Summary of Contents for DEVOLA DV20QHWF
-
Page 2: Table Of Contents
Table of Contents Safety Warning… ............2 Frequent enquiries ............3 Installation… ..............4 Components ..............5 Control Panel ..............6 Operation Methods ............7 Drainage ................8-9 Maintenance ..............10 Troubleshooting ............. 11... -
Page 3: Safety Warning
Safety Warning For your safety, please read the following contents carefully before using this dehumidifier: Requirements: ◆ Install this dehumidifier in smooth, level place to reduce vibration and noise. Keep a distance of at least 50cm between appliances and surroundings. ◆... -
Page 4: Frequent Enquiries
Frequent enquiries Why has the dehumidifier stopped working/ won’t work? This dehumidifier may be full of water or water tank is not installed properly, drain the water in water tank, or re-install water tank in correct way. At the moment the dehumidifier may be in the “dehumidification mode”, the ambient temperature is lower or higher (dehumidification cannot be performed when the ambient temperature is ＜5℃or ＞32℃). -
Page 5: Installation
Installation ◆ Please drain the water from water tank before operating. ◆ During operation please keep windows and doors short when possible as the unit works best in sealed conditions. ◆ When the dehumidifier is installed, a certain space must be reserved around this dehumidifier, the minimum distance above is 50cm, and the minimum distance in front/rear and left/right is 20cm as required, as shown in figure below. -
Page 6: Components
Components Front Control panel Water Front panel tank cover Back panel Water tank handle Water tank Back Handle Filter frame Drain outlet Power cord storage column Caster... -
Page 7: Control Panel
Control panel Timer To delay this dehumidifier turning on or off, press this button to activate the 24H Timer. Each time you press the button, it will increase an hour. So, 2 pressed for 2 hours, 3 for 3 hours etc. If you want to cancel timer setup, press twice continuously after setting the timer to a desired hour. -
Page 8: Operation Methods
Operating methods Description of functions Setting of timer off ⚫ When the dehumidifier is running, press the [Timer button] to adjust time from 1h to 24h, pressing the key once to increase the setting time by 1h, after the setting time exceeds 24h, the figure returns to 1 to restart cycle.This will then turn the dehumidifier off after this desired set time. -
Page 9: Drainage
Drainage 1. Use of Water Tank When the water tank is full of water, the full water icon on LCD flashes (the compressor, fan and negative ion will stop running), the BUZZER signals 10 times to alert the user to empty the tank. Place both hands... - Page 10 dehumidifier to drain water. ◆ Locate the drain outlet at the back, unscrew the drain cover, and pull out the water plug. ◆ Connect the 9mm drainage pipe to the drain outlet. Attention: The external water pipe must not be too long (the recommended length is less than 0.6 meters).
-
Page 11: Maintenance
Maintenance Precautions: ⚫ Please disconnect power supply before maintenance or repair to prevent electric shock. ⚫ If the dehumidifier is not used for long time, please disconnect power supply. ⚫ Please do not clean the dehumidifier body with chemical solvents alcohol, gasoline and benzene, such as etc.。... -
Page 12: Troubleshooting
Troubleshooting If the following problems occur to the dehumidifier, the following solutions can be adopted. Symptoms Possible reasons Solutions Is the power plug connected? Insert power plug into socket. Is the water tank full of water? (the Drain water from the water water tank is full of water or is tank, and then install the water The dehumidifier does...
