-R Option - Run Relay Activation:

The Run Relay is a SPDT user output relay that is normally activated if a run command is given.
The output for both NC and NO can switch up to 1A loads at 100Vdc or 120Vac max.
Note: The relay output is active per the activation chart below regardless of the master potentiometer
setting.
Run Input
Active
Inactive
Active
Active
Active

Troubleshooting

Technical Support Options

•
Visit the Dart Controls Web Site at: www.dartcontrols.com
•
Email technical support at: sales@dartcontrols.com
•
Telephone technical support at 317-873-5211

What's Special About www.dartcontrols.com?

•
Changes to printed material and product offerings first appear online
•
Product manuals and other literature are easily accessible
•
All information can be easily displayed or printed as needed

Basic Operating Information

Current Limit IGBT Temperature
exceeded shutdown value
Not exceeded Not Exceeded
Not exceeded Not Exceeded
Exceeded Not exceeded
Not exceeded Exceeded
Not exceeded Not exceeded
EEPROM Corruption
Not detected
Not detected
Not detected
Not detected
Detected
10
Relay state
ON
OFF
OFF
OFF
OFF
