Diagnostic Information
When using Link ECU, if using as Lambda 1 (device identifier 0) or Lambda 2 (device identifier 1), internal status and
error values will be displayed in PCLink.
Otherwise the CAN information will need to be used to determine problems (See Transmitted Information)
Lambda output defaults to zero when the module is not able to operate correctly.
Status Codes:
Code Description
0 Off
1 Disabled
2 Initialising
3 Diagnostics
4 Calibration
5 Heating
6 Operating
If a fault is detected in operating mode, the module will cycle back to 'Initialising', then run through the setup procedure
again, halting at 'Diagnostics' if a fault is found.
Error Codes:
Code Description
1 Ok
2 - 15 Internal Error
16 Heated too long
17 - 25 Internal Error
26 Battery under voltage
27 - 32 Internal Error
33 Open circuit APE-IPE
34 Open circuit RE-IPE
35 Open Circuit RComp
36 RComp Invalid
37 IPE short to ground
38 RE short to ground
39 APE short to ground
40 IPE or APE error
41 MES under voltage
42 MES over voltage
43 RE under voltage
44 RE over voltage
45 IPE under voltage
46 IPE over voltage
© 2021 Link Engine Management Ltd
Cause
Cause
Everything Ok
Heater current is being applied but
temperature not changing.
Supply voltage dropped below 10.8V
while operating.
APE-IPE loop is open circuit
RE-IPE loop is open circuit
Compensation resistor in connector is
open circuit
Not open circuit, but compensation
resistor is out of range.
Short or open circuit on IPE or APE
Short to ground.
Over 9V.
Short to ground.
Over 9V.
Short to ground.
Over 9V.
Controller turned off
Controller enabled, but RPM is zero.
Initialising hardware
Checking sensor
Calibrating sensor
Heating sensor to operating temperature
Normal Operation
Solution
Contact Link Technical Support
Check wiring, inspect sensor for damage.
Contact Link Technical Support
Check wiring, check battery. May occur
during cranking.
Contact Link Technical Support
Check wiring, inspect sensor
Ensure CAN-Lambda has good clean power
supply.
Check wiring, inspect connector. Typical
error when no sensor is connected.
Check sensor type, check wiring.
Check wiring, inspect sensor.
