Speedway G-Comp 350-500 Instructions

INSTRUCTIONS
© 2019, Speedway Motors, Inc.
350-500
70-81 Chevy Camaro
G-Comp Front Suspension

Kit Contents:

350-100.2
350-500.1
350-500.2
350-500.3
350-503
910-35000
910-35010
910-35341
910-35500
910-35600
1. Support the car on jack stands or hoist. The front
stands must be located on the main floor just behind
the firewall. Do not support the car on the front sub-
frame.
2. Remove the hood and inner fenders. Remove the
radiator, front bumper, fenders, and core support.
Disconnect all electrical components from the firewall
forward. Retain all hardware to be used during re-
assembly. Remove the engine, transmission, and
accessories. Support the subframe with a floor jack.
Unbolt the subframe from the body and lower it down
G-Comp Camber Shim Kit
G-Comp Subframe, Camaro
G-Comp Sway Bar Kit, Camaro
Hardware Kit, G-Comp Camaro
G-Comp 34'' Sway Bar
G-Comp Spindles
G-Comp Steering Arms
T-Bird Power Steering Rack
G-Comp Upper Control Arms
G-Comp Lower Control Arms
until the weight is supported by the front tires. The sub-
frame can now be rolled out of the way.
3. Install the G-Comp subframe. Now is a good time
to replace your old worn out body mount bushings.
Place the new upper bushing halves into their locations
on the subframe. The rear portion of the subframe
includes body mount locations for both early and later
style Camaros. Be sure to install the bushings into the
appropriate locations for your car. Using a floor jack,
raise the new G-Comp sub-frame into position while
lining up the holes in the sub-frame with the body.
Install new or re-use your OEM body mount bolts along
with the lower body mount bushings and washers.
Note: Start all of the body bolts before tightening
any of them completely. Once all of the bolts have
been started, make sure the subframe is aligned with
the car, and tighten the bolts. With the subframe in
place, you can now move the jack stands to the front
crossmember. This will make the vehicle more stable
while installing the rest of the kit.
1
