- Page 1 OWNER'S MANUAL Electronically-Tuned AM/FM/ Radio With CD PLAYER Made in China...
- Page 2 The Mobile Electronics Company UDIOVOX PECIALIZED PPLICATIONS, L.L.C. 90 DAY/12 MONTH LIMITED WARRANTY AUDIOVOX SPECIALIZED APPLICATION, LLC ( the company) warrants to the original retail purchaser of this product that should this product or any part thereof, under normal use and con ditions , be proven defective in material or workm anship within 90 days from the date of original purchase, such defect(s) will be repaired or replaced ( at the company's option) without charge for parts and repair labor.
- Page 3 FADER CONTROL i ) Press the "SEL" button to select the fader mode until "FAD" indicator lights up. ii)Press " " button to decrease the sound level of rear sp eakers or press " button to decrease the sound level of front speakers. LOC/RPT BUTTON IN RADIO MODE Press this button once in weak signal area.
-
Page 4: Wiring Diagram
APPLICATION NOTES This note will discuss DC Power sources and how they relate to 12 volt products . General Specifications Our general specification for the voltage range of operation is 10 to 16 volts DC . Voltage The voltage of a fully charged battery ( engine not running ) is approximately 12.5 VDC. -
Page 5: Troubleshooting Chart
TROUBLESHOOTING CHART AM/FM RADIOS Symptom Cause Check circuit fuse at source No Power No 12VDC Check in-line fuse on power lead Power lead disconnected Ground connection disconnected Circuit fuse at source No 12VDC to memory Power indicated; In-line memory lead fuse lead(electronically no audio output tuned units only)
