Quick Setup Guide
This guide describes the configuration process for the Sentinel Next devices in collaboration with
the Web Hosted Edition.
Important!
We offer the option to preconfigure the sensors for you. If you have chosen this option you do not
need to perform the setup steps below.
1. Download and install the Sentinel Next App
Go to the Apple App Store on you iOS device and search for "Sentinel Next" or click the link here.
https://itunes.apple.com/us/app/sentinel-next/id869274966?mt=8
The app is compatible with any iPhone, iPad, or iPod Touch with iOS version 5.0 or later.
Select the "Buy" option and the app will download and install on your device.
Page 1 of 8

Advertisement

loading

Related Manuals for Aginova Sentitel Next

Summary of Contents for Aginova Sentitel Next

  • Page 1 Quick Setup Guide This guide describes the configuration process for the Sentinel Next devices in collaboration with the Web Hosted Edition. Important! We offer the option to preconfigure the sensors for you. If you have chosen this option you do not need to perform the setup steps below.
  • Page 2 2. Power ON the Sentinel Next sensor The Sentinel Next comes with a pre-installed with a 3.6V lithium battery. Perform the following steps: Connect the probe. Press the momentary power button to power the unit on. The LED under the Mode button will illuminate green.
  • Page 3 LED Legend Mode LED: Green: Sensor is in factory default Direct Mode Blue (periodic blink): Sensor is configured to post data to a server. Battery LED: Green: Battery is fully charged. Red: Battery is charging. Both Mode and Battery LED blinking red: Battery is depleted.
  • Page 4 3. Connect to the Sentinel Next with your iOS device. On your iOS device, press the Settings icon to open the device settings menu. Then press on Wi-Fi to open the Wi-Fi menu. In the Wi-Fi Settings menu, find the Sentinel SSID in the list of available networks.
  • Page 5 4. Use the app to configure the Sentinel Next Once connected to the Sentinel Next, open the Sentinel Next app. On the application home screen you will see data relevant to the sensor such as current temperature, battery voltage, firmware version, etc. Press the “Configure Product”...
  • Page 6 Unless otherwise instructed by Aginova, leave the Data Server setting to the default value. Select the Sampling Period you want and press Done. Select the Connection Period you want and press Done. Sampling means how often the sensor will collect a data point.
  • Page 7 The Sensor Key is a numerical value located on the label on the back side of the sensor. If you are already a registered user on lyra.aginova.info, you can skip this step and simply log in. Once logged in go to the List of Sensors page and click the “Register a sensor” link in the lower right hand corner of the page.

  • Page 8: Troubleshooting

    Verify that the AP is correctly configured (SSID, channels, DHCP, etc). You can use another device (PDA, laptop) to verify that it can reach the internet. Contact Us User guides for all products are available online at http://www.aginova.com/support.php For further troubleshooting, contact help@aginova.com. Aginova Inc.
