Matco Tools GG-60 Operating Instructions, Warning Information, Parts Breakdown

Operating Instructions • Warning Information • Parts Breakdown
Read and carefully study the operating instructions before unpacking and operating the
Continuous Shot Air Grease Gun. The gun must be operated, maintained and repaired
by a person who is familiar with the operating instructions. Operate the gun only after
you have read and understand this operation manual.
FOR YOUR SAFETY
AND TO PREVENT INJURY:
EXTREME PRESSURE MAY CAUSE WHIP HOSE TO BURST. USE ONLY
APPROVED HOSES AND FOLLOW THE HOSE INSTRUCTIONS AND
WARNINGS.
THIS AIR OPERATED GREASE GUN CAN DEVELOP HIGH PRESSURES - UP
TO 6,000 PSIG (414 BAR). USE SAFETY GLASSES AND GLOVES WHILE
OPERATING THE GUN. KEEP HANDS CLEAR OF THE EXPOSED RUBBER
PORTION OF THE HOSE WHILE OPERATING THE GUN WITH HOSE.
IF FLUID APPEARS TO PENETRATE THE SKIN, SEEK IMMEDIATE MEDICAL
ATTENTION. DO NOT TREAT AS A SIMPLE CUT.
BE SURE THE TRIGGER IS NOT DEPRESSED WHEN ATTACHING THE GUN
TO AN AIR INLET HOSE.
AVOID ACCIDENTAL STARTING.
HOLD THE HOSE ONLY BY THE METAL SPRING GUARDS ON THE END.
DO NOT ALLOW THE HOSE TO KINK. DO NOT BEND THE HOSE IN A
TIGHT RADIUS.
REPLACE THE HOSE AT FIRST SIGN OF WEAR, KINK OR DAMAGE TO THE
OUTSIDE JACKET.
USE ONLY HIGH PRESSURE GREASE GUN HOSE AS A REPLACEMENT.
FEATURES
• 360˚ Swivel head allows incredible access to
grease fittings
• Simple, durable construction for years of
consistent, reliable service
• True continuous grease feed with one trigger pull
• Quiet, dependable operation
• Includes 18" high pressure grease hose and
durable 6" bent metal spout
GG-60
The Matco Air Operated Continuous Shot
Grease Gun is a fully pneumatic powered
tool. The gun is designed for manual
lubrication of grease points in automotive
and truck applications. The gun has a
single action pump that delivers grease
each time the trigger is depressed and the
plunger moves forward.
FOR YOUR SAFETY
AND TO PREVENT INJURY:
High pressure hazard.
Wear safety goggles.
Do not exceed 60 psi
with hose or 90 psi with
solid extension. To do so
may cause personal
injury.
Continuous Shot Air
1
GG-60
Grease Gun
w/Swivel Head
Rev. 01/29/04
