed 1. Accelerate to the desired speed, which must be more than 20 mph (30 km/h). OIK057157N (1) Cruise indicator (2) Set speed Cruise Control allows you to drive at speeds above 20 mph (30 km/h) without OOSN071036N depressing the accelerator pedal.
  • Page 337 Increasing set speed Decreasing set speed OOSN071039L OOSN071040L Push the + switch up and release Push the - switch down and release it immediately. The set speed will it immediately. The set speed will increase by 1 mph (1 km/h) each time decrease by 1 mph (1 km/h) each time the switch is operated in this manner.
  • Page 338 ) indicator will stay on. using the button. Driving speed may sharply increase or decrease when you press the button. NOTICE If Cruise Control pauses during a situation that is not mentioned, have the vehicle inspected by an authorized HYUNDAI dealer. 7-48...
  • Page 339 Turning off Cruise Control WARNING Take the following precautions when using Cruise Control: Always set the vehicle speed under the speed limit in your country. Keep Cruise Control off when the function is not in use, to avoid inadvertently setting a speed. Check that the Cruise ( ) indicator is off.
  • Page 340 Driver Assistance System Lane Following Assist is designed to help Lane Following Assist Settings detect lane markings and/or vehicles on Setting features to help center the vehicle in the lane. Detecting sensor OOSN071035L Turning Lane Following Assist On/Off With the engine on, shortly press the Lane Driving Assist button located on the OOSN051017N steering wheel to turn on Lane Following...
  • Page 341 Lane Following Assist Operation Warning and control OOSN071027N Warning Volume With the engine on, select ‘Driver OOSN071084N Lane Following Assist Settings menu to change the Warning If the vehicle ahead and/or both lane markings are detected and your vehicle Hands-off warning. speed is below 120 mph (200 km/h), the If you change the Warning Volume, green...
  • Page 342 Driver Assistance System WARNING Lane Following Assist does not operate at all times. It is the responsibility of the driver to safely steer the vehicle and to maintain the vehicle in its lane. The hands–off warning message may appear late depending on road conditions.
  • Page 343: Lane Following Assist (Lfa)

    ‘Check Lane message will appear on the cluster for several seconds, and the master ) warning light will illuminate on the cluster. If this occurs, have the vehicle inspected by an authorized HYUNDAI dealer. Limitations of Lane Following Assist OOSN081027N OOSN071019N...
  • Page 344 Driver Assistance System Rear View Monitor Settings Camera settings OOSN071007L OOSN071079N You can change Rear View Monitor by touching the setup icon ( ) on the screen while Rear View Monitor is operating, or selecting ‘Driver while the engine is on. In the Display Contents, you can OOSN071009L Rear View Monitor shows the area...
  • Page 345 Rear View Monitor Operation Extended Rear View Monitor Operating button The rear view will maintain showing on the screen to help you when parking. Operating conditions Shift the gear from R (Reverse) to N (Neutral) or D (Drive), the rear view will appear on the screen.
  • Page 346 HYUNDAI dealer. Limitations of Rear View Monitor When the vehicle is stopped for a long time in winter or when the vehicle is...
  • Page 347 Rear Cross-Traffic Collision-Avoidance Detecting sensor Assist is designed to help detect vehicles approaching from the left and right side while your vehicle is reversing. It will warn the driver that a collision is imminent with a warning message, and an audible warning. Also, braking is assisted to help prevent a collision.
  • Page 348 Driver Assistance System Rear Cross-Traffic Collision- Avoidance Assist Settings Setting features OOSN071026N Warning Timing With the engine on, select ‘Driver OOSN071034N Settings menu to change the initial Rear Cross-Traffic Safety warning activation time for Rear Cross- With the engine on, select ‘Driver Traffic Collision-Avoidance Assist.
  • Page 349: Rear Cross-Traffic Collision-Avoidance Assist (Rcca)

