  • Page 1 Owner's Manual | Warranty NEXO fuel cell...
  • Page 2 All Map Database cannot be copied without permission. Copyright Notice: © 1987 - 2018 HERE. You may not otherwise reproduce, modify and distribute the content without the prior written consent of HERE Technologies and HYUNDAI MnSOFT, Inc..
  • Page 3 시작하기 General...

  • Page 4: Name Of Each Component

    Name of Each Component Name of Each Component Head unit The image of this product may be different from the actual product. RADIO SEEK MEDIA SETUP TRACK a (1) button 䠐 Power on: Press this button in power OFF status. 䠐...
  • Page 5 Name of Each Component g SEEK W/TRACK S button When it is pressed shortly; 䠐 DAB/FM/AM mode: plays previous/next frequency. 䠐 Media mode: plays previous/next file. When it is pressed and held; 䠐 DAB/FM/AM: changes the frequency until the button is released. 䠐...
  • Page 6 Name of Each Component Driver Information System (DIS) Control - Type A The image of this product may be different from the actual product. BACK MENU HOME DRIVE MODE VIEW a BACK button 䠐 Press to move to the previous screen. 䠐...
  • Page 7 Name of Each Component Driver Information System (DIS) Control - Type B The image of this product may be different from the actual product. MENU BACK HOME DRIVE MODE VIEW a MENU button 䠐 Press to move to the pop-up menu in each mode. 䠐...

  • Page 8: Steering Wheel Remote Control

    Name of Each Component Steering wheel remote control The image of this product may be different from the actual product. button 䠐 Each time this button is pressed, the mode is changed. You can select the accessible media manually from [Mode Button (Steering Wheel)] menu. Only active/available media can be accessed.

  • Page 9: Basic Operation

    Basic Operation Basic Operation System ON/OFF Starting the system for the first time Press the engine start button. Once the system is turned on, the booting process will start and the safety warning page is displayed. <For LHD Cars (Left Hand Drive Cars)> <For RHD Cars (Right Hand Drive Cars)>...

  • Page 10: Turning The System Off

    Basic Operation Turning the system off Press and hold [1] on the head unit. To turn the system on again, press [1] on the head unit. Note Check the volume when turning on the system. Before turning on the system, adjust the volume to a reasonable level.

  • Page 11: Adjusting The Volume

    Basic Operation Adjusting the volume or AV ON/OFF AV OFF Press [1] on the head unit when the AV is ON. AV ON Press [1] on the head unit when the AV is OFF. Adjusting the volume Rotate the volume control knob [ ] on the head unit.

  • Page 12: Using The Controller

    Basic Operation Using the controller This control is used to move and select menus. Controller Description Move in the menu by turning the controller left/right. Push the controller up/down/left/right/diagonally to move in the menu. Press the controller to select menu.

  • Page 13: Using The Touch Screen

    Basic Operation Using the Touch screen Press the desired menu on the screen to select a menu. Note If you touch the screen while driving, the attention may be scattered and cause a traffic accident. For safety, please use after stopping.

  • Page 14: Split Screen

    Basic Operation General operation of the menu in available mode Split screen This feature is used to set the item to be displayed on the split screen on the right side of the screen by setting a checkmark the [Split screen] menu. Press [Split screen] on the pop-up menu in each mode.

  • Page 15: Sound Settings

    Basic Operation Sound settings This menu is used to adjust the sound effects for the whole system. Press [Sound settings] on the pop-up menu of available mode. <For LHD Cars (Left Hand Drive Cars)> <For RHD Cars (Right Hand Drive Cars)> For more details, refer to the "Sound"...
  • Page 16 Basic Operation Switching to simple view or normal view Press [Simple] on each mode screen. Or press [Menu] > [Simple view]. The simple view screen appears. Press [Normal] to move to the normal view. Or press [Menu] > [Normal view]. The normal view screen appears.

  • Page 17: Home Screen

    HOME screen HOME screen Basic operation of HOME screen Press [HOME] or [ ]. The HOME screen appears. Press the desired menu on the HOME screen. Subsequent operations will be performed according to the desired menu selection.

