1. PRECAUTION 1. Read this manual carefully before installing or using this equipment. 2. This equipment is designed for paint drying applications. Adjust to the correct temperature and check minimum safe distance from the heat source when using. Improper use may cause paint surface damage. 3.
3. INSTALLATION The shortwave infrared curing lamp is divided into 3 parts (a base, a column and a cassette). 1) Installation of the base. a. Open the packing of the base. b. Install the four wheels on the base respectively and tighten up the screws. Usually, the wheels with brakes should be mounted on the rear of the base.
4. CONTROLS 1. LCD display 2. Lamp selector (each lamp can be controlled separately) 3. Power adjustment 4. Time adjustment 5. Setting: - Press the button once, it will enter into "Routine" mode when the lamp is on. ① ② ③...
5. OPERATION 1. Automatic Mode a. Properly assemble the curing system according to the instruction (see page 3). b. Switch on the power supply. The system is ready to use when the graphic appears on the display screen as follows: 00: 00 POWER: 80% 00CM...
Page 8
5. OPERATION 2. Manual Mode a. Press the navigation buttons "Power +/- " and "Time +/-" when the lamp is ready to use to adjust the curing power and time. b. Press the button "Setting" to set the mode of "Routine" or "Pulse”. c.
6. TROUBLESHOOTING 1. Troubleshooting PROBLEM CAUSE SOLUTION a. Light tube damaged a. Check light tube Light tube does not work b. Lamp is not plugged in b. Check the connections c. Control silicon damaged c. Check control silicon Light tube does not turn a.
6. TROUBLESHOOTING 2. Lamp Tube Replacement 1. Prepare cassette for replacement 2. Remove the screws on the side panel of cassette. 3. Remove the screws on the front panel to open it. 4. Remove the screws on both ends of the lamp tube so it can be replaced.
7. EXPLODED VIEW Name Name Name Name Upright post Plastic nut Front wheel Transformer Top cover Connecting axle Base Cover plate (upper) Plastic band Connector (right) Back wheel Circuit board Connector (left) Handle Flange Bracket Lower connecting rod Cover plate (lower) Clamping bar Upper connecting rod Power switch...
