KMART 42702672 Assembly Instructions

Boxing Stand
Keycode: 42702672
Parts List
A. Base B. Base Cap C. Base Support Plate
x 2 x 2
F. Base Plate G. Spring Cover Cap
x 1 x 1
J. Height Adjustment Knob K. Upper Pole
x 1 x 1
n. Bolt M8 x 50mm o. Bolt M8 x 12mm p. Bolt M8 x 16mm
x 1 x 4
D. Base Plug E. Base Plug Cover
x 2 x 1
I. Middle Pole
H. Lower Pole (With a detached plastic ring in the pack)
x 1 x 1
L. Foam Cover M. Punch Ball
x 1
x 1
q. Bolt M6 x 30mm r. Nut M6
x 4 x 2
Boxing Stand
Keycode: 42702672
01 Assembly Instructions
Step 1
Turn the 2 x Base (A) over and connect them using 2 x Base
Support Plate (C) and 4 x Bolts M8 x 8mm (o).
x 1
Step 2
Attach Base Plate (F) to the Base (A) using 4 x Bolts M8 x 16mm (p).
Place Spring Cover Cap (G) over Lower Pole (H) and twist clockwise
top of Base Plate (F) until the coil on the end of Lower Pole (H) sits
on top of the Base Plate (F).
x 2
02
A
C
o
o
o
o
G
H
p
p
p p
F
A
