ASA Electronics MS-306 Owner's Manual

Am/fm stereo radio with auto reverse cassette player

Advertisement

Quick Links

R
Owner's Manual
AM/FM STEREO RADIO
WITH AUTO REVERSE CASSETTE PLAYER
Designed Specifically for
the Marine Environment
MS-306

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MS-306 and is the answer not in the manual?

Questions and answers

Summary of Contents for ASA Electronics MS-306

  • Page 1 Owner’s Manual AM/FM STEREO RADIO WITH AUTO REVERSE CASSETTE PLAYER Designed Specifically for the Marine Environment MS-306...
  • Page 3 1. POWER ON/OFF VOLUME Rotate knob clockwise past detent to turn radio “ON”. Further rotation increases the volume. Rotate knob counter-clockwise past detent to turn the radio “OFF”. Counter-clockwise rotation decreases the volume. 2. FADER CONTROL Clockwise rotation shifts the signal to the Left/Right front speakers. Counter-clockwise rotation shifts the signal to the Left/Right rear speakers.
  • Page 4 7. PROGRAM INDICATORS Indicates tape direction for reference to the fast forward/reverse buttons. Further indicates the direction (side) of the tape currently playing. To reverse the tape direction and play the other side of the cassette, lightly press both << and >> (5) buttons at the same time. The change of direction will be shown by the indicators.
  • Page 6: Bass Control

    AM/FM BAND SELECTOR Press this button to the “IN” position for FM band. Press and release it to the “OUT” position for the AM band. BASS CONTROL According to individual taste, Bass Sound can be boosted or cut by tuning this knob clockwise or counter-clockwise respectively.
  • Page 7: Care And Maintenance

    CARE & MAINTENANCE Cassette Always check that the tape is tightly wound inside the take-up spool on the cassette. If the tape is loose, wind it with a six-sided pencil. Never use C-120 (120 minute) cassettes in this player. Never use cassette player when the vehicle temperature is near or below freezing.
  • Page 8 Symptom No Power Power indicated; No audio output AM/FM RADIOS Cause No 12VDC No 12VDC to memory lead (electronically tuned units only) Speaker Output shorted Speaker out cross channeled Possible Solution Check circuit fuse at source Check in-line fuse on power lead (wall mount units are located in rear cabinet) Power lead disconnected...
  • Page 9 Only one channel (right or left side) Popping in one or both channels No AM Reception Radio Balance Speaker Disconnected Speaker lead shorted or grounded Speaker wiring shorted or positive lead grounded Speaker terminals grounded or shorted Antenna disconnected Antenna mast grounded or shorted Antenna center lead broken Note: Antenna leads can be tested with continuity or multi-tester.
  • Page 10 Audiovox Specialized Applications, LLC T E C H N I C A L B U L L E T I N AM/FM RECEPTION Many vans and RV’s have more than one AM/FM radio. The best way to insure good reception is to supply a separate antenna for each radio.
  • Page 11: Antenna Cable

    Special circuitry in electronic tuned radios or AM trimmers in mechanically tuned radios, make up for some of this difference in optimum mast length for AM reception. ANTENNA CABLE Increasing the antenna lead cable (adding extensions) will reduce sensitivity of AM with electronic tuned radios.
  • Page 12 Audiovox Specialized Applications, LLC T E C H N I C A L B U L L E T I N This bulletin will discuss DC Power sources and how they relate to 12 volt DC video products. DC (Direct Current) Power A large number of our products are designed for 12 volt DC applications.
  • Page 13 In conclusion, operating these video products without the engine running will drain the battery to the point where these products will perform unacceptably in a short period of time. Converters Many RV OEM’s incorporate converters as a source of 12VDC when connected to shore power (110-120 VAC).
  • Page 14: Accessory List

    AVT-988 9” Color Television with Remote (12V) AVT-597 5” Color Television with Remote (12V) AVT-1498 13” Color Television with Remote (12V) AVP-7000 Video Cassette Player (12V) AVP-7285 Video Cassette Player (12V) Wireless Headphone Kit: Includes 2 sets Wireless Headphones and Transmitter BPA-501-12 4 Amp Adapter for use with AVT-988 9”...
  • Page 15 88-00236-00...
