Network Connection Diagram

Refer to the following diagram examples to confirm the network environment that is
1
connected to the machine, and then perform the necessary operations for that
environment.
NOTE
•
For connecting a LAN cable to the machine, refer to the Quick Start Guide.
If you connect the machine directly to your computer, use a crossover cable.
•
For specifying the network settings, see "Specifying the Network Settings," on p. 2-1.
1-2 Network Connection Diagram
Connecting the machine directly to the computer
Client
(Windows 98/Me/2000)
Client
(Windows XP)
Connecting the machine to the computer via a print server
Client
(Windows 98/Me/2000/XP)
Client
(Windows 98/Me/2000/XP)
The Machine
: TCP/IP
Print Server
(
Windows 2000/XP/Server 2003)
The Machine
: TCP/IP
