Panasonic TC-29G12P Service Manual

Panasonic crt television user manual
Hide thumbs

Advertisement

Quick Links

Download this manual
l
l
l
The above specifications are subject to changes without notice.

Advertisement

loading

Related Manuals for Panasonic TC-29G12P

Summary of Contents for Panasonic TC-29G12P

  • Page 1 The above specifications are subject to changes without notice.

  • Page 3: Controls Location

    Controls Location Frontal View 1. POWER button By pressing this button the TV set is placed on STAND BY, and it is necessary to press the button STAND BY (3) to turn the TV set on. When switched to OFF the TV set is completely disconnected from the POWER LINE.

  • Page 4: Installation

    Installation How to connect an external antenna To obtain the best audio and video quality it is necessary to install an external antenna, with adequate cables (75 ohms co-axial cable) and the adequate terminal connector. Your local TV service can help you to acquire the adequate system and accessories for the installation of an external antenna in your location.
  • Page 5 Operation TV/VIDEO button R-TUNE quick tune in button Press this button to select TV input or VIDEO Use this button to alternate instantly input. between the two channels last selected. RECALL button Press this button to display the following functions: •...
  • Page 6 Operation Selecting the MENU language The language of the menu is factory set to Brazilian Portuguese. Follow the instructions below to change the menu language to either English, Portuguese or Spanish. 1. Press the ACTION button to display the main menu. 2.
  • Page 7 Operation Adjusting the image Adjusting color, hue, brightness, contrast and sharpness This TV set has 4 pre-adjusted image menus: DINAMIC, NORMAL, SOFT and 1. Press the ACTION button to display the GAME. Within each of these menus it is main menu. possible to change image configuration 2.
  • Page 8 Operation Color system and color saturation adjustment for each channel This TV set is compatible with three broadcast standards. That means this TV set can be used where either the PAL-M, PAL-N, or NTSC transmission standard is used. The AUTO capability allows the set to recognize automatically the broadcast standard being used.
  • Page 9 Operation Unlocking channels To unlock channels, follow steps 1 through 3 of the “GAME GUARD” procedure. Then, using the numerical keypad on the remote control, key in exactly the three-digit password previously selected during the GAME GUARD procedure. Type the same 3-digits code Unlocked previously used.
  • Page 10 Operation 3. Press again the ACTION button to 9. Repeat steps 5 through 7 to program display the timer control menu. the hour and minutes when the TV set should turn itself off (OFF). 10. Press the button CHANNEL ($) to select “CHANNEL”.
  • Page 11 Operation Adjusting the image Adjusting color, hue, brightness, contrast and sharpness This TV set has 4 pre-adjusted image menus: DINAMIC, NORMAL, SOFT and 1. Press the ACTION button to display the GAME. Within each of these menus it is main menu. possible to change image configuration 2.
  • Page 12 Operation Antenna mode Tune in mode for TV or Cable TV. It is necessary to select the antenna input appropriate for the input mode corresponding to the type of the local broadcast signal. Note: This function is disabled when the function “GAME GUARD” is active. •...

  • Page 13: Auto Power On

    Operation Manual channel tuning. This function allows the desired channels to be tuned in manually. Note: This function is automatically disabled when the function “GAME GUARD” is active. 4. Press the button CHANNEL ($) to select the option “PRESS CH $ FOR MORE”, and a second page with options will display.
  • Page 14 Operation Subtitles display mode “ cc MODE” This feature is used to help hearing-impaired viewers and also in language learning. This TV set features a built-in decoder that supplies a visual description of the audio track of certain TV programs, displaying the words as subtitles across the screen. This allows the viewer to also read the dialogs in TV programs or other information.
  • Page 15 Connection Connecting to an amplifier (stereo equipment) Terminals (LINE OUT FOR AUDIO AMPLIFIER) Connect these terminals to the AUX input of a stereo amplifier to listen to the stereo sound through the amplifier. Obs.: The terminals labeled “P/ AMPLIF. DE 1.
  • Page 26 Standard DAC table Z-board (Pincushion) - Schematic Diagram Y-board (CRT) - Schematic Diagram...
  • Page 27 TC-20G12P / TC-29G12P / TC-29G12PU Main Board Schematic Diagram - TC-20G12P / TC-29G12P / TC-29G12PU - 27 -...
  • Page 35 TZGNPAC29G12P A/C BOARD TZGNPZ29G12 Z BOARD C003 ECA1HM4R7B CAP. ELETROL. 4,70 µF 50 V C004 ECJ2VC1H330J CAP. CER. SMD 33 PF 50 V C005 ECJ2VC1H330J CAP. CER. SMD 33 PF 50 V C008 ECJ2VF1H104Z CAP. CER. SMD 100 nF 50 V C009 ECA1HM100B CAP.
  • Page 36 C804 ECKWAE472ZED CAP. CER. 4,70 nF 250 V C805 ECKR1H471KB6 CAP. CER. 470 PF 50 V C806 ECKWAE472ZED CAP. CER. 4,70 nF 250 V C807 ECKWAE472ZED CAP. CER. 4,70 nF 250 V C810 ECKCNA152MEB CAP. CER. 1,50 nF 4.000 V C811 ECA1EM101B CAP.
  • Page 37 ERJ6GEY0R00V RES. MET. FILM SMD 0 ERJ6GEY0R00V RES. MET. FILM SMD 0 ERJ6GEY0R00V RES. MET. FILM SMD 0 ERJ6GEY0R00V RES. MET. FILM SMD 0 JS006 ERJ6GEY0R00V RES. MET. FILM SMD 0 JS011 ERJ6GEY0R00V RES. MET. FILM SMD 0 JS1002 ERJ6GEY0R00V RES.
  • Page 38 R167 ERDS2TJ181T RES. CARBON 180 R168 ERJ6GEY0R00V RES. MET. FILM SMD 0 R170 ERJ6GEYJ471V RES. MET. FILM SMD 470 R171 ERJ6GEYJ682V RES. MET. FILM SMD 6,80 k 1/10 W R172 ERDS2TJ331T RES. CARBON 330 R173 ERDS2TJ101T RES. CARBON 100 R203 ERJ6GEY0R00V RES.
  • Page 39 R773 R774 R775 R776 R777 R778 R801 R802 ERG2FJ683H RES. MET. FILM 68 k 2 W R803 ERD50FJ474P RES. CARBON 470 k 1/2 W R804 ERD25TJ681T RES. CARBON 680 R805 R806 ERD25TJ332T RES. CARBON 3,30 k 1/4 W R807 ERDS1FJ220T RES.

This manual is also suitable for:

Tc-20g12pTc29g12pu
