Panasonic TC-20KL03A Service Manual

TELEVISION
Power source
Consumption
Antenna input jack
Color systems
Tuning system
Channel capability
Picture tube (Diagonal Visual)
Audio system
Video input jack
Audio input jack
Video Outlet
Audio Outlet
Dimension (width, height, depth)
Weight
Remote Control Transmiter:
Power Source
Infrared Length
Number of Buttons
Dimensions (W x H x D)
Specifications are subject to change without notice. Weight and dimensions shown are approximate.
Panasonic
All manuals and user guides at all-guides.com
110/220 V AC, 50/60 Hz automatic switch
75 ohms - VHF/UHF/CATV
PAL-M/NTSC/PAL-N
Panablack 48 cm
1 (back) + 1 (front)
1 (back) + 1 (front)
1 (back) + 1 (earphone)
600 x 473 x 487 (mm)
3V (2 AA type batteries)
9500 A (Angstron)
29 keys
(54 x 27 x 135) mm
TC-20KL03A
79 W
F.S.T.
2 to 13 (VHF)
14 to 69 (UHF)
1 to125 (CATV)
50 W PMPO
1 (back)
17.7 kg
Order DCS - NOV2003 - 001 - MS
TC-20KL03A
110/220 V AC, 50/60 Hz automatic switch
120 W
75 ohms - VHF/UHF/CATV
PAL-M/NTSC/PAL-N
F.S.T.
2 to 13 (VHF)
14 to 69 (UHF)
1 to125 (CATV)
Panablack 68 cm
82 W PMPO
1 (back) + 1 (front)
1 (back) + 1 (front)
1 (back)
1 (back) + 1 (earphone)
760 x 579 x 512 (mm)
34 kg
Supplied Accessories:
• 1 Remote Control Transmitter
• 1 300Ω/75Ω Balum
• 2 "AA" (or R6) batteries (1.5V; ABNT/IEC)
• 1 Internal antenna (for TC-20KL03A only)
© 2003 Panasonic da Amazônia S/A
CS Division
Technical Support
