- Page 1 Instruction Manual CENTAUR 2 CENTRIFUGE READ BEFORE USE! Models: MSB020.CX1.5 MSB020.CX1.1 71100-493-4...
- Page 2 Health and Safety at Work MSE UK Ltd is required under the Health and Safety at Work Act, 1974 and other UK legislation as designers, manufacturers, suppliers and importers of articles for use at work to ensure that, as far as is reasonably practicable, articles which we design, produce, supply or import are safe and without risk to health.
- Page 3 MSE UK Ltd, or its approved service agent, reserves the right to repair defective equipment on the premises of the customer, or at a service station, at the sole discretion of MSE UK Ltd or their approved agent. In the event of return to an approved service centre the customer is responsible for the safe packaging of the instrument and notification to the service centre.
- Page 4 ELECTRICITY SUPPLY Before connecting this apparatus to the electricity supply, check the information given on the apparatus rating plate and ensure that; A) Your supply is single phase A.C. (alternating current) of the stated frequency with neutral nominally at earth potential. B) Your supply voltage is within the stated range.
-
Page 5: Table Of Contents
CONTENTS 1. IMPORTANT INFORMATION................. 7 2. GENERAL DESCRIPTION ..................8 Controls And Indicators .................. 9 Centrifuge Bowl ..................... 10 Opening Lid Manually ................... 10 Specifications....................10 3. INSTALLATION ....................12 Preparation ..................... 12 Connecting To 3 Pin Plug ................12 Recommendation For Securing Centrifuge .......... - Page 6 CONTENTS Adjustment Of Balance Detector..............27 8. CIRCUIT DESCRIPTION ..................29 Power Input ....................29 Speed Control ....................29 Tacho Circuit ....................29 Speed Indication .................... 30 Lid Safety Circuit ................... 30 Balance Circuit....................30 9. ESSENTIAL PARTS LIST ..................32 Body Assembly ....................
-
Page 7: Important Information
GENERAL INFORMATION 1. IMPORTANT INFORMATION The following general instructions, and the precautions regarding the prevention of corrosion in rotors and accessories, as described under MAINTENANCE, must be noted and carefully observed. The maximum load should always be checked before commencing any operation. If the sample has a relative density greater than 1.2, the maximum permissible speed of the rotor should be calculated as given in this publication, and applied. -
Page 8: General Description
GENERAL DESCRIPTION 2. GENERAL DESCRIPTION The Centaur 2 centrifuge is CE marked in line with required European Directives for Electromagnetic and Low Voltage Compatibility, see “Declaration of Conformity” for EC Directive/standard used. 120v units designed for CSA approval to the following standards: CAN/CSA C22.2 No. -
Page 9: Controls And Indicators
GENERAL DESCRIPTION 2.1 Controls And Indicators Figure 1. Control Panel of the Centaur 2 Centrifuge 1. The Power On rocker switch, when on (switch illuminated) connects power through to various circuits and components within the centrifuge. 2. The Fuse Holder carries a 20mm long, 5 Amp glass cartridge fuse. It is easily removable. -
Page 10: Centrifuge Bowl
GENERAL DESCRIPTION 2.2 Centrifuge Bowl The centrifuge bowl is easily removable for cleaning or disinfection purposes see section 6 (Maintenance). 2.3 Opening Lid Manually An electrical interlock prevents the lid being opened while the rotor is turning, or when the power is disconnected. If access to the rotor is required during a power failure, insert the Lid Lock Release Key (supplied with accessories) to its fullest extent, into the small hole on the top of the lid, near the front;... - Page 11 GENERAL DESCRIPTION Accessories Supplied With The Centrifuge Part No. Description Quantity 32600.019 Fuse 5A (20mm) 76600.004 Lid Lock Release Key 88110.024 Lid Seal Insertion Tool 71100.493 Operating Manual 71100.958 Guarantee Card 240V 71100.1052 Guarantee Card 120V 82120.143 Spindle Nut (for Rotors 34121-607, 34117-603, 34117-604 only)
