2.3
Specifications
Dimensions
Enclosure 60W x 26H x 15D mm
Lead length 200mm
Weight 70g
Input Voltage
Controller 7.5 - 20.0 V
Sensor 10.8 - 16.5 V
Input Current
Controller 100 mA
Sensor Heater 8 A
Miscellaneous
Operating Temp -20 to 100 °C (-4 to 212 °F)
Sensor Genuine Bosch LSU4.9
Sensing Range 0.67 - 10 Lambda
Pressure Compensation 0.5 to 2.5 Bar
CAN Frequency 1Mbit/s,500kbit/s,250kbit/s,125kbit/s,100kbit/s
Connectors
Power Loom DTM04-4P mates with DTM06-4S
Sensor Loom Bosch LSU4.9 connector
© 2021 Link Engine Management Ltd
Introduction
