- Page 1 OptiClean U S E R ’ S G U I D E 6 6 T 6 S E R I E S ™ Safety Instructions Product View Assembly Operations Maintenance and Care 9-12 Troubleshooting Consumer Services Replacement Parts Warranty...
- Page 2 Everything we know about floor care went into the design and construction of this complete, high-tech home cleaning system. Your BISSELL canister vacuum is well made, and we back it with a limited one year warranty. We also stand behind it with a knowledgeable, dedicated Consumer Services department, so, should you ever have a problem, you’ll receive fast, considerate assistance.
-
Page 3: Important Safety Instructions
MPORTANT SAFETY INSTRUCTIONS When using an electrical appliance, basic precautions should be observed, including the following: REaD all InSTRUcTIonS bEfoRE USInG yoUR canISTER VacUUM. Always connect to a polarized outlet (left slot is wider than right). Unplug from outlet when not in use and before conducting maintenance. -
Page 4: Product View
roduct view Flex Hose Swivel Hose Easy Empty Dirt Cup Clean Filter Indicator Power Button Post-Motor HEPA Media Filter Upholstery Tool Crevice Tool w w w . b i s s e l l . c o m Handle Air Flow Regulator Carry Handle Automatic... -
Page 5: A Ssembling Your Vacuum
ssembling your vacuum Connect swivel hose by squeezing both locking buttons and inserting it into the suction opening on the canister. Once the swivel hose is inserted in the suction opening, release the locking buttons. Connect telescoping extension wand to the handle end of the flex hose. -
Page 6: Power Cord
perations Power cord The power cord is located at the rear of the vacuum. Gently pull out the power cord, watching for the yellow line. Stop pulling the power cord once the yellow line is visible. There is also a red line, which indicates the end of the usable cord. - Page 7 Special tools your bISSEll opticlean is not only a powerful carpet and rug vacuum cleaner, it’s also a versatile bare floor vacuum cleaner and above floor vacuum cleaner when you select one of the special tools. floor nozzle: Use to vacuum carpets, rugs and bare floors.
- Page 8 perations Variable suction power control The variable suction power control is located on the back of the vacuum. Turn the control toward the larger dots for maximum suction. Turn the control toward the smaller dots to minimize suction for lightly soiled areas or delicate fabrics.
-
Page 9: Emptying The Dirt Cup
aintenance and care Emptying the dirt cup Turn vacuum OFF ( ). Unplug the vacuum from electrical outlet. Open the dirt cup compartment by lifting up the door latch on the front of the vacuum. Lift the dirt cup assembly out from the vacuum. Remove the top cover from the dirt cup assembly by unfastening the latch, raising the front edge and removing the top cover from... -
Page 10: Cleaning The Pre-Motor Filter
aintenance and care Cleaning the pre-motor filter The pre-motor filter protects the motor from dirt and dust particles. Turn vacuum OFF ( ). Unplug the vacuum from electrical outlet. Open the dirt cup compartment by lifting up the door latch on the front of the vacuum. Lift out the dirt cup. - Page 11 aintenance and care Replacing the post-motor HEPA media filter The post-motor HEPa media filter assists in the filtration process to return clean air to the room. Turn vacuum OFF ( ). Unplug the vacuum from electrical outlet. Remove the filter door (located on the back of the vacuum) by pulling down on the filter door and pulling it toward you.
- Page 12 aintenance and care Replacing the dirt cup HEPA media & cleaning the foam filter continued The dirt cup foam filter is located between the bottom of the dirt cup and the HEPA media filter. Once the HEPA media filter has been removed, the foam filter can then be removed and cleaned or replaced as needed.
-
Page 13: Troubleshooting
6. Crack or hole in flex hose other maintenance or service not included in the manual should be performed by an Thank you for selecting a bISSEll product. Please do not return this product to the store. contact bISSEll consumer Services at 1-800-237-7691. - Page 14 ISSELL Consumer Services Or visit the BISSELL website - www.bissell.com When contacting BISSELL, have model number of cleaner available. Please record your Model Number: ___________________ Please record your Purchase Date: ___________________ noTE: Please keep your original sales receipt. It provides proof of purchase date in the event of a warranty claim.
- Page 15 - BISSELL OptiClean Item Part no. 203-7289 203-7259 203-7258 203-7260 203-7261 203-7267 203-7257 203-7256 203-7265 203-7266 203-7264 w w w . b i s s e l l . c o m Part name Dirt Cup Assembly Dirt Cup HEPA Media Filter...
- Page 16 ATTN: Consumer Services BISSELL HOMECARE, INC. IS NOT LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES OF ANY NATURE ASSOCIATED WITH THE USE OF THIS PRODUCT. BISSELL’S LIABILITY WILL NOT EXCEED THE PURCHASE PRICE OF THE PRODUCT. Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to you.
