Summary of Contents for AOC Envision Series L22H998
- Page 1 22” LCD TV L22H998...
-
Page 2: Table Of Contents
FOR YOUR SAFETY ... 2 PRECAUTIONS AND REMINDERS ... 4 IMPORTANT SAFETY INSTRUCTIONS ... 6 Quick Installation ... 8 Wall-mount instruction ... 9 ACCESSORIES... 11 FRONT PANEL BUTTONS ... 12 BACK PANEL BUTTONS... 13 REMOTE CONTROL ... 14 INSTALLATION... 16 Connecting RF antenna and Cable TV ... - Page 3 DANGEROUS VOLTAGE: The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that SA 1965 may be of sufficient magnitude to constitute a risk of electrical shock to persons.
-
Page 4: For Your Safety
FOR YOUR SAFETY Before operating the TV please read this manual thoroughly. This manual should be retained for future reference. FCC Class B Radio Frequency Interference Statement WARNING: (FOR FCC CERTIFIED MODELS) NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. - Page 5 DIGITAL TELEVISION TRANSITION NOTICE This device contains a digital television tuner, so it should receive digital over the air TV programming, with a suitable antenna, after the end of full-power analog TV broadcasting in the United States on June 12, 2009. Some older television receivers, if they rely on a TV antenna, will need a TV Converter to receive over the air digital pro-gramming, but should continue to work as before for other purposes (e.g., for watching low-power TV stations still broadcasting in analog,...
-
Page 6: Precautions And Reminders
PRECAUTIONS AND REMINDERS Place unit on even surfaces. Unplug immediately if is malfunction like no picture, no video/audio,smoke and bad odor from TV. Don't throw any object inside the TV box like metals or other flammable materials. Don't place the TV in confined spaces or in a box when using it. - Page 7 Remember to unplug the AC cord from the AC outlet before cleaning. Do not use liquid cleaners or aerosol cleaners to clean the display. Make sure to unplug the unit when not in use for a long period of time (days). Do not cover or block any vents and openings.
-
Page 8: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Read before operating equipment Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with a dry cloth. Do not block any of the ventilation openings. Install in accordance with the manufacturers instructions. - Page 9 18. Tilt/Stability – All televisions must comply with recommended international global safety standards for tilt and stability properties of its cabinets design. Do not compromise these design standards by applying excessive pull force to the front, or top, of the cabinet, which could ultimately overturn the product.
-
Page 10: Quick Installation
Quick Installation Install Remove Install the stand base to the TV. Remove the stand base from the TV. -
Page 11: Wall-Mount Instruction
Wall-mount instruction Preparing To Install The Optional Wall Mount Arm (not included) This TV can be attached to a wall mounting arm you can purchase separately. Turn the power OFF then disconnect the cables from the TV before performing the procedure below. 1. - Page 12 Attaching The Optional Wall Mount Arm (not supplied) Follow these steps to finish installing the wall mounting arm: 1. Place the wall mounting arm onto the back of the TV. Line up the holes of the arm with the holes in the back of the monitor.
-
Page 13: Accessories
ACCESSORIES Thank you for purchasing this LCD-TV. This LCD-TV package comes with: LCD TV User’s Guide book Remote control Battery AA x 2 Power Cord Quick Setup Guide Pedestal stand... -
Page 14: Front Panel Buttons
FRONT PANEL BUTTONS Volume Up Volume Down On Screen Display Menu On/Off CH Up CH Down Input Source Selection (Enter) Power ON/OFF button Power LED Indicator Remote Control Receiver... -
Page 15: Back Panel Buttons
BACK PANEL BUTTONS AC Power Switch (Must be turned on) Power (AC input) HDMI Input Terminal VGA signal input Composite Video input YPbPr signal input S-Video input AV/ S-Video signal Audio input (left/right) YPbPr signal Audio input (left/right) PC Audio input Headphone Jack Cable/ Air TV input F G H I... -
Page 16: Remote Control
REMOTE CONTROL... - Page 17 Remote control button function as follows: INPUT ENTER - VOL + LIST GUIDE 0~9, - number POWER UP/ DOWN/ LEFT/ RIGHT MENU ▼ ▲ ZOOM MUTE INFO SLEEP LAST Input source select Confirm selection or enter selected menu Direct to TV source Adjust volume UP/DOWN Select channel from program list Select electronic program guide (EPG) (Only available in DTV...