    Rear Cross-Traffic Collision- Avoidance Assist Operation Warning and control Rear Cross-Traffic Collision-Avoidance Assist will warn and help control the vehicle depending on collision risk level: and ‘Stopping vehicle and ending brake OOSN071027N Warning Volume With the engine on, select ‘Driver Settings menu to change the Warning Rear Cross-Traffic Collision-Avoidance Assist.
  • Page 350 Driver Assistance System Collision Warning To warn the driver of an approaching vehicle from the rear left/right side of your vehicle, the warning light on the side view mirror will blink and a warning will appear on the cluster. At the same time, an audible warning will sound.
  • Page 351 Rear Cross-Traffic Collision-Avoidance Assist will operate when all the following conditions are satisfied: - The gear is shifted to R (Reverse) - The vehicle speed is below 5 mph (8 km/h) - The approaching vehicle is within approximately 5 ft. (1.5 m) from the left and right side of your vehicle - The speed of the vehicle approaching from the left and right...
  • Page 352 Driver Assistance System The driver should hold the WARNING responsibility to control the vehicle. Take the following precautions when Do not solely depend on Rear Cross- using Rear Cross-Traffic Collision- Traffic Collision-Avoidance Assist. Avoidance Assist: Rather, maintain a safe braking distance, and if necessary, depress For your safety, change the Settings the brake pedal to reduce driving...
  • Page 353 If Rear Cross-Traffic Collision-Avoidance Assist does not operate properly after it is removed, have the vehicle inspected by an authorized HYUNDAI dealer. OTM070100N When the side view mirror warning light is not working properly, the ‘Check message will appear on the cluster for...
  • Page 354 Driver Assistance System Limitations of Rear Cross-Traffic WARNING Collision-Avoidance Assist Even though the warning message Rear Cross-Traffic Collision-Avoidance does not appear on the cluster, Rear Assist may not operate properly, or it Cross-Traffic Collision-Avoidance may operate unexpectedly under the Assist may not operate properly. following circumstances: Rear Cross-Traffic Collision- Departing from where trees or grass...
  • Page 355 When the vehicle is in a complex WARNING parking environment Driving near a vehicle or structure OJX1079112 OJX1079111 Rear Cross-Traffic Collision- [A] : Structure Avoidance Assist may detect vehicles which are parking or pulling out Rear Cross-Traffic Collision- Avoidance Assist may be limited near your vehicle (for example, a vehicle leaving beside your vehicle, when driving near a vehicle or...
  • Page 356 Driver Assistance System When the vehicle is parked When the vehicle is on or near a diagonally slope OJX1079113 OOSN071011L [A] : Vehicle Rear Cross-Traffic Collision- Avoidance Assist may be limited Rear Cross-Traffic Collision- when the vehicle is on an uphill or Avoidance Assist may be limited downhill slope, or near it, and may when backing up diagonally,...
  • Page 357 Pulling into the parking space where WARNING there is a structure When you are towing a trailer or another vehicle, we recommend that Rear Cross-Traffic Collision- Avoidance Assist is turned off due to safety reasons. Rear Cross-Traffic Collision- Avoidance Assist may not operate properly if interfered by strong electromagnetic waves.
  • Page 358 Driver Assistance System Reverse Parking Distance Reverse Parking Distance Warning can help warn the driver if an obstacle is Warning Operation detected within a certain distance when Operating button the vehicle is moving in reverse at low speeds. Detecting sensor OOSN071051N Parking Distance Warning OFF button (if equipped)
  • Page 359: Reverse Parking Distance Warning (Pdw)

    If it still does not work driving properly, have the vehicle inspected by backward an authorized HYUNDAI dealer. 24~48 in. Buzzer beeps The audible warning does not sound. (60~120 cm) intermittently The buzzer sounds intermittently.
  • Page 360 Parking Distance Warning indicator area is directly sprayed with high may not occur sequentially depending pressure washer on vehicle speed or obstacle shape. If Reverse Parking Distance Warning needs repair, have the vehicle inspected by an authorized HYUNDAI dealer. 7-70...
  • Page 361 The radio frequency components - Canada complies: Rear Corner Radar - United States & U.S. territory, Micronesia, Dominican Republic and Honduras OANATEL002 OANATEL003 OANATEL307 7-71...
  • Page 362: Emergency Situations

    8. Emergency situations Hazard Warning Flasher ................... 8-2 In Case of an Emergency While Driving ............8-2 If the Engine Stalls While Driving ................8-2 If the Engine Stalls at a Crossroad or Crossing ............8-2 If You Have a Flat Tire While Driving ................8-3 If The Engine Will Not Start ................
  • Page 363: Hazard Warning Flasher

    Turn on your hazard warning flasher. Try to start the engine again. If your vehicle will not start, contact an authorized HYUNDAI dealer or seek other qualified assistance. OOS080006L If the Engine Stalls at a Crossroad...
  • Page 364: If You Have A Flat Tire While Driving

    Normally but Doesn't Start traffic. When changing a flat tire, follow the Check the fuel level and add fuel if instructions provided later in this necessary. chapter. If the engine still does not start, have your vehicle checked by an authorized HYUNDAI dealer.
  • Page 365: Jump Starting

    Emergency situations JUMP STARTING Jump starting can be dangerous if done If acid gets into your eyes, flush your incorrectly. Follow the jump starting eyes with clean water for at least 15 procedure in this section to avoid serious minutes and get immediate medical injury or damage to your vehicle.
  • Page 366 Jump starting procedure Information Your vehicle has a battery in the luggage compartment, but when you jump start your vehicle, use the jumper terminal in the engine compartment. 1. Position the vehicles close enough that the jumper cables will reach, but do not allow the vehicles to touch.
  • Page 367 If the cause of your battery discharging is not apparent, have your vehicle checked by an authorized HYUNDAI dealer. Disconnect the jumper cables in the exact reverse order you connected them: 1. Disconnect the jumper cable from the black, negative (-) chassis ground of your vehicle (4).
  • Page 368: If The Engine Overheats

    5. If engine coolant is leaking out, stop is safe to do so. the engine immediately and call the nearest authorized HYUNDAI dealer 2. Place the shift lever in P (Park) and for assistance. set the parking brake. If the air conditioning is ON, turn it OFF.
  • Page 369 If in the engine. To prevent damage, overheating happens again, call add engine coolant slowly in small an authorized HYUNDAI dealer for quantities. It may require several assistance. refilling cycles to properly fill the engine cooling system. If necessary,...
  • Page 370 Check Tire Pressure OOS060047 OOSN081028N You can check the tire pressure in the Warning mode on the cluster. Refer to the “LCD Display Modes” in chapter 4. Tire pressure is displayed after a few minutes of driving after initial engine start up.
  • Page 371: Tire Pressure Monitoring System (Tpms)

    If any of the below happens, have them to the proper pressure. Driving on the system checked by an authorized a significantly under-inflated tire causes HYUNDAI dealer. the tire to overheat and can lead to tire 1. The Low Tire Pressure Telltale/ TPMS failure.
  • Page 372: Low Tire Pressure Warning Light

