FCC STATEMENT
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired
operation.
Warning: Changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications.
However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
This device complies with Industry Canada License-exempt RSS-210. Operation is subject to
the following two conditions: (1) this device may not cause interference, and (2) this device
must accept any interference, including interference that may cause undesired operation
of the device.
FCC Responsible party:
Company Name: FLIR Commercial Systems, Inc.
Address: 9 Townsend West, Nashua NH 03063 USA
Phone: 1- 603-324-7842
IC ID: 1590A-RH200WT; FCC ID: IWK-RH200W-T; CAN RSS-Gen/CNR-Gen.
SPECIFICATIONS
MAIN UNIT
Indoor temperature range/resolution: -5°C ~ 50°C (23°F ~ 122°F) / 0.1°C/°F
Temperature Accuracy:
Humidity range/resolution:
Humidity Accuracy (at 25°C [77°F]): ±8%RH (20~39% RH); ±5%RH (40~70% RH)
Power: 1.5V AA X 4 (alkaline battery recommended)
Dimensions: 130 (W) x 112 (H) x 27.5 (D) mm (5.1 x 4.4 x 1.1 in.)
Weight: 295g (0.65 lbs.)
WIRELESS SENSOR
Outdoor temperature range:
Outdoor humidity range:
Temperature resolution:
Relative humidity resolution:
Accuracy: See accuracy specs for Main Unit above
Wireless sensor signal frequency: 433MHz
No. of remote sensors:
RF transmission range:
Power:
Dimensions: 61 (W) x 113.6 (H) x 39.5 (D) mm (2.4 x 4.5 x 1.5 in.)
Weight:
±2°C (3.6°F), < 0°C (< 32°F)
±1°C (1.8°F), 0~40°C (32~104°F)
±2°C (3.6°F), > 40°C (> 104°F)
1% ~ 99 % / 1%
±8%RH (71~90% RH)
-40°C ~ 60°C (-40°F ~140°F)
1% ~ 99 %
0.1°C/°F
1%
Eight (8) units max.
30m (98.4 ft.) maximum
1.5V AA X 2 batteries (alkaline recommended)
136g (0.3 lbs.)
Two-year Warranty
Teledyne FLIR LLC warrants this Extech brand instrument to be free of defects in
parts and workmanship for two years from date of shipment (a six-month limited
warranty applies to sensors and cables). To view the full warranty text please
visit: http://www.extech.com/support/warranties.
Calibration and Repair Services
Teledyne FLIR LLC offers calibration and repair services for the Extech brand
products we sell. We offer NIST traceable calibration for most of our products.
Contact us for information on calibration and repair availability, refer to the
contact information below. Annual calibrations should be performed to verify
meter performance and accuracy. Product specifications are subject to change
without notice. Please visit our website for the most up-to-date product
information: www.extech.com.
Contact Customer Support
Customer Support Telephone List:
Calibration, Repair, and Returns:
Technical Support: https://support.flir.com
Copyright © 2021 Teledyne FLIR LLC
All rights reserved including the right of reproduction in whole or in part in any
www.extech.com
3
https://support.flir.com/contact
repair@extech.com
form
RH200W-en-US_v1.3 10/21