-
Page 12: Installation
INSTALLATION 3. INSTALLATION IMPORTANT: The rotor must not be fitted when moving or during transit. 3.1 Preparation Remove the centrifuge from its packing and place it on a rigid, level surface. Check that the available power supply corresponds to that stated on the voltage plate fixed to the rear panel of the centrifuge. -
Page 13: Recommendation For Securing Centrifuge
INSTALLATION 3.3 Recommendation For Securing Centrifuge A Fixing Kit for securing the Centaur 2 centrifuge to a suitably sound worktop is for securing centrifuge available from MSE as an optional accessory. It consists of an anchor bracket which is secured to the bench, or table, by two screws with nuts and washers;... -
Page 14: Rotors And Accessories
ROTORS AND ACCESSORIES 4. ROTORS AND ACCESSORIES 4.1 Installation Of Rotor Before fitting a rotor to the centrifuge ensure that the drive shaft is lightly smeared with petroleum jelly. Check that the rotor is clean - particularly pockets in angle rotors. -
Page 15: Loading The Rotor
ROTORS AND ACCESSORIES 4.3 Loading The Rotor The rotors must carry a full complement of cups/buckets and/or trunnion rings, but all cups/buckets need not be loaded. Loads must be placed symmetrically about the rotor and opposing loads should balance to within 2 grams. Where possible, balancing by sight is usually sufficient. -
Page 16: Rotors And Accessories Tables
ROTORS AND ACCESSORIES 4.5 Rotors And Accessories Tables The centrifuge complies with the requirements of BS4402 only when fitted with one of the following rotors. * Max. rev/min at 240V or 110V ** Supplied as standard with buckets # Available as spares Haem. -
Page 17: Place Swing Out Rotor
ROTORS AND ACCESSORIES 4.5.2 4 Place Swing out rotor 34121-607 Bucket Trunnion Adaptor/ Rotor Max.* Max. Max. Tube Size Cushion Capacity Speed (mm) (mm) 34411-912 34134-604 34142-105** 4 x 100ml 3500 2246 Sealing cap 34144-308 4 x 50ml 3500 2246 43561-156 can be 34151-302 8 x 15ml... -
Page 18: Place Swing Out Rotor
ROTORS AND ACCESSORIES 4.5.3 8 Place Swing out rotor 43121-111 (includes buckets and spindle nut) Bucket Trunnion Adaptor/ Rotor Max.* Max. Max. Tube Size Cushion Capacity Speed (mm) (mm) 34411-905# 34142-101** 8 x 15ml 3500 2200... -
Page 19: Place Angle Rotor
ROTORS AND ACCESSORIES 4.5.4 8 Place Angle rotor 34117-603 Bucket Trunnion Adaptor/ Rotor Max.* Max. Max. Tube Size Cushion Capacity Speed (mm) (mm) 34411-909 34142-104** 8 x 50ml 4600 3120 34411-909 34148-705 8 x 50ml 4600 3120 conical 29 34411-909 34141-114 8 x 1oz 4600... -
Page 20: Place Angle Rotor
ROTORS AND ACCESSORIES 4.5.5 12 Place Angle rotor 34117-604 Bucket Trunnion Adaptor/ Rotor Max.* Max. Max. Tube Size Cushion Capacity Speed (mm) (mm) 34411-904 34142-101** 12 x 15ml 4600 3000 34411-904 43161-103 12 x 15ml 4600 3000 conical 17 34411-904 34148-101 12 x Haem. -
Page 21: Operation
OPERATION 5. OPERATION 5.1 Run Procedure Ensure that the Rotor is correctly loaded and secured and the Timer set at Off. Close the lid and press down firmly. Press the Power switch on. The Power On and the Lid Unlocked indicators will come on. Select Timer to Hold, for continuous running, or to the time required. -
Page 22: Lid Safety Circuit
OPERATION 5.6 Lid Safety Circuit The Lid Safety Circuit has a dual function: It prevents power being switched to the motor until the lid is properly closed. It imposes a delay of approximately three and a half minutes in the event of a tacho failure before the Lid Unlocked indicator comes on and the lid can be opened. -
Page 23: Maintenance
After use wash rotors, metal buckets, cups, carriers and adaptors in warm soapy water, dry and store, inverted, in a dry place. Rotors should be protected with MSE Rotor Spray (Cat. No.17341.151), which is an anti-corrosion and de-waterising agent. -
