ThermalTronix
TT-1066MD-FTM Series
Thermal Imaging Camera
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ThermalTronix TT-1066MD-FTM Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Intellisystem ThermalTronix TT-1066MD-FTM Series

Summary of Contents for Intellisystem ThermalTronix TT-1066MD-FTM Series

  • Page 1 ThermalTronix TT-1066MD-FTM Series Thermal Imaging Camera User Manual...
  • Page 2 General Information CONVENTIONAL Warning: The improper operation can cause the thermal imaging system the major damage。 Careful, attention, warning, danger: In the reminder operation should pay attention item Please read "WARNING" & "CAUTION" in the operation manual attached to the product carefully for proper operation before using the product.

  • Page 3: Table Of Contents

    Table of contents 1. INTRODUCTION ........................1 3. CONNECTIONS & BUTTONS DESCRIPTION ..............1 4. CLIENT SOFTWARE OPERATIONS ................. 2 4.1 G ....................... 2 ETTING STARTED 4.2 G ....................3 RAPHICAL USER INTERFACE 4.2.1 Interface and Connection description ................3 4.2.2 Interface operation description ..................

  • Page 4: Introduction

    1. Introduction Thank you for choosing the TT-1066MD-FTM thermal imaging camera (referred to hereafter as “camera” or “TT-1066MD-FTM”). The TT-1066MD-FTM uses the high sensitive UFPA detector. Simply connect the camera to a PC or a monitor and produce high-quality real-time images. Its low weight, ruggedness and compacted.

  • Page 5: Client Software Operations

    4. Client software operation TT-1066MD-FTM_Client is accessional software you can use pc to control the camera by this software. Getting started Double click on to start up the software, with the interface shown as following: Figure 5.1...

  • Page 6: Graphical User Interface

    4.2 Graphical user interface 4.2.1 Interface and Connection description Interface work region Figure 5.2 There are four small work regions on the software interface, it’s said that four apparatus can be connect to the PC and operate by the software, and then operate one of the regions to control the corresponding apparatus.
  • Page 7 Figure 5.4  If the apparatus in the sleep mode will automatically awaken, the video will display on the screen if the connection is successful. Figure 5.5  Click the work region 1 to zoom in the region 1 to whole work region. Network transfer rate Apparatus...

  • Page 8: Interface Operation Description

    4.2.2 Interface operation description To start up the video play software. For more information see section 5.4. To analyze thermal image. it’s spare function in currently. Click to quit the software and then the TT-1066MD-FTM_Client dialog box will pop-out. (Right figure) Press Y to disconnect the apparatus.
  • Page 9 To set the frames of the infrared original data record. To set the frame capture interval. Unit: millisecond (mS), the parameter must be the multiple of 20.otherwise the system will automatic amend the parameter. Click to record the infrared data. Every time operation will record the frames according with the setting of “Frames”, and the interval of the adjacent frame decided by the setting of “Interval”.
  • Page 10 Control item selection. Click ▼ to display options(right figure)： When you select one of the items the others item will be invalid.  YUN：Select to control Yun terrace；  LENS：Select to control LENS, Click left/right button to adjust focus, or press C button to autofocus.

  • Page 11: System Setting

    4.3. System setting Figure 5.7 IP address：Set IP address of the apparatus. Note: the IP address setup must same as the current apparatus Figure 5.8 To set the emissivity of spots, line and areas .To select the display temperature type of areas. Figure 5.9 Click button to change the path.
  • Page 12 Figure 5.10 Item Optional Comments Video Type PAL/NTSC Analog video output Video Mode Auto/Manu Brightness, contrast adjustment mode Temp Yes/No To show or hide the temperature result and Image palette. ISO Temp User- Isotherm temperature. Reference the 4.2.3.3 defined ISO Hight User- Isotherm height Reference the 4.2.3.3 defined...
  • Page 13 Item Value Comments Measure Class To select temperature range Refe Type 9 optional To select reference temperature type Refe Temp User-defined To set the temperature if the Refe Type selected Value Ambient Temp User-defined To set the ambient temperature Obj Distance User-defined To set the distance from camera to object Ambient...
  • Page 14 Item Parameter Comments MAC Addr Settled The unique MAC address of every apparatuses set by manufactory Auto Adjust User-defined To set the automatic calibrate time. If set 0 this Time function will inactive. Range (60~600) Date Time To display current date and time System Info To display system information Language...

  • Page 15: Video Play Software

    4.4. Video play software Figure 5.16  Click to display a windows dialog box, select the file that you want and then click open to play the video.  Click to display the following dialog box. Figure 5.17  Click to play the video in full screen.