  • Page 18: Customizing Home Screen

    HOME screen Customizing HOME screen You can change the position by pressing and holding the menu icon on the HOME screen. Press and hold the desired menu icon on the HOME screen. Press and drag an item to rearrange the screen. Press [HOME] or [...
  • Page 19 Favourites Favourites Adding your Favourite menu items to [Favourites] menu Select your favourite items for quick and easy access. Press [HOME] or [ ] > [Favourites]. Press [Add to favourites]. If your Favourite menu items are already added, press [Menu] > [Add].
  • Page 20 Favourites Select one of the [Navigation favourites], [Radio favourites] or [Shortcuts]. Select one of the categories. Select the desired item. 䠐 [Mark all]: Selects all items. 䠐 [Unmark all]: Unmarks all items. 䠐 [Cancel]: Exits favourites screen. Press [Add]. Note 䠐...
  • Page 21 Favourites Rearranging your favourite menu [HOME] or [ ] > [Favourites]. Press [Menu] > [Rearrange]. Press and hold an item, then move it up/down to rearrange.
  • Page 22 Favourites Deleting your favourite menu Press [HOME] or [ ] > [Favourites]. Press [Menu] > [Delete]. Select the desired item, then press [Delete] > [Yes]. 䠐 [Mark all]: Selects all items. 䠐 [Unmark all]: Unmarks all items. 䠐 [Cancel]: Exits delete screen.

  • Page 23: Precautions For Safety

    Precautions for Safety Precautions for Safety Notations used within this User's Manual CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
  • Page 24 Precautions for Safety To reduce the risk of electric shock, do not remove the cover or back of this product. There are no user-serviceable parts inside. Refer servicing to qualified service personnel. To reduce the risk of fire or electric shock, do not expose this product to dripping or splashing water, rain, or moisture.
  • Page 25 Precautions for Safety WARNING: 䠐 Don’t use a cellular phone when you are driving. You must stop at a safe place to use a cellular phone. 䠐 The use of the navigation radio by no means relieves the driver of his/her responsibilities. The highway code must always be observed.
  • Page 26 Precautions for Safety CAUTION: 䠐 Do not keep the navigation system running with the engine stopped. Doing so may discharge the vehicle battery. When you use the navigation system, always keep the engine running. 䠐 When the driver wants to operate the navigation system, first park the vehicle in a safe location and set the parking brake.

  • Page 27: General Information

    General Information General Information About USB Connect the USB device after turning on the engine. The USB device may become damaged if it is already connected when the ignition is turned on. 䠐 Files that are not standard format files will not be played. 䠐...

  • Page 28: Mp3 File Information

    General Information MP3 file Information 䠐 Sampling frequency: 8 ~ 48 KHz (MP3), 22.5 ~ 48 KHz (WMA), 8 ~ 192 KHz (FLAC) 䠐 Bit rate: 8 ~ 320 Kbps (MP3), 20 ~ 320 Kbps (WMA), 8 Kbps ~ 1.6 Mbps (FLAC) 䠐...

  • Page 29: Using Ipod® Devices

    General Information Using iPod® Devices Precautions upon using iPod® 䠐 Some iPods with unsupported communication protocols may not properly operate with the system. 䠐 If the iPod malfunctions due to an iPod device defect, reset the iPod and try again. (To learn more, refer to your iPod manual.) 䠐...

  • Page 30: Before Thinking The Product Has

    Before Thinking the Product Has Malfunctioned Before Thinking the Product Has Malfunctioned The current position as shown on the navigation may differ from the actual position under the following conditions. The following occurrences are not malfunctions: 䠐 When driving on Y-shaped roads with narrow angles the current position may be displayed in the opposite direction.
  • Page 31 Before Thinking the Product Has Malfunctioned Correct route guidance may not occur due to search conditions or driving position. The following occurrences are not malfunctions: 䠐 Guidance to go straight may be given while driving on a straight road. 䠐 Guidance may not be given even when having turned at an intersection. 䠐...
  • Page 32 Before Thinking the Product Has Malfunctioned Before Thinking the Product Has Malfunctioned Errors which occur during the operation or installation of the device may be mistaken as a malfunction of the actual device. If you are having problems with the device, try the suggestions listed below. If the problems persist, contact your dealer.

