Summary of Contents for M&V S.r.l. Minima
-
Page 3: Table Of Contents
The Accessories ................................... 4 The internal tank ................................. 4 ................................. 5 INIMA PECIFICATIONS THE MAJOR CONTROLS OF THE MINIMA ........................6 IMPORTANT NOTE ................................7 PREPARING THE MINIMA FOR OPERATION ........................ 8 ..........................8 ILLING THE INIMA FOR THE FIRST TIME ............................ -
Page 4: Introduction
Minima Inspection and unpacking After having removed the packaging, inspect the Minima for shipping damage. If you have any doubts, do not use the Minima and contact a professionally qualified person or your dealer. Always keep all packaging including any plastic bags. -
Page 5: Always Ensure The Portafilter Is Locked In Correctly
Unpacking the Minima The Minima comes in a thick cardboard box with shaped packaging designed to protect it. Do not place the Minima onto a surface subject to scratching or damage before installing the felt or rubber protectors. The felt protectors allow the machine to easily slide on the counter top for filling. -
Page 6: Minima Specifications
Hot water on demand. Steam on demand, wands on ball joint mounts. Steam Boiler can be switched On/Off as required Pressure Gauge Group mounted (direct measure at coffee). © M&V S.r.l. Page 5 of 21 ACS Minima userguide version 1.6 April 19.doc... -
Page 7: The Major Controls Of The Minima
1. Shows Brew and service boiler temperature 2. Shot timer (automatic) 3. Low water indicator (H2O) 4. 2 buttons to set brew temperatures or access advanced settings © M&V S.r.l. Page 6 of 21 ACS Minima userguide version 1.6 April 19.doc... -
Page 8: Important Note
The Minima is a machine that is simple to use even though it is a dual boiler machine. The single LED display shows temperature, shot timer, low water visual indication and to access both temperature settings and advanced settings. -
Page 9: Preparing The Minima For Operation
7. The pump may continue to run as it completes the fill of the service boiler. 8. Make sure the water tank water level is dropping and topped up as required. 9. Once the pump has stopped running, press the right hand display button once and Minima will now start heating the brew boiler. -
Page 10: Flushing The Minima Before Using
Coffee To do the Minima any justice at all, coffee must be fresh. You should know the roast date of the coffee and only use quality coffee from good roasters. Ideally, the coffee should rest for at least 5 days from the roast date before using, often even longer. -
Page 11: Using The Minima
Midnight every day. At 2018 electricity prices, it costs less than 20p to run for 16 hours. Because Minima uses a simple power switch rather than a soft switch. A mains timer or WiFi smart plug device can control the machines On/Off times automatically. This is very convenient and saves having to remember to switch the machine off at night and on in the morning. -
Page 12: Espresso & Other Drinks
Minima It’s important to have a routine, You might give Minima a 4 or 5 second stabilisation flush before pulling a shot after a long break between shots e.g. 10 minutes or more. I use this water to warm the cup. You can choose to do this or not. -
Page 13: Cappuccino
Do not be afraid to experiment, it is why you have a prosumer machine, to duplicate and then move beyond what you can get in the coffee shop. © M&V S.r.l. Page 12 of 21 ACS Minima userguide version 1.6 April 19.doc... -
Page 14: Steaming Milk
It does require some practice to achieve that perfect “glossy micro foam”. Steaming with the Minima is fast, so be careful not to steam too long. The steaming time for milk to use in a single Latte is only 20 seconds or so. -
Page 15: Drawing Hot Water To Warm Cups, For Americanos, Tea And Other Hot Drinks
There will be some steam, so be careful, as the area above the wand will get hot. If your machine has wooden knobs and the water knob gets excessively wet, we advise you quickly dry it after drawing water. © M&V S.r.l. Page 14 of 21 ACS Minima userguide version 1.6 April 19.doc... -
Page 16: Cleaning And Maintenance
Annually Minima will benefit from an annual inspection; this can be a quick visual and auditory inspection for leaks or hissing sounds when both boilers are on. Should you discover any problems, consult your dealer for advice. The Visual part of the inspection is easily done using a torch and by removal of the top cover (cup warmer) of the machine It's held on by 5 hex head screws (3 at the top and 2 at the back). -
Page 17: E61 Gasket Replacement
Switch the Minima on with service boiler heating enabled. The service boiler should start refilling (do not touch the coffee brew switch unless you intend to descale the brew boiler as well). Add more descaling solution to the cold-water tank as necessary. -
Page 18: Brew Boiler Descaling
It is very important to use a damp microfibre cloth and wipe of all splashes of descaler from the stainless steel surface of the machine and group to avoid damage. Regularly rinse the cloth out. © M&V S.r.l. Page 17 of 21 ACS Minima userguide version 1.6 April 19.doc... -
Page 19: Other Problems
This can happen by accident or you may be asked to reset it. The electronics manufacturer has a system that requires you to press and hold both buttons on the display then switch the Minima on to access advanced mode programming. - Page 20 93C. An offset of 16, means the brew boiler is actually at 110C. This allows for approximately 17C cooling when it reaches the coffee. Service Boiler offset - Always set to 0 © M&V S.r.l. Page 19 of 21 ACS Minima userguide version 1.6 April 19.doc...
-
Page 21: Pid Values Explained
We recommend you use the values in the guide, but with experience, small changes may benefit the operation of the Minima in its specific environment because this may be hotter or cooler than the test environment. Warning, if you accidentally power on the machine whilst holding only the right hand button,... -
Page 22: Appendix 1 - Electrical Schematic (Simplified)
Information Technology Solutions INIMA OWNERS MANUAL Appendix 1 - Electrical Schematic (simplified) © M&V S.r.l. Page 21 of 21 ACS Minima userguide version 1.6 April 19.doc... - Page 23 Information Technology Solutions MINIMA OWNERS MANUAL DICHIARAZIONE DI CONFORMITÀ CE - DECLARATION OF CE CONFORMITY DÉCLARATION DE CONFORMITÉ CE - CE KONFORMITÄTSERKLÄRUNG - DECLARAÇÃO DE CONFORMIDADE CE EG CONFORMITEITSVERKLARING - CE-OVERENSSTEMMELSESERKLÆRING M & V S.r.l. Dichiara sotto la propria responsabilità che la macchina in seguito denominata, in base alla sua progettazione, costruzione e per l'utilizzo, è...