    Low Tire Pressure If you cannot reach a service station or if the tire cannot hold the newly added Warning Light air, replace the low pressure tire with the spare tire. Low Tire Pressure Position and The Low Tire Pressure Telltale will remain Tire Pressure Telltale on and the TPMS Malfunction Indicator may blink for one minute and then...
  • Page 373: Tpms Malfunction Indicator

    The TPMS Malfunction Indicator on. Have the flat tire repaired by an will illuminate after it blinks for authorized HYUNDAI dealer as soon as approximately one minute when there possible or replace the flat tire with the is a problem with the Tire Pressure spare tire.
  • Page 374 Tire always have your tires serviced by an Pressure Monitoring System (TPMS) authorized HYUNDAI dealer. components may void the warranty for You may not be able to identify a tire that portion of the vehicle.
  • Page 375: Introduction

    Air pressure loss in the tire may adversely the tire and the tire should be inspected affect tire performance. by an authorized HYUNDAI dealer as For this reason, you should avoid abrupt soon as possible. steering or other driving maneuvers,...
  • Page 376: Components Of The Tire Mobility Kit

    Components of the Tire Mobility Kit OOSN081022 1. Speed-restriction label 2. Sealant bottle and label with speed restriction 3. Filling hose 4. Connectors and cable for the power outlet direct connection 5. Holder for the sealant bottle 6. Compressor 7. ON/OFF switch 8.
  • Page 377: Using The Tire Mobility Kit

    Emergency situations Using the Tire Mobility Kit WARNING Do not use the tire sealant after the WARNING sealant has expired (for example, past the expiration date on the sealant container). This can increase the risk of tire failure. WARNING Keep out of reach of children. Avoid contact with eyes.
  • Page 378 OOSN081025 OOSN081012L 1. Shake the sealant bottle (2). 5. Plug the compressor power cord (4) into the vehicle power outlet. 2. Connect the filling hose (3) to the sealant bottle (2) in the direction of (A) NOTICE and connect the sealant bottle to the compressor (6) in the direction of (B).
  • Page 379 Emergency situations Distributing the sealant CAUTION Do not attempt to drive your vehicle if the tire pressure is below 200 kpa (29 psi). This could result in an accident due to sudden tire failure. 8. Switch off the compressor. 9. Detach the hoses from the sealant bottle connector and from the tire valve.
  • Page 380 OOSN081023 Use of the TMK may be ineffectual for tire damage larger than approximately 0.16 inch (4 mm). Contact an authorized HYUNDAI dealer if the tire cannot be made roadworthy with the Tire Mobility Kit. OOSN081011N 11. After driving approximately 4~6 miles (7~10 km or about 10 minutes), stop at a safe location.
  • Page 381: How To Adjust Tire Pressure

    Emergency situations How to Adjust Tire Pressure Information The pressure gauge may show higher than actual reading when the compressor is running. To get an accurate tire pressure, the compressor needs to be turned off. WARNING The tire inflation pressure must be inflated to the proper pressure (Refer to “Tire and Wheels”...
  • Page 382: Notes On The Safe Use Of The Tire Mobility Kit

    0.16 inch (4 mm) or in the sidewall. Please contact the nearest HYUNDAI dealer if the tire cannot be made roadworthy with the Tire Mobility Kit. Do not use the Tire Mobility Kit if a tire is severely damaged by driving run flat or with insufficient air pressure.
  • Page 383: Towing

    [A] : Dollies cause damage to the vehicle. If emergency towing is necessary, we recommend having it done by an authorized HYUNDAI dealer or a commercial tow-truck service. Proper lifting and towing procedures are necessary to prevent damage to the vehicle. The use of wheel dollies or flatbed is recommended.
  • Page 384: Removable Towing Hook

    Removable Towing Hook WARNING Front If your vehicle is equipped with a rollover sensor, set the Engine Start/ Stop button in the OFF or ACC position when the vehicle is being towed. The side impact and curtain air bag may deploy if the sensor detects the situation as a rollover.
  • Page 385: Emergency Towing

    Set the Engine Start/Stop button in you have it done by an authorized the ACC position so the steering HYUNDAI dealer or a commercial tow wheel is not locked. (if equipped) truck service. Place the shift lever in N (Neutral).
  • Page 386: Tie-Down Hook

    NOTICE To avoid damage to your vehicle and vehicle components when towing: Always pull straight ahead when using the towing hooks. Do not pull from the side or at a vertical angle. Do not use the towing hooks to pull a vehicle out of mud, sand or other conditions from which the vehicle cannot be driven out under its own...
  • Page 387: Maintenance

    9. Maintenance Engine Compartment ..................9-3 Maintenance Services ..................9-4 Owner’s Responsibility ....................9-4 Owner Maintenance Precautions ................9-4 Owner Maintenance ..................9-5 Owner Maintenance Schedule ................... 9-6 Scheduled Maintenance Services ..............9-7 Normal Maintenance Schedule .................. 9-9 Maintenance Under Severe Usage Conditions ............9-12 Explanation of Scheduled Maintenance Items ..........9-14 Fuel Filter (for gasoline engine) .................
  • Page 388 Tires and Wheels ..................... 9-34 Tire Care ........................9-35 Recommended Cold Tire Inflation Pressures ............9-35 Check Tire Inflation Pressure ..................9-36 Tire Rotation .......................9-36 Wheel Alignment and Tire Balance ................9-37 Tire Replacement .......................9-37 Wheel Replacement ....................9-39 Tire Traction ........................9-39 Tire Maintenance......................9-39 Tire Sidewall Labeling ....................9-39 Tire Terminology and Definitions ................
  • Page 389: Engine Compartment

