ShorePort PWC Lift
Instructions
1022950 - 58" x 138" Tan ShorePort
1029301 - 58" x 138" Gray ShorePort
1.
To avoid the risk of personal injury or death, study and fully understand the proper installation
and operating procedures and safety precautions outlined in this owner's manual.
2.
NOT COMPLYING WITH THE PROCEDURES AND PRECAUTIONS OUTLINED IN THIS
MANUAL MAY RESULT IN PERSONAL INJURY OR DEATH AND WILL INVALIDATE THE
WARRANTY.
3.
Use caution when handling gasoline; plastic creates static electricity and may ignite flamable
gases or liquids resulting in burns.
4.
Never jump or dive into the water before the entire subsurface area has been checked for
depth. Not doing so may result in personal injury or death.
5.
Do not run on the ShorePort; the ShorePort has uneven surfaces and may be slippery when
wet causing a falling injury.
6.
Check bolts periodically to ensure hardware and connectors remain securely fastened.
7.
If you have any questions about assembly, installation, use or suitability of this product,
contact an authorized dealer or ShoreMaster directly at 800-328-8945.
®
- PUT SAFETY FIRST
Shoreport
SHOREMASTER.COM
Advertisement
Related Manuals for Shoremaster ShorePort 1022950
Summary of Contents for Shoremaster ShorePort 1022950
- Page 1 Check bolts periodically to ensure hardware and connectors remain securely fastened. If you have any questions about assembly, installation, use or suitability of this product, contact an authorized dealer or ShoreMaster directly at 800-328-8945. SHOREMASTER.COM...
- Page 2 Note: The front of the ShorePort is 16" tall and will have a freeboard of about 14" without a PWC on it. The rear roller should rest about half way out of the water without a PWC on it. The freeboard can be increased by adding supplemental floatation (item 10). SHOREMASTER.COM...
- Page 3 The spacer kit can be used in any of the three slots. To the left, recommended roller position for PWC's that are difficult to remove from the Shoreport. Front roller in position B, middle roller in position C. SHOREMASTER.COM...
- Page 4 Grease Access Hole snap in needle (the needle can be purchased from ShoreMaster with part number 1017538 or through a parts store). To add grease to the keel roller you will have to make sure your ShorePort came with the keel rollers that have a small hole drilled into the middle of the roller.
- Page 5 Bracket with Chain Bracket with 3' Pipe P/N:1007729 Floating Dock Guide connector 5'-3" Pipe P/N:1007732 P/N: 1013365 P/N: 1023737 - Tan P/N: 1022952 - Tan 7' Pipe P/N:1007736 1029304 - Gray 1029310 - Gray 10'-6" Pipe P/N:1007737 21' Pipe P/N:1002676 SHOREMASTER.COM...
- Page 6 Attach ShorePorts together using 2' Notched Connector and ShorePort 1' Side Rear Connector. Step 2. Attach ShorePort to Poly Dock using ShorePort front connectors. Step 3. Slide 2" schedule 40 pipe into pipe brackets and drive into ground using post pounder. SHOREMASTER.COM...
- Page 7 If multiple ShorePorts are to be attached side by side pipe brackets should be used instead of side mount flexi-hinge. Kit includes front and back brackets to attach side of ShorePort to floating dock. Floating ShorePort Dock Side Mount Flexi-Hinge SHOREMASTER.COM...
- Page 8 Note: DO NOT attach ShorePort to Poly Dock using only poly pipe bracket / ShorePort side connector you must also use a pipe bracket on the outside of the ShorePort (as shown). Note: See Connector Instructions for directions on how to assemble ShorePort connectors. SHOREMASTER.COM...
- Page 9 2" x 8" and bolt the 2" x 8" to the dock (as shown in Detail A). Parts List ITEM DESCRIPTION ShorePort Universal Stand-off Plate Assembly (Pair) 2" Schedule 40 Pipe Shoreport Rear Pipe Bracket with Hardware Medium Pipe Bracket with Hardware Standing Dock or Sea Wall SHOREMASTER.COM...
