USER GUIDE
10/100 Ethernet
Ethernet to Fiber Isolation Card
The RLH 10/100 Ethernet fiber link card converts a 10/100BaseT
RJ45 port to an op�cal signal for transmission over either
mul�mode or singlemode fiber op�c cable.
With half or full duplex opera�on, it also features Auto MDI/MDI-X
so a straight through or crossover cable can be used regardless of
end device. The card provides Link Loss Pass-through (LFP), and
has an informa�ve LED display for status monitoring.
This product is IEEE 802.3 10Base-T, 100Base-Tx and 100Base-Fx
compliant, and is interoperable with other 10/100 BaseT and
Base-FX devices. Both dual fiber (single direc�on) and single fiber
(bidirec�onal) models are available. Please refer to the op�cs
configura�on table below.
This fiber link card is designed to be installed into any of the RLH
Fiber Link Card Housings, and occupies a single card slot.
Key Features
Provides 10/100 Ethernet over fiber
Connects directly to RJ45 connector
IEEE 10/100 standards compliant
Auto MDI/MDI-X
Half or full duplex opera�on
User selectable link fault detec�on mode (Link Fault Pass-
through) allows quick fault isola�on
Extends network span up to 120km/74 miles (singlemode)
Bidirec�onal communica�on over a single fiber is available
Environmentally rugged with wide opera�ng temperature
range
U�lizes ultra-reliable 1x9 fiber op�c modules
On board LED status display
RLH Industries, Inc.
936 N. Main Street, Orange, CA 92867
RLH Industries, Inc.
Fiber Optic Link
Phone: 800-877-1672
www.fiberopticlink.com
10/100 Ethernet
U�lizes 24~56VDC power source
Available in singlemode and mul�mode
Available with ST, SC or FC connectors
Compa�ble with a wide variety of RLH Card
Housings
Limited Life�me Warranty
Made in USA
FAX: 714-532-1885
email: info@fiberopticlink.com
The leader in
rugged, fiber op�c
technology
UG-M071 2021-12-07

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RLH 10 and is the answer not in the manual?

Questions and answers

Summary of Contents for RLH Industries RLH 10

  • Page 1 UG-M071 2021-12-07 10/100 Ethernet Ethernet to Fiber Isolation Card The RLH 10/100 Ethernet fiber link card converts a 10/100BaseT RJ45 port to an op�cal signal for transmission over either mul�mode or singlemode fiber op�c cable. With half or full duplex opera�on, it also features Auto MDI/MDI-X so a straight through or crossover cable can be used regardless of end device.
  • Page 2: General Safety Practices

    The leader in RLH Industries, Inc. rugged, fiber op�c Fiber Optic Link technology USER GUIDE www.fiberopticlink.com General Safety Practices The equipment discussed in this document may require tools designed for the purpose being described. RLH recommends that service personnel be familiar with the correct handling and use of any installa�on equipment used, and follow all safety precau�ons including the use of protec�ve personal equipment as required.
  • Page 3 The leader in RLH Industries, Inc. rugged, fiber op�c Fiber Optic Link technology USER GUIDE www.fiberopticlink.com General Safety Practices (cont’d) Guidelines for Handling Terminated Fiber Cable ■ Do not bend fiber cable sharply; use gradual and smooth bends to avoid damaging glass fiber ■...
  • Page 4: System Diagram

    The leader in RLH Industries, Inc. rugged, fiber op�c Fiber Optic Link technology USER GUIDE www.fiberopticlink.com Applications Network equipment in high voltage areas can be at risk due to Ground Poten�al Rise (GPR). A copper network cable referenced to a remote ground can become a path for high voltages during a ground fault. Placement of all-dielectric fiber op�c cable (instead of copper) completely eliminates the presence of a remote ground, which drama�cally...
  • Page 5: Installation

    The leader in RLH Industries, Inc. rugged, fiber op�c Fiber Optic Link technology USER GUIDE www.fiberopticlink.com Installation Prior to installa�on: ■ Check for shipping damage ■ Check the contents to ensure correct model and fiber type ■ Have a clean, dry installa�on environment ready ■...
  • Page 6: Dip Switch Settings

    The leader in RLH Industries, Inc. rugged, fiber op�c Fiber Optic Link technology USER GUIDE www.fiberopticlink.com Installation (cont’d) DIP Switch Settings The front panel DIP switches may be set for op�onal modes. The factory default is for all switches. Switch Descrip�on...
  • Page 7: Troubleshooting

    TP port. If trouble persists, replace the unit and retest. If technical assistance is required, contact RLH Industries, Inc. technical support department*. *Tech support contact info is at the end of this document...
  • Page 8: Ordering Information

    The leader in RLH Industries, Inc. rugged, fiber op�c Fiber Optic Link technology USER GUIDE www.fiberopticlink.com Ordering Information Mode Connector Distance Fibers Wavelength Part Number Mul�mode 2km/1.2 miles Dual Fiber 1310nm EF4-04-2 Singlemode 20km/12.4 miles Dual Fiber 1310nm EF4-40-2 Singlemode...
  • Page 9: Key Specifications

    The leader in RLH Industries, Inc. rugged, fiber op�c Fiber Optic Link technology USER GUIDE www.fiberopticlink.com Key Specifications Protocols: 100BASE-FX, 10BASE-T, or 100BASE-TX Copper Connector: RJ45 UTP 100m/328 feet Copper Distance: Fiber Connector: ST or SC (Dual fiber or single fiber (bi-direc�onal) connectors)
  • Page 10: Tech Support

    The leader in RLH Industries, Inc. rugged, fiber op�c Fiber Optic Link technology USER GUIDE www.fiberopticlink.com Contact A�: Sales By Mail: RLH Industries, Inc. 936 N. Main St. Orange, CA 92867 By Phone: Local 714-532-1672 Sales / Service Toll Free...