    ENGINE COMPARTMENT Gasoline 2.0 T-GDI The actual engine compartment in the vehicle may differ from the illustration. OOSN091011L 1. Engine coolant reservoir / 5. Air cleaner Engine coolant cap 6. Engine oil dipstick 2. Fuse box 7. Engine oil filler cap 3.
  • Page 390: Maintenance Services

    HYUNDAI’s high service quality procedures can be done only by an standards and receives technical support authorized HYUNDAI dealer with special from HYUNDAI in order to provide you tools. with a high level of service satisfaction. Your vehicle should not be modified in any way.
  • Page 391: Owner Maintenance

    The following lists are vehicle checks and WARNING inspections that should be performed Performing maintenance work on a by the owner or an authorized HYUNDAI vehicle can be dangerous. If you lack dealer at the frequencies indicated to sufficient knowledge and experience...
  • Page 392: Owner Maintenance Schedule

    Maintenance Owner Maintenance Schedule At least monthly: When you stop for fuel: Check coolant level in the engine coolant reservoir. Check the coolant level in the engine coolant reservoir or the water-cooled Check the operation of all exterior intercooler coolant reservoir. lights, including the stoplights, turn signals and hazard warning flashers.
  • Page 393: Scheduled Maintenance Services

    SCHEDULED MAINTENANCE SERVICES Follow Normal Maintenance Schedule if the vehicle is usually operated where none of the following conditions apply. If any of the following conditions apply, you must follow the Maintenance Under Severe Usage Conditions. Repeatedly driving short distance of less than 5 miles (8 km) in normal temperature or less than 10 miles (16 km) in freezing temperature Extensive engine idling or low speed driving for long distances Driving on rough, dusty, muddy, unpaved, graveled or salt-spread roads...
  • Page 394 Then, select ‘Yes’ when the message “Has the engine oil been changed? Press [Yes] to reset the oil life.” appears on the screen. - If there is no alert until the maximum maintenance interval, have the vehicle checked by an authorized HYUNDAI dealer.
  • Page 396 Maintenance 9-10...
  • Page 397 9-11...
  • Page 398: Maintenance Under Severe Usage Conditions

    Maintenance Maintenance Under Severe Usage Conditions The following items must be serviced more frequently on cars mainly used under severe driving conditions. Refer to the chart below for the appropriate maintenance intervals. R : Replace I : Inspect and if necessary, adjust, correct, clean or replace Maintenance Driving Maintenance item...
  • Page 399 Severe driving conditions A. Repeatedly driving short distance of less than 5 miles (8 km) in normal temperature or less than 10 miles (16 km) in freezing temperature B. Extensive engine idling or low speed driving for long distances C. Driving on rough, dusty, muddy, unpaved, graveled or saltspread roads D.
  • Page 400: Explanation Of Scheduled Maintenance Items

    Check the fuel lines, fuel hoses and secure, and that no leaks are present. connections for leakage and damage. Hoses should be replaced immediately if We recommend an authorized HYUNDAI there is any evidence of deterioration or dealer replace any damaged or leaking damage.
  • Page 401: Parking Brake

    Cooling System Brake Discs, Pads, Calipers and Rotors Check cooling system components, such as radiator, coolant reservoir, hoses and Check the pads, the disc, and the rotor connections for leakage and damage. for any excessive wear-out. Inspect Replace any damaged parts. calipers for any fluid leakage.
  • Page 402: Engine Oil

    Maintenance ENGINE OIL Checking the Engine Oil Level Engine oil is used for lubricating, cooling, and operating various hydraulic components in the engine. Engine oil consumption while driving is normal, and it is necessary to check and refill the engine oil regularly. Also, check and refill the oil level within the recommended maintenance schedule to prevent deterioration of oil performance.
  • Page 403: Checking The Engine Oil And Filter

    Capacities” section in chapter 2). during its use. Have the engine oil and filter changed by an authorized NOTICE HYUNDAI dealer according to the Oil Life Management System instructions To prevent damage to your engine: or the Maintenance Schedule at the Do not spill engine oil when adding beginning of this chapter.
  • Page 404 Maintenance WARNING CALIFORNIA PROPOSITION 65 WARNING Engine oil contains chemicals known to the State of California to cause cancer, birth defects and reproductive harm. Used engine oil may cause irritation or cancer of the skin if left in contact with the skin for prolonged periods of time.
  • Page 405: Engine Coolant

    Checking the Coolant Level distilled (deionized) water to bring the level to the MAX mark, but do not overfill. If frequent additions are required, see an authorized HYUNDAI dealer for a cooling system inspection. WARNING Never remove the engine coolant cap and/or water-...
  • Page 406 Maintenance Turn the vehicle off and wait until the WARNING engine cools down. Use extreme care Make sure the coolant cap is properly when removing the engine coolant closed after refilling coolant. Otherwise cap and/or water-cooled intercooler the engine could be overheated while coolant cap.
  • Page 407: Changing Coolant

    Changing Coolant The engine in your vehicle has Have the coolant changed by an aluminum engine parts and must be authorized HYUNDAI dealer according protected by an phosphate-based to the Maintenance Schedule at the ethylene glycol coolant to prevent beginning of this chapter.
  • Page 408: Brake Fluid

    If the fluid level Use only the specified brake fluid (refer is excessively low, have the brake system to “Recommended Lubricants and checked by an authorized HYUNDAI Capacities” section in chapter 2). dealer. WARNING If the brake system requires frequent additions of fluid this could indicate a leak in the brake system.
  • Page 409: Washer Fluid

