- Page 1 INSTRUCTION MANUAL Cordless Vacuum Cleaner VC001GL VC003GL Read before use.
-
Page 2: Specifications
Do not short the battery cartridge. • See the chapter “MAINTENANCE” for the appropriate details of precautions during user maintenance. SPECIFICATIONS Model: VC001GL VC003GL Standard filter type Cloth filter (for dry and wet dust) Maximum air volume (with BL4040, ø32 mm x 1.7 m hose) 2.7 m... -
Page 3: Safety Warnings
The vibration total value (tri-axial vector sum) deter- and electronic equipment, accumulators mined according to EN60335-2-69: and batteries may have a negative impact on the environment and human health. Model VC001GL Do not dispose of electrical and electronic Vibration emission (a ) : 2.5 m/s or less appliances or batteries with household Uncertainty (K) : 1.5 m/s... - Page 4 AVOID UNINTENTIONAL STARTING. Be sure 23. For user servicing, the machine shall be dis- switch is OFF when installing battery(ies). mantled, cleaned and serviced, as far as is reasonably practicable, without causing risk to Do not attempt to pick up flammable materials, the maintenance staff and others.
- Page 5 Do not touch the terminals with any con- causing fires, personal injury and damage. It will ductive material. also void the Makita warranty for the Makita tool and charger. Avoid storing battery cartridge in a con- tainer with other metal objects such as Tips for maintaining maximum nails, coins, etc.
-
Page 6: Parts Description
The cleaner has double battery slots. With two identical PARTS DESCRIPTION batteries in parallel, you can extend your running time in one or more uses without having to stop to recharge batteries. The cleaner also works with a single battery, so you can choose with either double batteries or single battery according to your needs. - Page 7 Align the tongues on the battery cartridges with the Indicator lamps Remaining grooves in the battery housing and slip them into place. capacity Insert them all the way until they lock in place with a little click. Lighted Blinking Then lock the battery cover. 75% to 100% 50% to 75% 25% to 50%...
- Page 8 Let the appliance and battery(ies) cool down. If no improvement can be found by restoring protection system, then contact your local Makita Service Center. NOTE: The battery indicators will also be activated when the cleaner starts functioning or switches its Switch action power source from one to another.
- Page 9 Adjusting suction power Locking and unlocking casters The suction power can be adjusted according to your work needs. Rear casters can be locked with stoppers to help the • Turn the suction force adjusting knob to the left to cleaner stand still. reduce the suction power.
- Page 10 Mount the head unit over the tank and secure ASSEMBLY them with the locking latches. CAUTION: Always be sure that the appliance is switched off and the battery cartridges are removed before carrying out any work on the appliance. CAUTION: Always wear dust mask during assembly or maintenance.
- Page 11 To pick up water or wet dust only, the water filter is more Install the paper pack into the tank with its card- suitable than the cloth filter. board opening hooked on the paper pack holder. When installing the water filter, align its mounting posi- tion marking with the one on the tank.
- Page 12 Spread the other top edges of the bag outwards over the top NOTE: Take the polyethylene bag out of the tank rims of the tank. Place the cloth filter or prefilter over the poly- carefully to avoid it from being scratched and torn by ethylene bag to fasten the opening of the bag securely.
- Page 13 Lift the push bar up and tighten the knob to prepare Installing MAKPAC adapter installing the MAKPAC cases onto the cleaner. Optional accessory Connectable and stackable MAKPAC storage cases can be installed on top of the cleaner with an optional adapter.
- Page 14 Attachments with lock function Connections with your work tools (Country specific) Optional accessory By connecting the vacuum cleaner to any available NOTICE: work tools compatible with the cleaner, it works as a When installing the attachment with dust extractor for your power tools. lock function, be sure to align the release button with the hook on the attachment.
-
Page 15: Maintenance
Discoloration, deformation or cracks may result. To maintain product SAFETY and RELIABILITY, repairs, any other maintenance or adjustment should be performed by Makita Authorized or Factory Service Centers, always using Makita replacement parts. Fig.32 Storage of accessories... -
Page 16: Optional Accessories
CAUTION: These accessories or attachments Wipe and shake dust off the cloth filter by hand on are recommended for use with your Makita tool occasions. specified in this manual. The use of any other accessories or attachments might present a risk of injury to persons. - Page 20 Makita Europe N.V. Jan-Baptist Vinkstraat 2, 3070 Kortenberg, Belgium Makita Corporation 3-11-8, Sumiyoshi-cho, Anjo, Aichi 446-8502 Japan 885912-222 www.makita.com 20210615...