-
Page 18: Installation
INSTALLATION Connecting RF antenna and Cable TV Make sure the power is OFF before installing your LCD TV. 1) AIR TV: Connect the LCD TV to TV antenna with 75-ohm coaxial cable. Preset the air TV channels into memory with Auto Scan function when using an antenna TV system. This air input jack both support TV and DTV systems. - Page 19 2) With S-Video cable: 3) With YPbPr cable: 4) With HDMI cable: S-Video Cable (not supplied) VCD or DVD Player Audio Cable (not supplied) YPbPr Cable (not supplied) Audio Cable (not supplied) HDMI Cable (not supplied) VCD or DVD Player VCD or DVD Player (DVD Player should have the HDMI output terminal)
-
Page 20: Connecting To The Headphone
With HDMI-DVI cable: Connecting to the Headphone Connect the headphone to the headphone output terminal of the LCD TV. (Headphone sold separately). Connecting to a Computer 1) With VGA Cable: Connect the VGA cable from VGA output of the computer to the VGA terminal input of your LCD TV. -
Page 21: Connecting With The Power Cord
2) With HDMI-DVI Cable: Connect the HDMI-DVI cable from the DVI output of the computer to the HDMI terminal input of the LCD TV. Also, connect the green end of the Audio In cable from the audio output of your computer to the audio input terminal (red/white) of the LCD TV. -
Page 22: Basic Operation
BASIC OPERATION To operate your LCD TV, you may use the TV remote control or bottom panel buttons to select input source, change channels, or adjust volume. Turning on the LCD TV Before using the LCD TV: 1. Connect external equipment properly. 2. -
Page 23: Electronic Program Guide (Epg)
Electronic Program Guide (EPG) Press the GUIDE button on the remote control and the program information for the channel you are watching will be displayed on the screen. This function is only available when in DTV source. * The picture here shows an example of the GUIDE screen in a DTV source. Channel Select Press number key or ▼CH▲... -
Page 24: Favorite Channels
Favorite Channels Press FAV button to show Favorite List and select your favorite channels that have already been stored. (You need to preset the favorite channels from the OSD menu to enable this function.) Sleep Time Setting Repeatedly press SLEEP button to set the off timer. The function is used to automatically shut off the LCD TV after a preset period of time passed. -
Page 25: Using The Osd Function
Using the OSD function You can use the OSD menus and options to adjust various settings by using the remote control. The basic operation is as following: Press MENU to display OSD menu. Press ◄► to select your desired top Menu, and press ENTER or ▼ to enter the menu you select. -
Page 26: Advanced Operation-Osd Menu
ADVANCED OPERATION—OSD MENU PICTURE Menu —To adjust the picture quality In TV, AV, S-Video, YPbPr, HDMI source: Note: The CHANNEL Menu icon on the screen will disappear in AV, S-Video, YPbPr, and HDMI sources. In PC source: Picture Mode: To select picture mode between Standard, Dynamic, Soft, and Personal. Contrast: To adjust contrast of video. -
Page 27: Audio Menu
Zoom Mode: To select image size from Full, 4:3, Movie Scale, or Zoom In. Noise Reduction: To select noise restriction function from Standard, Strong, Off, or Weak. (Not supported in or above 720p) Advanced: To adjust advanced PC functions, press ► to enter. (only appear in PC source) Auto: To auto adjust picture’s horizontal position, vertical position, fine tune and H-Size. -
Page 28: Time Menu
In AV, S-Video, YPbPr, HDMI, PC source: Sound Mode: To select sound mode between Standard, Music, Movie, Sports, and Personal. Treble/Bass: To adjust the treble, bass or balance. Prefer Language: To select the available audio languages. (only enabled in DTV mode) MTS: Press ◄►... -
Page 29: Option Menu
Clock: To adjust the current time. Press ► to enter. Use ◄► to move between Year, Month, Date, Hour, Minute, and use ▲▼ to adjust. Select OK and press ENTER to save the setting. ＊The “Clock” time can only be adjusted manually, when “Auto Sync” is set to “Off”. OPTION Menu —To set up OSD window In TV, AV, S-Video source:... - Page 30 Closed Caption: To set close caption options. CC Mode: To select Closed Caption Mode from CC Off, CC On, or CC on Mute. Basic Selection: To set basic analog closed caption options. (CC1~CC4, TEXT1~TEXT4, or Off) Advanced Selection: To select closed caption signal formats and set up caption modes for digital TV channels.