    If the stroke is more or less than specified, have the parking brake adjusted by an authorized WARNING HYUNDAI dealer. To prevent serious injury or death, take Stroke : 4~6 clicks at a force of 44 lbs the following safety precautions when...
  • Page 410: Air Cleaner

    1. Loosen the air cleaner cover attaching be careful that dust or dirt does not clips and open the cover. enter the air intake, or damage may result. Use HYUNDAI genuine parts. Use of non-genuine parts could damage the air flow sensor. 9-24...
  • Page 411: Climate Control Air Filter

    CLIMATE CONTROL AIR FILTER Filter Inspection The climate control air filter should be replaced according to the Maintenance Schedule. If the vehicle is operated in severely air-polluted cities or on dusty rough roads for a long period, it should be inspected more frequently and replaced earlier.
  • Page 412: Wiper Blades

    Maintenance WIPER BLADES Blade Inspection Blade Replacement Contamination of either the windshield When the wipers no longer clean or the wiper blades with foreign matter adequately, the blades may be worn or can reduce the effectiveness of the cracked, and require replacement. windshield wipers.
  • Page 413 Front windshield wiper blade replacement OGSR076066 OGSR076067 Type A 1. Put the front windshield wipers into the service position. 2. Raise the wiper arm and slightly rotate the wiper blade assembly to expose the plastic locking clip. NOTICE OGSR076068 Do not allow the wiper arm to fall 3.
  • Page 414 Maintenance OLF074018 OLF074017 Type B 1. Raise the wiper arm. NOTICE Do not allow the wiper arm to fall against the windshield, since it may chip or crack the windshield. OLF074019 2. Lift up the wiper blade clip (1). Then pull down the blade assembly (2) and remove it.
  • Page 415 3. Make sure the blade assembly is installed firmly by trying to pull it slightly. To prevent damage to the wiper arms or other components, have the wiper blades replaced by an authorized HYUNDAI dealer. 9-29...
  • Page 416 Maintenance BATTERY When lifting a plastic-cased battery, WARNING excessive pressure on the case may To prevent SERIOUS INJURY or DEATH cause battery acid to leak. Lift with a to you or bystanders, always follow battery carrier or with your hands on these precautions when working near opposite corners.
  • Page 417: For Best Battery Service

    Keep the battery securely mounted. The actual battery label in the vehicle may differ from the illustration. Keep the battery top clean and dry. 1. CMF60L-BCI : The HYUNDAI model Keep the terminals and connections name of battery clean, tight, and coated with petroleum jelly or terminal grease.
  • Page 418: Battery Recharging

    1. Turn off the battery charger main switch. 2. Unhook the negative clamp from the negative battery terminal. 3. Unhook the positive clamp from the positive battery terminal. Always use batteries for replacement from an authorized HYUNDAI dealer. 9-32...
  • Page 419: Reset Items

    By jump starting After a jump start from a good battery, drive the vehicle for 20-30 minutes before it is shutoff. The vehicle may not restart if you shut it off before the battery had a chance to adequately recharge. See “Jump Starting” in chapter 8 for more information on jump starting procedures.
  • Page 420: Tires And Wheels

    Maintenance TIRES AND WHEELS WARNING Information - Power Hop Tire failure may cause loss of vehicle When fully accelerating the vehicle from control resulting in an accident. To standstill, a front tire oscillation called reduce risk of SERIOUS INJURY or “Power Hop”...
  • Page 421: Tire Care

    All tire pressures should be checked recommend it be checked by an when the tires are cold. “Cold tires” authorized HYUNDAI dealer. means the vehicle has not been driven Over-inflation produces a harsh ride, for at least three hours or driven less than excessive wear at the center of the 1 mile (1.6km).
  • Page 422: Check Tire Inflation Pressure

    Maintenance Check Tire Inflation Pressure Tire Rotation Check your tires, including the spare tire, To equalize tread wear, HYUNDAI once a month or more. recommends that the tires be rotated according to the maintenance schedule How to check or sooner if irregular wear develops.
  • Page 423: Wheel Alignment And Tire Balance

    Wheel Alignment and Tire Information Balance The outside and inside of the The wheels on your vehicle were aligned unsymmetrical tire is distinguishable. and balanced carefully at the factory to When installing an unsymmetrical tire, be give you the longest tire life and best sure to install the side marked “outside”...
  • Page 424 Tires degrade over time, even when they are not being used. Regardless of the remaining tread, HYUNDAI recommends that tires be replaced after six (6) years of normal service. Heat caused by hot climates or frequent high loading conditions can accelerate the aging process.
  • Page 425: Wheel Replacement

    Wheel Replacement Tire Sidewall Labeling When replacing the metal wheels for any This information identifies and describes reason, make sure the new wheels are the fundamental characteristics of equivalent to the original factory units in the tire and also provides the tire diameter, rim width and offset.
  • Page 426 Maintenance Example tire size designation: Tire speed ratings (These numbers are provided as an The chart below lists many of the example only; your tire size designator different speed ratings currently being could vary depending on your vehicle.) used for passenger vehicle tires. The speed rating is part of the tire size 235/40R19 96Y designation on the sidewall of the tire.
  • Page 427 4. Tire ply composition and material 7. Uniform tire quality grading The number of layers or plies of Quality grades can be found where rubber-coated fabric in the tire. Tire applicable on the tire sidewall between manufacturers also must indicate the tread shoulder and maximum section materials in the tire, which include steel, width.
  • Page 428: Tire Terminology And Definitions

