INSTRUCTIONS
© 2019, Speedway Motors, Inc.
350-300
G-Comp Rear Suspension
62-67 Nova
350003.1
350003.2
350003.3
350003.4
350003.5
350004
350023
350024
REAR CROSSMEMBER
PANHARD
BAR BRACKET
SADDLE
BRACKET
Kit Contents
G-Comp Chassis Brace
G-Comp Front Supports
G-Comp Upper Rear Crossmember
G-Comp Panhard Bar
Hardware Kit
G-Comp Rear Truck Arms
Panhard Bar Hardware, Nova
G-Comp Rear Panhard Bar Brackets
REAR END HOUSING
(NOT INCLUDED)
U-BOLT
PANHARD BAR
COIL-OVER SHOCK
(NOT INCLUDED)
TRUCK ARM
FRONT SUPPORT
CHASSIS BRACE
CAM BOLT
1
Advertisement
Table of Contents
Related Manuals for Speedway 350-300
Summary of Contents for Speedway 350-300
- Page 1 INSTRUCTIONS © 2019, Speedway Motors, Inc. 350-300 G-Comp Rear Suspension 62-67 Nova Kit Contents 350003.1 G-Comp Chassis Brace 350003.2 G-Comp Front Supports 350003.3 G-Comp Upper Rear Crossmember 350003.4 G-Comp Panhard Bar 350003.5 Hardware Kit 350004 G-Comp Rear Truck Arms 350023...
- Page 2 INSTRUCTIONS © 2019, Speedway Motors, Inc. 350-300 G-Comp Rear Suspension 62-67 Nova 1. Remove Rear Suspension: Raise the car and support it with jack stands or a lift. Remove the exhaust, drive shaft, rear end, and all rear suspension components including the rubber bump stops. Disconnect fuel lines and remove fuel tank.
- Page 3 INSTRUCTIONS © 2019, Speedway Motors, Inc. 350-300 G-Comp Rear Suspension 62-67 Nova 5. Prep Rear End: If re-using a rear end, tear down the rear end to just a bare housing. Remove any spring perches or brackets. For the saddles and panhard bar bracket to be positioned properly, it is critical that they fit tightly against the bare axle tubes.
- Page 4 INSTRUCTIONS © 2019, Speedway Motors, Inc. 350-300 G-Comp Rear Suspension 62-67 Nova 8. Tack-Weld Saddle Brackets: Once you are sure the rear end is located properly, tack-weld the saddle brackets to the rear end housing. It is recommended to double check all measurements after tack welding.
- Page 5 INSTRUCTIONS © 2019, Speedway Motors, Inc. 350-300 G-Comp Rear Suspension 62-67 Nova 10. Check Alignment and Clearances: It is recommended at this point to cycle the suspension though its travel and check for any clearance issues. This is also a good time to double check that the rear end is aligned properly with the car and the pinion angle is correct.
- Page 6 INSTRUCTIONS © 2019, Speedway Motors, Inc. 350-300 G-Comp Rear Suspension 62-67 Nova 13. Alignment: Lower the car onto the ground and check for desired ride height. Adjust ride height if necessary by raising the car and spinning the adjusting collar on the coil-over. Repeat procedure until desired ride height is obtained.
- Page 7 CODs are not accepted. Shipping costs for exchanged merchandise product, and each part thereof, is sold “as is”, and “with all faults” and Speedway will be charged to your credit card.
