Summary of Contents for TownSteel 2000 Series
-
Page 2: Table Of Contents
Index Disable or Enable all User Codes and Manager Codes within Definition· · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · ·02 the system Factory Default Setting·... -
Page 3: Definition
Definition: Code Length: Emergency Open Mode: Group Function: LED Indicator: Locked Mode: Manager Code: Master Code: Pass Time: Passage Mode:... -
Page 4: Factory Default Setting
Penalty Time (Anti-T amper Lockout): REM1: REM2: Service Code (One-time User Code): User Code: Factory Default Setting Master Code: Pass Time: Penalty Time: Important Notes: Factory Default Master Code must be changed to your own personal Master Code before programming any other codes. -
Page 5: Change Master Code
Pressing Star (“□ ”) key cancels on-going programming. Pressing Pound (“#”) key starts programming. Replacing batteries does not change existing settings. During programming, Blue LED indicator indicates either success of programming or programming in progress, and red LED indicator indicates failure of programming. -
Page 6: Add Code
Add Code Add a Manager Code – Program 02 Key Sequence □ ● □ □ ● ● ●● [Master Code] [2-digit Manager ID] [New Manager Code] □ if you want to add Manager Code of “2000” with Manger ID 90, Press: ●... -
Page 7: Add Multiple User Code
User Code of “2010” with User ID 01, Press: □ ● ● 01 ● 2010 ●● For example, 5555 Add Multiple User Codes – Program 02 Key Sequence User Code Key Sequence: □ ●... -
Page 8: Delete Code
Delete Code Delete Manager Code – Program 03 Key Sequence □ ● □ □ ● ●● [Master Code] [2-digit Manager ID] □ if you want to delete Manager Code “5000” with Manager ID “50”, Press: ● ● ●● For example, 5555 Delete User Code –... -
Page 9: Disable Or Enable Code
□ 5555 ● □ □ ● □ □ ●● For example, if you want to delete all Service Codes, Press Disable or Enable Code Disable or Enable a Manager Code Disable a Manager Code – Program 04 Key Sequence □... - Page 10 Key Sequence □ □ □ ● ● ●● [Master or Manager Code] [2-digit User ID] □ □ □ For example, if you want to enable User Code “2030” with User ID “03”, Press ● ● ●● [5555] [03] Notes: Manager Code can only enable User Code under the same Manager Group.
-
Page 11: Disable Or Enable All User Codes Within The System
Enable all User Codes under Same Manager Group – Program 6X Key Sequence □ □ □ ● ●● [Master or Manager Code] Result: All User Codes in Group X are disabled. Note: X is the group number from 0 to 9. -
Page 12: Disable Or Enable Group Function
Key Sequence □ □ □ ● ●● [Master Code] □ ● □ □ ●● For example, if you want to disable all User Codes and Manager Codes, Press [5555] Notes: All User Codes and Manager Codes are disabled. And all Service Codes are cleared out. -
Page 13: Enable Or Disable Passage Mode
□ ● □ □ ●● [Master Code] Result: Manager Codes are restricted to program User Codes within their own groups, and all following groups until another Manager Code appears. Enable or Disable Passage Mode Enable Passage Mode – Program 40 Key Sequence □... -
Page 14: Remote Access Terminals
Note: LED indicator flashes to indicate lock status. LED indicator flashes in red if lock is in Locked Mode; LED indicator flashes in blue if lock is in Passage Mode. Disable Lock Status Indicator – Program 91 Key Sequence □... -
Page 15: Revert To Factory Setting
Revert to Factory Setting – Program 99 Key Sequence □ □ □ □ □ ● ● ●● [Master Code] Result: Lock is reverted to factory default setting. All codes are deleted and Master Code changes to 12345. Note: The Blue LED lights for 7 seconds and 2 beeps sounds. -
Page 16: Adjust Keypad Sound Level
Key Sequence □ ● □ □ ● ● ●● [Master Code] [1-digit for invalid codes entry] [1-digit X0 seconds] Example 1: □ ● ● ● ●● 5555 (Master Code = 5555) Result: Disable Keypad Anti-Tamper Lockout Example 2: □... -
Page 17: Code Location Function
Code Location Function - Program 09 □ ● □ □ ● ●● [Master Code] [Enter Code to be located] Result: If the code entered is recognized, the following sequence will occur: 1. At the start of the Code Location sequence, the lock will Flash both the Blue and RED LEDs and emit 2 beeps. -
Page 18: Low Battery Warning
Low Battery Warning When the battery voltage is lower than 4.5VDC, LED indicator will flash in red for 5 times before the Blue LED flashes to signal acceptance of the code. Batteries should be changed as soon as this happens. - Page 19 A: Yes. It is terminal 1. Labeled as R1 on PCB cover. A PHR-2 connector with 1’ long wire is included in the package. 5. What is the product warranty? A: one year limited. 6. What’s the Technical Support Contact? A: From 7:00AM-3:30PM, Mon-Fri, Pacific Time Toll Free: (877) 858-0888 Email: sales@townsteel.com Website: www.townsteel.com -18-...