    Maintenance Tire Terminology and Definitions Traction - AA, A, B & C The traction grades, from highest to Air Pressure lowest, are AA, A, B and C. Those grades The amount of air inside the tire pressing represent the tire’s ability to stop on wet outward on the tire.
  • Page 429 DOT Markings Maximum Inflation Pressure A code molded into the sidewall The maximum air pressure to which a of a tire signifying that the tire is in cold tire may be inflated. The maximum compliance with the U.S. Department air pressure is molded onto the sidewall. of Transportation motor vehicle safety Maximum Load Rating standards.
  • Page 430 Maintenance Pneumatic tire Traction A mechanical device made of rubber, The friction between the tire and chemicals, fabric and steel or other the road surface. The amount of grip materials, that, when mounted on an provided. automotive wheel provides the traction Tread and contains the gas or fluid that sustains the load.
  • Page 431: All Season Tires

    All Season Tires Radial-Ply Tires HYUNDAI specifies all season tires Radial-ply tires provide improved tread on some models to provide good life, road hazard resistance and smoother performance for use all year round, high speed ride. The radial-ply tires used including snowy and icy road conditions.
  • Page 432: Low Aspect Ratio Tires

    When there is an impact on a tire, inspect the tire condition. Or, you can contact an authorized HYUNDAI dealer. Inspect the tire condition and pressure every 1,800 miles (3,000 km) to prevent tire damage.
  • Page 433: Fuses

    If the replacement fuse blows, this indicates an electrical problem. Avoid using the system involved. We recommend that you immediately consult an authorized HYUNDAI dealer. WARNING NEVER replace a fuse with anything but another fuse of the same rating. A higher capacity fuse could cause damage and possibly cause a fire.
  • Page 434: Instrument Panel Fuse Replacement

    If it fits loosely, consult an authorized HYUNDAI dealer. In an emergency, if you do not have a spare fuse, use a fuse of the same rating from a circuit you may not need for operating the vehicle, such as the cigarette lighter fuse.
  • Page 435: Engine Compartment Panel Fuse Replacement

    NOTICE the clips. If it fits loosely, consult an Always place the fuse switch in the authorized HYUNDAI dealer. ON position while driving the vehicle. Do not move the fuse switch repeatedly. The fuse switch may be damaged.
  • Page 436 Information 4. Remove the nuts shown in the picture If the multi fuse is blown, consult an above. authorized HYUNDAI dealer. 5. Replace the fuse with a new one of the same rating. 6. Reinstall in the reverse order of removal.
  • Page 437: Fuse/Relay Panel Description

    Fuse/Relay Panel Description Information Instrument panel fuse panel Not all fuse panel descriptions in this manual may be applicable to your vehicle; the information is accurate at the time of printing. When you inspect the fuse box on your vehicle, refer to the fuse box label. OOSN091012L Inside the fuse/relay box cover, you can find the fuse/relay label describing fuse/...
  • Page 438 Maintenance Driver’s side fuse panel Fuse Rating Circuit Protected Fuse Name Front Wireless Charger Unit, Front Air Ventilation Control Module, ATM Shift Lever IND., Driver Console Switch, Electro Chromic Mirror, A/V & Navigation Head Unit, 7.5A MODULE5 Low DC-DC Converter, Data Link Connector, AMP, Crash Pad Switch, Head Lamp LH/RH, A/C Control Module, Front/Rear Seat Warmer Control Module 7.5A...
  • Page 439 Driver’s side fuse panel Fuse Rating Circuit Protected Fuse Name Rear Seat Warmer Control Module S/HEATER REAR Low DC-DC Convertor, AMP 7.5A Smart Key Control Module, BCM MODULE6 7.5A MDPS Unit MDPS 7.5A Hazard Switch, Data Link Connector MODULE1 Electronic Sound Generator Unit, Front Air Ventilation 7.5A MODULE7 Control Module, Front/Rear Seat Warmer Control Module...
  • Page 440 Maintenance Driver’s side fuse panel Fuse Rating Circuit Protected Fuse Name Front Seat Warmer Control Module, S/HEATER FRT Front Air Ventilation Control Module A/C Control Module, Blower Motor, E/R Junction Block A/C2 (RLY. 10) 7.5A A/C Control Module, E/R Junction Block (RLY. 10) A/C1 Smart Key Control Module, PDM1...
  • Page 441 Engine compartment fuse panel Information Not all fuse panel descriptions in this manual may be applicable to your vehicle; the information is accurate at the time of printing. When you inspect the fuse panel in your vehicle, refer to the fuse panel label.
  • Page 442 Maintenance Engine compartment fuse panel Relay Name Relay No. PDM #3 (IG1) Relay RLY.3 Srart #1 Relay RLY.4 Power Outlet Relay RLY.5 PDM #4 (IG2) Relay RLY.6 Fuel Pump Relay RLY.7 PDM #2 (ACC) Relay RLY.8 Blower Relay RLY.10 PTC Heater #1 Relay RLY.11 Rear Heated Relay RLY.12...
  • Page 443 Engine compartment fuse panel Fuse Rating Circuit Protected Type Fuse Name E/R Junction Block (Fuse - F19, F20, F21, 180A ALTERNATOR F22, F23, F24, F25), Alternator MULTI FUSE-1 100A MDPS Unit MDPS PCB Block (Fuse - F1, F2, F3, Engine Control Relay) IGPM (Fuse - F30, IPS0, IPS1, IPS2) IGPM (IPS3, IPS4, IPS5, IPS6, IPS7)
  • Page 444 Maintenance Engine compartment fuse panel Fuse Rating Circuit Protected Type Fuse Name Electronic Vacuum Pump VACUUM PUMP E/R Junction Block (RLY.7) FUEL PUMP IGPM (Fuse - F21, F24, F27, F28, F33, Leak Current Autocut Device) ECS Unit FUSE LSD Control Module E-LSD ESP Control Module ABS1...
  • Page 445 Engine compartment fuse panel (PCB Block) Fuse Rating Circuit Protected Fuse Name PCB Block (A/C Comp Relay) PCB Block (Horn Relay) HORN ECU3 Not Used SPARE Ignition Coil #1/#2/#3/#4 IGN COIL Not Used SPARE Oxygen Sensor (Up/Down) SENSOR1 E/R Junction Block (RLY. 7) SENSOR3 Not Used SPARE...
  • Page 446 Maintenance Engine compartment fuse panel Information (Battery terminal cover) Not all fuse panel descriptions in this manual may be applicable to your vehicle; the information is accurate at the time of printing. When you inspect the fuse panel in your vehicle, refer to the fuse panel label.
  • Page 447: Light Bulbs

