Summary of Contents for dreo DR-HSH003
- Page 1 PTC Fan Heater User Guide support@dreo.com MODEL: DR-HSH003 MANUFACTURER： support@dreo.com Shenzhen Hesung Innovation Technology Co., LTD...
-
Page 2: Table Of Contents
CONTENTS IMPORTANT SAFETY INSTRUCTIONS -------------------------01 USING YOUR HEATER --------------------------------------------------06 Package Contents ------------------------------------------------------07 Product Diagram --------------------------------------------------------07 Control Panel -------------------------------------------------------------08 IMPORTANT Remote Control ----------------------------------------------------------08 Operations and Functions -------------------------------------------09 SAFETY Other Features ----------------------------------------------------------11 Replacement of Batteries in Remote Control -----------------12 INSTRUCTIONS Specifications ------------------------------------------------------------13 CLEANING AND MAINTENANCE -----------------------------------14 TROUBLESHOOTING ----------------------------------------------------16 WARRANTY AND SERVICE -------------------------------------------19... -
Page 3: Important Safety Instructions
Do not use outdoors. Thanks for choosing the Dreo PTC Fan Heater. Please read this User Guide thoroughly before use and retain it for future This heater is not intended for use in bathrooms, reference. laundry areas and similar indoor locations. Never locate... - Page 4 It is normal for the plug and cord to feel warm to the NOTE: There may be a trace of smoke or odor when the touch. A plug or cord which becomes hot to the touch unit is first operated. This indicates that a drop of oil fell or becomes distorted in shape may be a result of a on the heating coil during the manufacturing process.
-
Page 5: Using Your Heater
Package Contents 1 x PTC Fan Heater 1 x Remote Control 1 x Thank You Card 1 x User Guide Product Diagram Control Buttons Handle USING YOUR Display HEATER Rear Cover Air Outlet PTC Fan Heater Power Cord and Plug Base... -
Page 6: Control Panel
Control Panel Operations and Functions Place the heater on a firm, level surface free from obstructions, and at least 3ft. (0.9m) away from any wall or combustible material. Plug into an appropriate voltage AC 120V outlet, The unit will enter standby mode with a beep and power indicator on red. -
Page 7: Other Features
Other Features Temperature Adjustment When the unit is on, press on the heater / remote control to adjust the temperature from 41 The heater is designed with power-off to 95°F in 1°F increments. Memory memory function. It will always remember your When the set temperature (T0) is reached, the Function last settings (temperature, working mode,... -
Page 8: Replacement Of Batteries In Remote Control
Press the locking button Replace the battery with to pop out the battery the same type (CR2025 holder. 3V), making sure the (+) side facing up. Specifications Model DR-HSH003 Input 120V~ 60Hz Rated Power 1500W (High) 900W (Low) Remote Control CR2025, 3V Battery... -
Page 9: Cleaning And Maintenance
Cleaning and Maintenance It is recommended that the heater be cleaned at least one time during the operating season and before off-season storage in order to provide the optimum level of performance. Always disconnect the appliance from the mains by switching it off and removing the plug from the power outlet before cleaning. -
Page 10: Troubleshooting
Troubleshooting The following troubleshooting guide addresses the most common problems. If problems persist, contact the Customer Support at support@dreo.com. Problem Possible Causes Solution Unplug it from the E2 - Temperature sensor power source and short circuit contact Customer Support. Unplug it from the... -
Page 11: Warranty And Service
Turn the heater OFF, unplug it and allow it to cool. Check and remove any objects on or Overheat Protection adjacent to the has been activated. heater. Wait 5-10 minutes before plugging the unit back in. Heater does Ensure that your not start circuit breaker or fuse is working properly. - Page 12 If you encounter any issues or have any questions regarding Thanks for choosing DREO heater. This product is covered your new product, please contact our helpful Customer with DREO product and labor warranty for 12 months from the Support Team. date of its original purchase.