-
Page 31: Lock Menu
LOCK Menu —To set up parental control In TV, AV, S-Video, YPbPr, HDMI, PC source: Note: The CHANNEL Menu icon on the screen will disappear in AV, S-Video, YPbPr, HDMI, and PC sources. Enter Password: Enter password and the screen below will show. (The default password is 0000.) Note: Some options will be disabled when in YPbPr, HDMI, or PC source. - Page 32 US: Press ► to set TV or MPAA ratings. TV: To adjust TV blocking level in the US. The following screen will allow you to customize the following TV ratings: TV-Y (all children) TV-Y7 (older children) TV-G (general audience) You can also customize the TV ratings for the following content: ALL (All types of content) FV (fantasy violence) V (violence)
- Page 33 MPAA: To adjust movie blocking level in the US. You can select between G, PG, PG-13, R, NC-17, X, or N/A. The movie Ratings in the US are defined as following: G (general audience) PG (parental guidance suggested) PG-13 (recommended for children 14 years of age or older) R (mature audience) Canada: Press ►...
- Page 34 Canada Eng: To adjust blocking level in English-speaking region of Canada. You can select between C, C8+, G, PG, 14+, 18+, EXEMPT. The Canadian English Ratings are defined as following: C (children) C8+ (children eight years and older) G (general programming, suitable for all audiences) PG (parental guidance) Canada Fre: To adjust blocking level in French-speaking region of Canada.
-
Page 35: Channel Menu
CHANNEL Menu —To set up for TV Note: The Channel Menu is only active in TV source. When in AV, S-Video, YPbPr, HDMI, or PC source, the CHANNEL Menu will not appear. Note: The condition of DTV Signal will only be displayed when source is in DTV. TV Source: To select Cable or Air as the TV source. - Page 36 Favorite: To set your favorite channels into memory. Press ENTER to confirm/ cancel your favorite channels. Press◄ / ► to go to previous / next page. Show/Hide: Press ENTER to skip the selected channel. To restore the channel, press ENTER again.
- Page 37 Channel Label: Press ► to edit a name for the current channel (the channel selected in Channel No.). Use ▲▼ to choose letters or signs, ◄► to move forward or backward, and then press MENU or ENTER to exit. DTV Signal: To display the detected signal strength of the current DTV channel.
-
Page 38: Technical Specification
TECHNICAL SPECIFICATION Type Color Filter Glass surface Input signal Video Audio Compatibility Recommended Resolution and supported Speaker Output Audio Output Voltage Power Full Scan Display area Temperature Operating Humidity conditions Altitude Temperature Storage condition Humidity Altitude Physical Dimensions With stand Weight (Net) Without stand Regulations... -
Page 39: Safety Precautions
SAFETY PRECAUTIONS This LCD TV is manufactured and tested to insure the user’s safety. Improper use or installation may result danger to the LCD TV as well as to the user. Carefully go over the following WARNINGS before installation and keep this guide handy. WARNINGS This LCD TV should be operated only at the correct power sources indicated on the label on the rear end of the LCD TV. -
Page 40: Care And Maintenance
CARE AND MAINTENANCE Care Avoid exposing your LCD TV directly to sunlight or other heat source. Place your LCD TV away from the sun to reduce glare. Put your LCD TV in a well ventilated area. Do not place anything heavy on top of your LCD TV. Make certain your LCD TV is installed in a clean and moisture-free area.