    LIGHT BULBS Consult an authorized HYUNDAI dealer Information to replace most vehicle light bulbs. It is The headlamp and tail lamp lenses could difficult to replace vehicle light bulbs appear frosty if the vehicle is washed after because other parts of the vehicle must...
  • Page 448: Headlamp, Position Lamp, Turn Signal Lamp, Daytime Running Light (Drl) Replacement

    However, if the lamp goes out after flickering momentarily, or continues to flicker, have the system checked by an authorized HYUNDAI dealer. The position lamp may not turn on when the position lamp switch is turned on, but the position lamp and headlamp switch may turn on when the headlamp switch is turned on.
  • Page 449: Side Repeater Lamp Replacement

    OOSN091025N If the LED does not operate, have the (1) Stop/Tail lamp vehicle checked by an authorized (2) Stop/Tail lamp HYUNDAI dealer. (3) Turn signal lamp (4) Backup lamp (5) Side marker If these lamps do not operate, have the vehicle checked by an authorized HYUNDAI dealer.
  • Page 450: High Mounted Stop Lamp Replacement

    Replacement OOSN091014L OOS077043 If the high mounted stop does not 1. Using a flat-blade screwdriver, gently operate, contact an authorized HYUNDAI pry the lens cover from the lamp dealer. housing. 2. Remove the bulb by pulling it straight The LED lamps cannot be replaced as out.
  • Page 451: Interior Light Bulb Replacement

    Interior Light Bulb Replacement Luggage compartment lamp Map lamp, Room lamp, Vanity mirror lamp, Luggage compartment lamp and Glove box lamp OOS077048 Glove box lamp OOS077053 Room lamp OOS077047 1. Using a flat-blade screwdriver, gently pry the lens from the interior lamp housing.
  • Page 452: Appearance Care

    Maintenance APPEARANCE CARE NOTICE Finish maintenance Washing If you park your vehicle near a stainless steel sign or glass facade building, the To help protect your vehicle’s finish from vehicle’s exterior plastic parts such rust and deterioration, wash it thoroughly as a bumper, spoiler, garnish, lamp and frequently at least once a month or outside rearview mirror might be...
  • Page 453 NOTICE High-pressure washing When using high-pressure washers, make sure to maintain sufficient distance from the vehicle. Insufficient clearance or excessive pressure can lead to component damage or water penetration. Do not spray the camera, sensors or its surrounding area directly with a high pressure washer.
  • Page 454 Do not use steel wool, abrasive your vehicle maintained and repaired cleaners, or strong detergents by an authorized HYUNDAI dealer. Take containing highly alkaline or extreme care, as it is difficult to restore caustic agents on chrome-plated or the quality after the repair.
  • Page 455 Bright-metal maintenance WARNING To remove road tar and insects, use After washing the vehicle, test the a tar remover, not a scraper or other brakes while driving slowly to see if sharp object. they have been affected by water. If To protect the surfaces of bright metal braking performance is impaired, dry parts from corrosion, apply a coating...
  • Page 456 By using the most advanced design corrosion protection is particularly and construction practices to combat important. Some of the common causes corrosion, HYUNDAI produces vehicles of accelerated corrosion are road salts, of the highest quality. However, this is dust control chemicals, ocean air and only part of the job.
  • Page 457 To help prevent corrosion Keep your garage dry Keep your vehicle clean Don’t park your vehicle in a damp, poorly ventilated garage. This creates The best way to prevent corrosion is a favorable environment for corrosion. to keep your vehicle clean and free of This is particularly true if you wash your corrosive materials.
  • Page 458: Interior Care

    Maintenance Interior Care Cleaning the upholstery and interior trim Interior general precautions Vinyl (if equipped) Prevent caustic solutions such as perfume and cosmetic oil, from Remove dust and loose dirt from vinyl contacting the interior parts because with a whisk broom or vacuum cleaner. they may cause damage or discoloration.
  • Page 459 Caring for the leather seats Leather (if equipped) Features of seat leather - Vacuum the seat periodically to remove dust and sand on the seat. It - Leather is made from the outer skin will prevent abrasion or damage of of an animal, which goes through a the leather and maintain its quality.
  • Page 460 If the interior wooden trim is damaged, you may get a splinter from the wood surface. Therefore, you should immediately have the damaged interior wooden trim replaced by an authorized HYUNDAI dealer. 9-74...
  • Page 461: Emission Control System

