INSTRUCTION MANUAL
To use it safely ・・・・・・・・・・・・・・・・・・・１
１．OUTLINE・・・・・・・・・・・・・・・・・・・・・・・・２
２．SPECIFICATION・・・・・・・・・・・・・・・・・・・・・２
３．INSTALLATION ・・・・・・・・・・・・・・・・・・・・・３
４．WIRING ・・・・・・・・・・・・・・・・・・・・・・・・３
５．OPERATION METHOD ・・・・・・・・・・・・・・・・・・・４
６．STARTUP・・・・・・・・・・・・・・・・・・・・・・・・５
７．INTEGRAL SETTING ・・・・・・・・・・・・・・・・・・・６
８．LIMIT SETTING・・・・・・・・・・・・・・・・・・・・・７
９．MAINTENANCE・・・・・・・・・・・・・・・・・・・・・・８
１０．MAINTENANCE MODE ・・・・・・・・・・・・・・・・・・・８
１１．TROUBLESHOOTING・・・・・・・・・・・・・・・・・・・・９
１２．DIMENSION DRAWING (OUTLINE)・・・・・・・・・・・・・・11
※The operator should read this Instruction Manual carefully and
handle the device correctly.
1-8-18 Norimatsu-Higashi,Yahatanishi-ku,Kitakyushu 807-0837 Japan
Phone No.(8193)691-3731 Fax No.(8193)691-3735
http://www.matsushima-m-tech.com
E-mail sales@matsushima-m-tech.com
FOR
DUST MONITOR
TYPE
ＰＦＭ－Ｍ０１Ｅ
（COMPACT TYPE）
Contents
TPFM-004E
Rev8:May.5.2018
Advertisement
Related Manuals for Matsushima PFM-M01E
Summary of Contents for Matsushima PFM-M01E
- Page 1 ５．OPERATION METHOD ・・・・・・・・・・・・・・・・・・・４ ６．STARTUP・・・・・・・・・・・・・・・・・・・・・・・・５ ７．INTEGRAL SETTING ・・・・・・・・・・・・・・・・・・・６ ８．LIMIT SETTING・・・・・・・・・・・・・・・・・・・・・７ ９．MAINTENANCE・・・・・・・・・・・・・・・・・・・・・・８ １０．MAINTENANCE MODE ・・・・・・・・・・・・・・・・・・・８ １１．TROUBLESHOOTING・・・・・・・・・・・・・・・・・・・・９ １２．DIMENSION DRAWING (OUTLINE)・・・・・・・・・・・・・・11 ※The operator should read this Instruction Manual carefully and handle the device correctly. 1-8-18 Norimatsu-Higashi,Yahatanishi-ku,Kitakyushu 807-0837 Japan Phone No.(8193)691-3731 Fax No.(8193)691-3735 http://www.matsushima-m-tech.com E-mail sales@matsushima-m-tech.com...
- Page 2 Cause for any peripheral equipment or device. d. Accident beyond control and force majeure (fire, earthquake, flood, riots, etc.). Lack of instructions to MATSUSHIMA for information or safety requirements that can be predicted only by customers’ side. This warranty conditions do not limit customers’ legal right.
- Page 3 １．OUTLINE An electric charge is generated when solid particles in the gas passes through the probe of the dust monitor on the duct or pipe. This electric charge is known as frictional static electricity or contact electrification. The size of the electric charge can be calculated by the following equation and be regarded as the value of the electrical current and is in proportion to the amount of dust.
- Page 4 ３．INSTALLATION To install the Dust Monitor, use the one-inch socket that is provided. Weld the socket onto the pipe. Install the Dust Monitor so it is horizontal or vertical. Weld around the entire circumference of the pipe to prevent gas from leaking. (Attention in installation) The Dust Monitor may malfunction under the following environmental conditions.
- Page 5 ５．OPERATION METHOD Please refer to table 1 and figure 4 for indicator and the operation switch relation on the panel. Maintenance mode can be used to confirm “current signal adjustment”, “simulated alarm output”, “limit setting value”, and “integral setting value” by setting the Range Switch to “0”. Details have been described to 10.
- Page 6 ６．STARTUP 6-1．Warming-up The Dust Monitor needs to warm up for approximately one hour after the power supply is turned on. 6-2．Measuring Range After warming up, set the optimum measuring range. First, set the Range Switch to “1～4” if the flow speed is constant, the operation of the filter is normal, and the dust is the environmental conditions are normal.
- Page 7 ７．INTEGRAL SETTING The Dust Monitor can be set to output an averaged measuring signal by adjusting the Integration Volume (Data averaging). Follow the procedures below to carry out integral setting. (The Integration Volume is set to “0 s” at our factory before shipment, unless otherwise requested.) 1) Set the Range Switch to “0”.
- Page 8 Limit Setting Volume by referring to the current value. 0% (4mA) to 100% (20mA) 10.MAINTENANCE MODE Refer to 【Operation chart : LIMIT 1/2 and ALARM detection】 （LIMIT output） TYPE:PFM-M01E 20mA Set value (LIMIT) Time NO (open) NO (open)
- Page 9 ９．MAINTENANCE Use a rag to periodically clean the probe. Maintenance scheduling depends on what is being measured and under what conditions. As outlined in the guidelines, we recommend cleaning the probe at least once every three months. Turn off the power before cleaning. Be careful not to burn yourself when removing the probe.
- Page 10 Example. Current value necessary for integrating 3.5 seconds. ３．５×０．５３３＋４＝５．８７ｍＡ Range Switch POWER LED （Green） LIMIT SET LED（Green） LIMIT LED （Yellow） Mode Change Switch ALARM LED （Red） I.TIME SET LED（Green） LIMIT adj. Volume I.TIME adj. The tester is connected Volume 4 mA adj. 20 mA adj.
- Page 11 Malfunction Possible Cause Corrective Action ・ Short-circuited between the electrode and the ・ Remove the sensor and check if The output value is too high. duct or pipe because of material stuck onto the any material is stuck onto the electrode surface.
- Page 12 １２．DIMENSION DRAWING（OUTLINE） Fig.8. Dimension drawing of Dust Monitor TYPE：PFM-M01E Housing Main Unit ※Please give A 10mm or more. ※Please give B 20mm or more. Please have not accumulated dust in B. Fig.9. Installation reference figure - 11 -...