Page 24: Renewing The Fuse
Fit the new fuse and refit the holder back into the receptacle. If the fuse blows again during use, contact the local distributor, or MSE (UK) Ltd. NB - If the fuse blows immediately or blows again during normal use, the power... -
Page 25: Removal And Replacement Of Centrifuge Bowl
MAINTENANCE 6.9 Removal And Replacement Of Centrifuge Bowl To remove the bowl for cleaning or disinfection purposes proceed as follows: Open the lid, disconnect the centrifuge from the power supply and remove the rotor (if fitted). Peel back the lip of the seal above the bowl vent (inside the bowl at right) note position of the vent then lift the bowl by the vent hole above the seal at this point. -
Page 26: Servicing
SERVICING 7. SERVICING This section has been included for the guidance of competent service engineers only - preferably those trained by MSE (UK) Ltd. 7.1 Calibration Of Speed Control Disconnect the centrifuge from the power supply Remove the instrument chassis (see section 6.7 for removal instructions). -
Page 27: Adjustment Of Balance Detector
SERVICING 7.3 Adjustment Of Balance Detector With the centrifuge upright and after operation with a loaded rotor for a few minutes, to allow the motor to settle in its operating position, insert a 1mm thick gauge between the microswitch actuator and the side of the tacho-box (Item 6. - Page 28 SERVICING Figure 6 Partially Exploded View Of Centaur 2...
-
Page 29: Circuit Description
CIRCUIT DESCRIPTION 8. CIRCUIT DESCRIPTION 8.1 Power Input A.C. mains power is fed to the centrifuge via a double-pole switch SW1, a 5 Amp fuse FS1 and a filter. The Power switch SW1, when switched on, is illuminated by a green neon lamp. 8.2 Speed Control The motor current is phase-controlled by a series triac MR1 which is triggered by an opto-isolator IC1. -
Page 30: Speed Indication
CIRCUIT DESCRIPTION 8.4 Speed Indication The output of VT1 is fed, via a Schmitt trigger, to a monostable circuit (IC3 pins 4, 5, 6, 8, 9 and 10). The pulse width is fixed by a time constant of 22 nf and a 50k variable resistor RV1. - Page 31 CIRCUIT DESCRIPTION...
-
Page 32: Essential Parts List
PARTS LIST ESSENTIAL PARTS LIST 8.7 Body Assembly Part No. Description Remarks 93600.078 Bowl Liner 26600.001 Bowl Seal 71500.055 Motor-Support Bush 96500.015 Retaining Ring 73050.002 Rubber Foot 96500.225 Black Plug Button 72100.121 Left-hand Side Panel 72100.120 Right-hand Side Panel 88120.040 Lid Stop 8.8 Lid and Associated Assembly 72900.045... -
Page 33: Motor Assembly
PARTS LIST 8.9 Motor Assembly Part No. Description Remarks 34400.159 Motor (for 220/240V - 50/60Hz) 34400.160 Motor (for 100/120V - 50/60Hz) 78070.013 Motor Seal 73030.001 Anti-vibration Mount 82120.143 Spindle Nut For rotors 34121.607 34117.603, 34117.604 only 72100.115 Tacho Disc 61080.036 Optical Tacho PCB Assembly 42050.003 Slotted Optical Switch... -
Page 34: Instrument Chassis Assembly
PARTS LIST 8.12 Instrument Chassis Assembly Part No. Description Remarks 32600.019 Fuse 5A (20mm) 32900.037 Fuse Holder 38700.046 Timer Switch, 30 min, 16A, 250V 44050.035 Potentiometer, Speed Control 76070.099 Knob 28mm Black 76070.095 Knob 28mm Black 76070.096 Cap 28mm Black Speed/Timer Control 76070.097 Pointer 28mm Grey... -
Page 35: How To Obtain Service On Your Falcon Centrifuge
5. Fill out the attached service request form and place inside the centrifuge. 6. Pack in a protective box (preferably that in which the centrifuge was originally supplied). 7. MSE (UK) Ltd will specify the carrier to be used and will give details of how the freight is to be charged. - Page 36 SERVICE REQUEST FORM Should it become necessary to have your MSE centrifuge repaired, please take a few moments to fill out this form, which will help us to ensure you receive the best and fastest service possible. Model: ................Serial number: ................