  • Page 33: Troubleshooting

    Troubleshooting Troubleshooting Problem: The power does not turn on. 䠐 Possible Cause : The fuse is disconnected. 䠐 Countermeasure: - Replace with a suitable fuse. - If the fuse is disconnected again, please contact your dealer. 䠐 Possible Cause : Device is not properly connected. 䠐...
  • Page 34 Troubleshooting Problem: The USB does not work 䠐 Possible Cause : USB memory is damaged. 䠐 Countermeasure: Please use after formatting the USB into FAT 16/32 format. 䠐 Possible Cause : USB memory has been contaminated. 䠐 Countermeasure: Remove any foreign substances on the contact surface of the USB memory and multimedia terminal.

  • Page 35: Trademarks And Licenses

    PLEASE READ THIS END USER LICENSE AGREEMENT (“EULA”) CAREFULLY BEFORE USING THE NAVIGATION SYSTEM. This is a license agreement between you and HYUNDAI MNSOFT, INC.. including its affiliates (“COMPANY”) regarding a copy of COMPANY navigable map database together with associated software, media and explanatory printed documentation published by COMPANY (jointly the “Product”).

  • Page 36: Terms And Conditions

    Trademarks and Licenses Terms and Conditions Personal Use Only. You agree to use this Product together with COMPANY authorized application for the solely personal, non-commercial purposes for which you were licensed, and not for service bureau, time-sharing or other similar purposes. Accordingly, but subject to the restrictions set forth in the following paragraphs, you agree not to otherwise reproduce, copy, modify, decompile, disassemble, create any derivative works of, or reverse engineer any portion of this Data, and may not transfer or distribute it in any form, for any purpose, except to...
  • Page 37 Trademarks and Licenses and to the storage and processing of such personal information on computers located outside of the country in which you reside. Even though COMPANY has taken steps intended to protect your personal information from being intercepted, accessed, used, or disclosed by unauthorized persons, COMPANY cannot fully eliminate security risks associated with your personal information and cannot guarantee that its systems will not be breached.
  • Page 38 Trademarks and Licenses DO NOT ATTEMPT TO CONFIGURE THE PRODUCT OR INPUT INFORMATION WHILE DRIVING. FAILURE TO PAY FULL ATTENTION TO THE OPERATION OF YOUR VEHICLE COULD RESULT IN DEATH, SERIOUS INJURY, OR PROPERTY DAMAGE. BY USING THE PRODUCT, YOU ASSUME ALL RESPONSIBILITY AND RISK.
  • Page 39 Trademarks and Licenses Exclusions. Some jurisdictions do not allow certain warranty exclusions or the limitation or exclusion of liability, so to that extent the above exclusion may not apply to you. To the extent that COMPANY may not, as a matter of applicable law, disclaim any implied warranty or limit its liabilities, the scope and duration of such warranty and the extent of COMPANY’s liability shall be the minimum permitted under such applicable law.
  • Page 40 Trademarks and Licenses Miscellaneous. If any provision of this EULA is found to be invalid or unenforceable, it will be enforced to the extent permissible and the remainder of this EULA will remain in full force and effect. Failure by COMPANY to prosecute any right with respect to a default hereunder will not constitute a waiver by COMPANY of the right to enforce rights with respect to the same or any other breach.
  • Page 41 Trademarks and Licenses Notice of Use Contractor (Manufacturer/ Supplier) Name: HYUNDAI MNSOFT, INC. This Product and related documentation are commercial items as defined in FAR 2.101 and is subject to this EULA under which this Product is provided. © 20XX HYUNDAI MNSOFT. All rights reserved.
  • Page 42 Copyright for Junction View Junction View Data provided by ZENRIN USA, INC. Copyright(C) 20XX, All rights Reserved. About Map Updates You can contact your HYUNDAI dealer shop. Information This product requires regular updates for new functions and map updates. Updating may require up to 1 hour depending on the data size.

  • Page 43: Specification

    Specification Specification AV/Navigation product specification Power Supply DC 14.4 V Operating Power DC 9 V ~ DC 16 V Current Consumption Maximum 6 A Dark Current Maximum 1 mA Common Operating Temperature -20 ℃ ~ +70 ℃ Storage Temperature -40 ℃ ~ +85 ℃ 3178 (W) x 50 (H) x 156 (D) mm Dimensions (Head unit) 1.4 kg...
  • Page 44 Specification Specification FCC RF Radiation Exposure Statement: This equipment complies with FCC RF Radiation exposure limits set forth for an uncontrolled environment. This device and its antenna must not be co-located or operating in conjunction with any other antenna or transmitter. This equipment should be installed and operated with a minimum distance of 20 cm between the radiator and your body.