    ORVR system is designed to allow the vehicle inspected and maintained vapors from the fuel tank to be loaded by an authorized HYUNDAI dealer in into a canister while refueling at the gas accordance with the maintenance station, preventing the escape of fuel schedule in this manual.
  • Page 462 Maintenance 3. Exhaust Emission Control Do not operate the engine in confined or closed areas (such as garages) any System more than what is necessary to move The Exhaust Emission Control System is the vehicle in or out of the area. a highly effective system which controls When the vehicle is stopped in an exhaust emissions while maintaining...
  • Page 463 Do not modify or tamper with any part of the engine or emission control system. We recommend that all inspections and adjustments are made by an authorized HYUNDAI dealer. Avoid driving with an extremely low fuel level. Running out of fuel could cause the engine to misfire, damaging the catalytic converter.
  • Page 464: California Perchlorate Notice

    Maintenance CALIFORNIA PERCHLORATE NOTICE Perchlorate Material-special handling may apply, See: https://dtsc.ca.gov/perchlorate Notice to California Vehicle Dismantlers: Perchlorate containing materials, such as air bag inflators, seatbelt pretensioners and keyless remote entry batteries, must be disposed of according to Title 22 California Code of Regulations Section 67384.10 (a). 9-78...
  • Page 465 Index...
  • Page 466 Index Accessing Your Vehicle ..................5-4 Hyundai Digital Key ..................5-11 Immobilizer System ..................5-10 Smart Key ......................5-4 Air Bag - Supplemental Restraint System ............3-39 Additional Safety Precautions ................3-60 Air Bag Warning Labels ................... 3-60 How Does the Air Bags System Operate? ............3-44 Occupant Classification System (OCS) ............
  • Page 467 Braking System ....................6-19 Anti-Lock Brake System (ABS) ..............6-22 Disc Brakes Wear Indicator ................6-19 Downhill Brake Control (DBC) ..............6-30 Electronic Stability Control (ESC) ..............6-23 Good Braking Practices ..................6-33 High Performance Brake .................. 6-20 Hill-Start Assist Control (HAC) ..............6-30 Parking Brake ....................
  • Page 468 Index Drive Mode Integrated Control System .............. 6-38 Drive Mode ...................... 6-38 N mode ......................6-40 NGS (N Grin Shift) ..................6-42 Vehicle Characteristic ..................6-43 Driver Attention Warning (DAW) ..............7-39 Driver Attention Warning Malfunction and Limitations ........7-43 Driver Attention Warning Operation ..............
  • Page 469 Engine Compartment Panel Fuse Replacement ..........9-49 Fuse/Relay Panel Description ................9-51 Instrument Panel Fuse Replacement ..............9-48 Guide to hyundai genuine parts ................1-3 Hazard Warning Flasher ..................8-2 High Beam Assist (HBA) ................... 5-67 High Beam Assist Malfunction and Limitations ..........5-69 High Beam Assist Operation ................
  • Page 470 Index If the Engine Overheats ..................8-7 If The Engine Will Not Start ................. 8-3 If the Engine Doesn’t Turn Over or Turns Over Slowly ........8-3 If the Engine Turns Over Normally but Doesn’t Start ........8-3 If You Have a Flat Tire (with Tire Mobility Kit) ..........8-14 Components of the Tire Mobility Kit ...............
  • Page 471 Interior Features ....................5-91 Cargo Area Cover ..................... 5-99 Clock ........................ 5-96 Clothes Hanger ....................5-97 Cup Holder ....................... 5-91 Floor Mat Anchor(s) ..................5-97 Luggage Net Holder ..................5-98 Power outlet ...................... 5-92 Sunvisor ......................5-92 USB Charger ....................5-93 Wireless Smart Phone Charging System ............
  • Page 472 Index Lighting ....................... 5-60 Exterior Lights ....................5-60 Interior Lights ....................5-64 Luggage Compartment Lamp ................5-66 Welcome System ....................5-66 Maintenance Services .................... 9-4 Owner Maintenance Precautions ................ 9-4 Owner’s Responsibility ..................9-4 Mirrors ......................... 5-36 Inside Rearview Mirror ..................5-36 Side View Mirrors ....................
  • Page 473 Rear Cross-Traffic Collision-Avoidance Assist (RCCA) ........7-57 Rear Cross-Traffic Collision-Avoidance Assist Malfunction and Limitations 7-63 Rear Cross-Traffic Collision-Avoidance Assist Operation ......7-59 Rear Cross-Traffic Collision-Avoidance Assist Settings........7-58 Rear View Monitor (RVM) ................. 7-54 Rear View Monitor Malfunction and Limitations ..........7-56 Rear View Monitor Operation ................
  • Page 474 Index Seats ........................3-3 Front Seats ......................3-5 Head Restraints ....................3-11 Rear Seats ......................3-8 Safety Precautions ....................3-4 Seat Warmers ....................3-16 Special Driving Conditions ................. 6-52 Driving at Night ....................6-53 Driving In Flooded Areas ................. 6-54 Driving in the Rain ...................
  • Page 475 Theft-alarm System ..................... 5-32 Tire Pressure Monitoring System (TPMS) ............8-9 Changing a Tire with TPMS ................8-12 Check Tire Pressure .................... 8-9 Low Tire Pressure Position and Tire Pressure Telltale ........8-11 Low Tire Pressure Warning Light ..............8-11 Tire Pressure Monitoring System ..............
  • Page 476 Index Vehicle break-in process ..................1-7 Vehicle Certification Label .................. 2-13 Vehicle data collection and event data recorders ........... 1-8 Vehicle Identification Number (Vin) ..............2-13 Vehicle Load Limit ....................6-60 The Loading Information Label ............... 6-61 Vehicle modifications .................... 1-7 Vehicle settings (infotainment system) ..............

Table of Contents

Save PDF
